Ford GT (2018 year). Manual - part 10

Competition Series

E252158

The competition series intelligent access
key does not have a hatch release button
or a removable key. In addition to the
competition series intelligent access key,
a provided separate key unlocks the
competition series hatch.

Using the Key Blade

Intelligent Access Key

A manual driver door release is located in
the engine compartment.

To access the door release:

E229693

1.

Open the rear hatch using the key
blade.

E229694

2. Pull the release located on the left side

of the storage box under the rear hatch.

Competition Series

1.

Unlock rear hatch using your key.

E251577

2. Push the button to release the handle.

E251578

3. Pull the handle up until you feel a click.

4. Push down on the hatch until you feel

a click.

E251630

5. Lift the hatch and remove the

two-piece prop rod from the storage
area.

E251629

6. Assemble the prop rod and use it to

prop open rear hatch.

E229694

7.

Pull the release located on the left side
of the storage box under the rear hatch.

Replacing the Battery

Note: Refer to local regulations when
disposing of transmitter batteries.

Note: Do not wipe off any grease on the
battery terminals or on the back surface of
the circuit board.

Note:  Replacing the battery will not delete
the transmitter from the vehicle.  The
transmitter should operate normally.

A message will appear in the information
display when the remote control battery
is low.  See Information Messages (page
73).

Intelligent Access Transmitter

The remote control uses one coin-type
three-volt lithium battery CR2032 or
equivalent.

E234661

1.

Push the release button and pull the
key blade out.

E234660

2. Twist a thin coin under the tab hidden

behind the key blade head to remove
the battery cover.

E218402

3. Insert a suitable tool, for example a

screwdriver, in the position shown and
carefully remove the battery.

4. Install a new battery with the + facing

upward.

5. Reinstall the battery cover and the key

blade.

Car Finder

E138623

Press the button twice within
three seconds.  The horn sounds
and the turn signals flash.  We

recommend you use this method to locate
your vehicle, rather than using the panic
alarm.

Sounding a Panic Alarm

Note: The panic alarm will only operate
when the ignition is off.

E138624

Press the button to activate the
alarm.  Press the button again or
switch the ignition on to

deactivate.

REPLACING A LOST KEY OR
REMOTE CONTROL
