SPECIAL OPERATING
CONDITIONS SCHEDULED
MAINTENANCE

If you operate your vehicle primarily in any
of the following conditions, you need to
perform extra maintenance, as indicated.
If you operate your vehicle occasionally
under any of these conditions, it is not
necessary to perform the extra
maintenance. For specific
recommendations, see your dealership
service advisor or technician.

Perform the services shown in the
following tables when specified or within
3,000 mi (4,800 km) of a message
appearing in the information display
prompting you to change your oil.

Example 1: The message comes on at
28,751 mi (46,270 km). Perform the
30,000 mi (48,000 km) automatic
transmission fluid replacement.

Example 2: The message has not
come on, but the odometer reads
30,000 mi (48,000 km) (for example,
the Intelligent Oil-Life Monitor was
reset at 25,000 mi (40,000 km)).
Perform the engine air filter
replacement.

Towing a trailer or using a car-top carrier

Change engine oil and filter as indicated by the information
display and perform services listed in the Normal Sched-
uled Maintenance chart.

As required

Inspect rear axle and U-joints. Lubricate if equipped with
grease fittings.

Inspect frequently, service
as required

See axle maintenance items under Exceptions.

Change manual transmission fluid.

Every 60,000 mi
(96,000 km)

Replace spark plugs.

Extensive idling or low-speed driving for long distances, as in heavy commercial use

(such as delivery, taxi, patrol car or livery)

Change engine oil and filter as indicated by the information
display and perform services listed in the Normal Sched-
uled Maintenance chart.

As required

Replace cabin air filter.

Inspect frequently, service
as required

Inspect engine air filter. Replace as required.

Every 15,000 mi
(24,000 km)

Replace spark plugs.

Every 60,000 mi
(96,000 km)

Operating in dusty or sandy conditions (such as unpaved or dusty roads)

Replace cabin air filter.

Inspect frequently, service
as required

Inspect engine air filter. Replace as required.

Every 15,000 mi
(24,000 km)

Inspect the wheels and related components for abnormal
noise, wear, looseness or drag.

Every 5,000 mi (8,000 km)

Rotate tires, inspect tires for wear and measure tread
depth.

Change engine oil and filter.

*

Every 5,000 mi (8,000 km)
or six months

Change manual transmission fluid.

Every 50,000 mi
(80,000 km)

*

Reset your Intelligent Oil-Life Monitor after each engine oil and filter change.

Exclusive use of E85 (Flex fuel vehicles only)

If ran exclusively on E85, fill the fuel tank full with regular
unleaded fuel.

Every oil change interval

Exceptions

There are several exceptions to the Normal
Schedule:

Rear Axle Maintenance

A rear axle fluid change or level check is
not required unless a leak is suspected or
the assembly has been submerged in
water. During long periods of trailer towing
with outside temperatures above 70°F
(21°C), and at wide-open throttle for long
periods above 45 mph (72 km/h), change
the rear axle fluid every 30,000 mi
(48,000 km) or three months, whichever
comes first (if rear axle is filled with
non-synthetic fluid). This interval can be
waived and 150,000 mi (240,000km)
service interval can continue if the rear axle

is filled with 75W85 synthetic gear fluid
meeting Ford specification
WSS-M2C942-A, part number
XY-75W85-QL, or equivalent. Add friction
modifier XL-3 (EST-M2C118-A) or
equivalent for complete refill of
Traction-Lok rear axles.

California Fuel Filter Replacement

If you register your vehicle in California, the
California Air Resources Board has
determined that the failure to perform this
maintenance item does not nullify the
emission warranty or limit recall liability
before the completion of your vehicle's
useful life. Ford Motor Company, however,
urges you to have all recommended
maintenance services performed at the
specified intervals and to record all vehicle
service.

Hot Climate Oil Change Intervals

Vehicles operating in the Middle East,
North Africa, Sub-Saharan Africa or
locations with similar climates using an
American Petroleum Institute (API)
Certified for Gasoline Engines (Certification
mark) oil of SM or SN quality, the normal
oil change interval is 3,000 mi (4,800 km).

If the available API SM or SN oils are not
available, then the oil change interval is
1,800 mi (2,900 km).

Engine Air Filter and Cabin Air Filter
Replacement

The life of the engine air filter and cabin air
filter is dependent on exposure to dusty
and dirty conditions. Vehicles operated in
these conditions require frequent
inspection and replacement of the engine
air filter and cabin air filter.

SCHEDULED MAINTENANCE RECORD

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp
