Ford Mustang (2018 year). Manual - part 71

Drivebelt Routing

E198573

MOTORCRAFT PARTS - 2.3L ECOBOOST™

Part Number

Component

FA-1918

Air filter element.

FL-910-S

Oil filter.

BXT-96R-590

Battery.

SP-537

Spark plugs.

FT-188

Transmission filter

FP-78

Cabin air filter.

WW-1964 (passenger side)

Windshield wiper blade.

WW-2160 (driver side)

We recommend Motorcraft replacement parts available at your Ford dealer or at
fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor
Company’s specifications and are engineered for your vehicle. Use of other parts may
impact vehicle performance, emissions and durability. Your warranty may be void for any
damage related to use of other parts.

If a Motorcraft oil filter is not available, use an oil filter that meets industry performance
specification SAE/USCAR-36.

For spark plug replacement, contact an authorized dealer. Replace the spark plugs at the
appropriate intervals.  See Scheduled Maintenance (page 433).

MOTORCRAFT PARTS - 5.0L

Part Number

Component

FA-1918

Air filter element.

FL-500-S

Oil filter.

BXT-96R-590

Battery.

SP-548

Spark plugs.

FT-188

Transmission filter.

FP-78

Cabin air filter.

WW-1964 (passenger side)

Windshield wiper blade.

WW-2160 (driver side)

We recommend Motorcraft replacement parts available at your Ford dealer or at
fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor
Company’s specifications and are engineered for your vehicle. Use of other parts may
impact vehicle performance, emissions and durability. Your warranty may be void for any
damage related to use of other parts.

If a Motorcraft oil filter is not available, use an oil filter that meets industry performance
specification SAE/USCAR-36.

For spark plug replacement, contact an authorized dealer. Replace the spark plugs at the
appropriate intervals.  See Scheduled Maintenance (page 433).

VEHICLE IDENTIFICATION
NUMBER

The vehicle identification number is
located on the left-hand side of the
instrument panel.

E142476

Please note that in the graphic, XXXX is
representative of your vehicle identification
number.

The Vehicle Identification Number contains
the following information:

E142477

World manufacturer identifier

A

Brake system, Gross Vehicle
Weight Rating, Restraint Devices
and their locations

B

Make, vehicle line, series, body
type

C

Engine type

D

Check digit

E

Model year

F

Assembly plant

G

Production sequence number

H

VEHICLE CERTIFICATION
LABEL

E167469

The National Highway Traffic Safety
Administration Regulations require that a
Safety Compliance Certification Label be
affixed to a vehicle and prescribe where
the Safety Compliance Certification Label
may be located. The Safety Compliance
Certification Label shall be affixed to either
the door hinge pillar, the door latch post,
or the edge of the door near the door latch,
next to the driver's seating position.

TRANSMISSION CODE
DESIGNATION

E167814

The transmission code is on the Safety
Compliance Certification Label.  The
following table shows the transmission
code along with the transmission
description.

Code

Description

U

Ten-speed automatic transmission 10R80

X

Six-speed manual transmission MT82
