Transmission clutch fluid temperature
must be in the normal operating
temperature range.

•

No powertrain or brake system warning
indicators are active.

Launch Control remains active until:
•

You switch the feature off through the
display screen.

•

Your vehicle no longer meets the
conditions required for launch control
to operate.

Using Launch Control

To use Launch Control:
•

Activate the launch control feature
through the display screen. See
General Information (page 70).

•

When activated, the LC icon appears
in white inside the information cluster.

•

With your vehicle at a complete stop,
hold the brake pedal firmly and press
the accelerator pedal to wide open
throttle.

•

When the engine reaches the required
RPM and your vehicle meets all other
system requirements, the LC icon turns
from white to green and the vehicle is
ready to launch.

•

Quickly release the brake pedal and
carefully steer your vehicle when it
accelerates from a stop. The launch
control feature controls wheel spin as
you accelerate.

•

After completing the run and stopping,
the LC icon returns to white.

•

If any operating conditions are not
within specification, the LC icon turns
grey with a strikethrough.

•

You can switch launch control off
through the display screen. See
General Information (page 70).

REAR VIEW CAMERA

WARNINGS

The rear view camera system is a
reverse aid supplement device that
still requires the driver to use it in

conjunction with the interior and exterior
mirrors for maximum coverage.

Objects that are close to either
corner of the bumper or under the
bumper, might not be seen on the

screen due to the limited coverage of the
camera system.

Use caution when turning camera
features on or off when the
transmission is not in park (P). Make

sure your vehicle is not moving.

The rear view camera system provides a
video image of the area behind your
vehicle.

During operation, lines appear in the
display which represent your vehicle’s
proximity to objects behind your vehicle.

E236446

The camera is located below the license
plate.

Using the Rear View Camera
System

The rear view camera system displays
what is behind your vehicle when you place
the transmission in reverse (R).

The system uses fixed guidelines to help
you see what is behind your vehicle. Fixed
guidelines show the path your vehicle is
moving while reversing in a straight line.
This can be helpful when backing into a
parking space.

The camera may not operate correctly
under the following conditions:
•

Nighttime or dark areas if the reverse
lamps are not operating.

•

Mud, water or debris obstructs the
camera's view.  Clean the lens with a
soft, lint-free cloth and non-abrasive
cleaner.

•

The camera is misaligned due to
damage to the rear of your vehicle.

Camera Guidelines

Note: Fixed guidelines are only available
when the transmission is in reverse (R).

E243771

Centerline

A

Fixed guideline: Red Zone

B

Fixed guideline: Yellow zone

C

Fixed guideline: Green zone

D

Always use caution while reversing.
Objects in the red zone are closest to your
vehicle and objects in the green zone are
farther away. Objects are getting closer to
your vehicle as they move from the green
zone to the yellow or red zones. Use the
side view mirrors and rear view mirror to
get better coverage on both sides and rear
of the vehicle.

Manual Zoom

WARNING

When manual zoom is on, the full
area behind your vehicle may not
show. Be aware of your surroundings

when using the manual zoom feature.

Note: Manual zoom is only available when
the transmission is in reverse (R).

Selectable settings for this feature are
Zoom in (+) and Zoom out (-). Press the
symbol in the camera screen to change the
view. The default setting is Zoom OFF.

This feature allows you to get a closer view
of an object behind your vehicle. The zoom
is only active while the transmission is in
reverse (R). When the transmission shifts
out of reverse (R), the feature
automatically turns off and must be reset
when it is used again.

Rear Camera Delay

You can select to have the rear camera
continue to display after shifting from
reverse (R).  See Settings (page 248).

PRINCIPLE OF OPERATION

Cruise control lets you maintain a set
speed without keeping your foot on the
accelerator pedal. You can use cruise
control when your vehicle speed is greater
than 20 mph (30 km/h).

USING CRUISE CONTROL

WARNINGS

Do not use cruise control on winding
roads, in heavy traffic or when the
road surface is slippery. This could

result in loss of vehicle control, serious
injury or death.

When you are going downhill, your
vehicle speed could increase above
the set speed. The system does not

apply the brakes.

Note: Cruise control disengages if the
vehicle speed decreases more than 10 mph
(16 km/h) below the set speed when driving
uphill.

E227119

The cruise controls are on the steering
wheel.

Switching Cruise Control On

Press ON.

E71340

The indicator appears in the
information display.

Setting the Cruise Speed

1.

Drive to desired speed.

2. Toggle SET+ or SET-.

3. Take your foot off the accelerator

pedal.

Note: The indicator changes color.

Changing the Set Speed

Note:  If you accelerate by pressing the
accelerator pedal, the set speed will not
change.  When you release the accelerator
pedal, your vehicle returns to the speed that
you previously set.

•

Toggle SET+ or SET- to change the set
speed in small increments.

•

Press the accelerator or brake pedal
until you reach the desired speed.
Toggle SET+ or SET-.

•

Toggle and hold SET+ or SET-. Release
the control when you reach the desired
speed.

Canceling the Set Speed

Press CAN or tap the brake pedal.  The set
speed does not erase.

Resuming the Set Speed

Press RES.

Switching Cruise Control Off

Note: You erase the set speed when you
switch the system off.

Press OFF when the system is in standby
mode, or switch the ignition off.
