Ford Police Interceptor Sedan (2018 year). Manual - part 18

Trip 1 & 2

You can access the menu using the
information display control.

Note:

Some options may appear slightly

different or not at all if the items are
optional.

Trip 1 & 2

Digital Speedometer

Trip Odometer

Trip Timer

Average Fuel

•

Digital Speedometer - Shows a digital display of your vehicle speed.

•

Trip Odometer — Registers the distance of individual journeys.

•

Trip Timer — The timer stops when you turn your vehicle off and restarts when you
restart your vehicle.

•

Average Fuel — Shows the average fuel economy for a given trip.

Note:

Press and hold OK on the current screen to reset the respective trip, distance, time

and fuel information.

Fuel Economy

Fuel Economy

Dist to empty

Inst Fuel Econ

Average Fuel

•

Distance to Empty - Shows the approximate distance your vehicle can travel before
running out of fuel.

•

Inst Fuel Economy - Shows a visual graph of your instantaneous fuel economy along
with your Avg MPG since the function was last reset.

•

Average Fuel — Shows the average fuel economy since last reset.

Note:

You can reset your average fuel economy by pressing and holding the OK button on

the left hand steering wheel controls.

Information

Information

Coolant Temp. — The engine coolant indicator changes colors indicating: blue for cool,
gray for normal and red for hot. If the engine coolant temperature exceeds the normal
range, stop the vehicle as soon as safely possible, switch off the engine and let the
engine cool.

Engine hours — Displays the hours of engine run time.

Engine Idle hours — Indicates how much time the vehicle idles in Park or Neutral.

Settings

In this mode, you can configure different
driver setting choices.

Note:

Some items are optional and may

not appear.

Settings

Traction Ctrl

Driver Assist

Blindspot

Cross Traffic

Rear Park Aid

Choose your applicable setting.

Language

Display

Choose your applicable setting.

Distance

Units

Temperature

Choose your applicable setting.

DTE calcula-
tion

Convenience

Choose your applicable setting.

Remote Unlock

Locks

Oil Life Reset XXX% — Hold OK to Reset

Oil Life
Reset

Silent Mode

Courtesy Wipe

Wipers

INFORMATION MESSAGES

Note:

Depending on the vehicle options

equipped with your vehicle, not all of the
messages will display or be available.
Certain messages may display abbreviated
or shortened depending upon which cluster
type you have.

E213998

Press the OK button to acknowledge and
remove some messages from the
information display. Other messages
delete automatically after a short time.

You need to confirm certain messages
before you can access the menus.

AdvanceTrac™

Action

Message

Displayed when the AdvanceTrac® system has detected a

condition that requires service. Contact your authorized dealer

as soon as possible.

Service AdvanceTrac

The driver has disabled or enabled the traction control.

AdvanceTrac Off On

Alarm

Action

Message

Displayed when the perimeter alarm system is armed and the

vehicle is entered using the key on the driver’s side door. In

order to prevent the perimeter alarm system from triggering,

the ignition must be turned to start or on before the 12 second

chime expires.

Vehicle Alarm To Stop

Alarm, Start Vehicle.

AWD

Action

Message

Displays if the AWD system disables to protect itself. This

may occur if you operate the vehicle after installing the

compact spare tire, if the system is overheating or if there is

an issue with another vehicle system that prevents the AWD

system from operating. The AWD system resumes normal

operation and clears this message after you install the road

tire and you switch the ignition on and off, or after you allow

the system to cool. If this message remains on, have a quali-

fied technician service your vehicle to repair other vehicle

systems.

AWD OFF

Displayed in conjunction with the powertrain malfunction/

reduced power light when the system is not operating properly.
If the warning stays on or continues to come on, contact your

authorized dealer as soon as possible.

Check AWD

Displayed when the system needs its power transfer unit

lubrication changed. This message may be set if the vehicle

has experienced extended periods of extreme/severe duty

cycle driving.

Change AWD Power

Transfer Unit Lube

Battery and Charging System

Action

Message

Displayed when the charging system needs servicing. If the

warning stays on or continues to come on, contact your

authorized dealer as soon as possible.

Check Charging System

The battery management system detects an extended low
voltage condition. Your vehicle will disable various features

to help preserve the battery. Turn off as many of the electrical

loads as soon as possible to improve the system voltage.

Once the system voltage recovers, the disabled features will

operate as normal.

Low Battery Features

Temporarily Turned Off

The battery management system determines that the battery

is at a low state of charge. Switch the ignition off as soon as

possible to protect the battery. This message clears once you
start the vehicle and the battery state of charge has recovered.
Turning off unnecessary electrical loads allows faster battery

state-of-charge recovery.

Turn Power Off To Save

Battery
