Ford Mustang (2018 year). Manual - part 95

Description

Item

Callout

Touch the button to maximize

defrosting. Outside air flows

through the windshield vents,

the fan automatically adjusts to

the highest speed and the

temperature dial returns to the

MAX Defrost:

full heat position. You can use

this setting to defog or clear a

thin covering of ice from the

windshield. The heated rear

window also automatically turns
on when you select MAX Defrost.

Touch to clear the windshield of

fog and thin ice. Touch again to

return to the previous airflow

selection. When on, defrost

provides outside air to reduce

window fogging and distributes

air through the windshield

defroster vents and demister

vents.

Defrost

Note: To prevent window

fogging, you cannot select recir-

culated air when Defrost is on.

Touch the button to switch on automatic operation.
Select the desired temperature using the temperature
control. The system adjusts fan speed, air distribution,
air conditioning operation, and selects outside air or
recirculated air to heat or cool the vehicle in order to
maintain the desired temperature.

AUTO

D

Touch the button to switch the system on and off.
Switching off the climate control system prevents
outside air from entering the vehicle.

Power

E

This button lights up when the passenger controls are
active. To switch the dual zone operation off and link
the passenger temperature to the driver temperature,
touch the DUAL button to switch it off.

DUAL

F

Touch up or down to adjust the temperature.

Right-hand front seat
temperature

G

Touch up or down to increase or decrease the volume
of air circulated in your vehicle.

Fan speed:

H

 (If Equipped)

Description

Item

Callout

A popup appears on the screen to display the air
conditioning options.

A/C

I

Touch to cool your vehicle with

recirculated air. Touch again for

normal A/C operation. MAX A/C

distributes air through instru-

ment panel vents and may help
reduce odors from entering your

vehicle. MAX A/C is more

economical and efficient than

normal A/C mode.

MAX A/C

Touch to switch the air condi-

tioning on or off. Use A/C with

recirculated air to improve

cooling performance and effi-

ciency. A/C engages automatic-

ally in MAX A/C, defrost and

footwell/defrost

A/C

Touch to switch the recirculated

air on or off which may reduce
the amount of time needed to

cool down the interior and help

reduce odors from reaching the

interior. Recirculated air also

Recirculated air:

engages automatically when
you select MAX A/C. You can

engage this manually in any

airflow mode except defrost. It

may also turn off in all airflow

modes except MAX A/C to

reduce fog potential.

Select these controls individually, together or with
Defrost to direct the air flow to the area you desire.

Manual airflow distri-
bution controls:

J

Distributes air through the instrument panel vents.

Panel:

Distributes air through the demister vents, floor vents
and rear seat floor vents.

Floor:

 (If Equipped)

PHONE

WARNING

Driving while distracted can result in
loss of vehicle control, crash and
injury. We strongly recommend that

you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Hands-free calling is one of the main
features of the system. Once you pair your
cell phone, you can access many options
using the touchscreen or voice commands.
While the system supports a variety of
features, many are dependent on your cell
phone’s functionality.

Pairing Your Cell Phone for the
First Time

Pair your Bluetooth-enabled phone with
the system before using the functions in
hands-free mode.

Switch on Bluetooth on your device to
begin pairing.  See your phone’s manual if
necessary.

To add a phone, select:

Menu Item

Add Phone

1.

Follow the on-screen instructions.

2. A prompt alerts you to search for the

system on your phone.

3. Select your vehicle's make and model

as it displays on your phone.

4. Confirm that the six-digit number

appearing on your phone matches the
six-digit number on the touchscreen.

5. The touchscreen indicates when the

pairing is successful.

6. Your phone may prompt you to give

the system permission to access
information. To check your phone’s
compatibility, see your phone’s manual
or visit the website.

Alternatively, to add a phone, select:

Menu Item

Add Phone

Then select:

Discover Other Bluetooth Devices

1.

Follow the on-screen instructions.

2. Select your phone's name when it

appears on the touchscreen.

3. Confirm that the six-digit number

appearing on your phone matches the
six-digit number on the touchscreen.

4. The touchscreen indicates when the

pairing is successful.

5. Your phone may prompt you to give

the system permission to access
information. To check your phone’s
compatibility, see your phone’s manual
or visit the website.

At a minimum, most cell phones with
Bluetooth wireless technology support the
following functions:
•

Answering an incoming call.

•

Ending a call.

•

Dialing a number.

•

Call waiting notification.

•

Caller identification.

 (If Equipped)

Other features, such as text messaging
using Bluetooth and automatic phonebook
download, are phone-dependent features.

To check your phone’s compatibility,
see your phone’s manual or visit the
website:

Websites

owner.ford.com

Websites

www.syncmyride.ca

www.syncmaroute.ca

Phone Menu

This menu becomes available after pairing
a phone.

E205447

Action and Description

Menu Item

Item

Displays your recent calls.

Recent Call
List

A

You can place a call by selecting an entry from this list.

 (If Equipped)
