Ford Low Cab Forward (Ford year). Manual - part 6

AUDIO SYSTEMS

AM/FM Stereo (if equipped)

Driving while distracted can result in loss of vehicle control,
accident and injury. Ford strongly recommends that drivers use

extreme caution when using any device that may take their focus off
the road. The drivers primary responsibility is the safe operation of
their vehicle. Only use cell phones and other devices not essential to
the driving task when it is safe to do so.

1. ON/AUDIO: Press to turn the
radio on/off and turn to adjust the
volume.

2. PWR: Press to turn the radio on
and off.

3. BAND: Press to alternate
between AM, FM1, FM2 and
Weatherband.

Entertainment Systems

4. DSPL TM SET: Press to display
the time or to set the clock.

To set the clock:
• Turn the ignition on.
• Press and hold the DSPL TM SET button until the hours digits flash,

then press either the TUNE or SEEK buttons to set the hour.

• Press the DSPL TM SET button again and the minutes digits will flash.

Press either the TUNE or SEEK buttons to set the minutes.

• After five seconds, the display will show the time.
5. AUTO: Press to automatically set
the strongest stations to presets.

6. DIM: Press to adjust the
brightness of the radio display.

7. SCAN: Press to search the
current band for all listenable
stations. Press again to stop the
scan.

8. Memory preset buttons (1–6):
To set a station: Select frequency
band AM/FM; tune to a station,
press and hold a preset button until
sound returns.

For the TUNE and SEEK buttons, press and hold both TUNE and BAND
for two seconds to switch between manual tune and seek modes. The
display will show either “MANUAL” or “SEEK” to indicate the mode.

9. TUNE: Press to manually change
radio frequency up or down.

10. SEEK: Press to find the next
strong station up or down the
frequency band.

Entertainment Systems

AM/FM Stereo/CD (if equipped)

Driving while distracted can result in loss of vehicle control,
accident and injury. Ford strongly recommends that drivers use

1. BAND:
In radio mode, press to change the
band (AM/FM1/FM2/WB).
In CD/MP3 mode: press to pause and play a track/file.

2. SRC: Turns radio power on and
off. To turn power off, press and
hold for more than one second.
Press to change the listening source (Radio, XM/Sirius receiver [if
equipped], CD/MP3 player [if CD/MP3 disc is loaded] or CD changer [if
equipped]).

Entertainment Systems

3. DISP: Press to switch between
Radio/CD/MP3/Clock display.
In CD mode, pressing DISP will
display the disc title and track title.

To set the clock: Press and hold
DISP for more than two seconds;
the hours will flash to indicate time
setting mode is activated.

Press

to set the hour ahead/back. Press DISP; the minutes will

flash to indicate time setting mode is activated. Press

to set

the minutes ahead/back. Press DISP to end the time setting adjustment.

Note: Press and hold

to change the numbers rapidly.

TUNE/SEEK

In radio mode: Press to
manually go up or down the radio
frequency. Hold down for more
than

⁄

second to find the

next/previous strongest broadcast
station.

In CD/MP3 mode: Skip to the next/previous track/file. Hold down for
more than

⁄

second to fast reverse/fast forward.

5. Radio preset stations 1–6:
Press BAND to select the desired
frequency band.

Manual preset: Press

TUNE/SEEK

to manually find a station

to be stored, then press and hold one of the preset station buttons until
the display blinks once.
Auto Preset Memory (APM): Press and hold BAND for more than two
seconds. The six strongest stations will be stored in presets 1–6. The
presets will then be scanned for five seconds each. Press BAND again to
stop the scan.
Tuning in a Weather Band (WB) station: Press BAND to select WB,
then press any of the memory presets to monitor that preset station.

FOLDER/DISC

: Select

the next/previous folder on an MP3
disc or the next CD track on a disc.

Entertainment Systems
