E145780

3. Press the bulb in and turn the bulb

counterclockwise to remove it.

License Plate Lamp

3

2

1

E72789

1.

Use a suitable tool, for example a
screwdriver, to carefully remove the
lamp.

2. Remove the lamp.

3. Turn the bulb holder counterclockwise

and remove it.

4. Remove the bulb by pulling it straight

out.

BULB SPECIFICATION CHART

Replacement bulbs are specified in the
chart below. Headlamp bulbs must be
marked with an authorized “D.O.T.” for
North America to make sure they have the
proper lamp performance, light brightness,
light pattern, and safe visibility. The correct
bulbs will not damage the lamp assembly
or void the lamp assembly warranty and
will provide quality bulb illumination time.

Trade name

Function

H7LL

*Headlamp high beam (Halogen)

H11LL

*Headlamp low beam (Halogen)

LED

*Side marker lamp - front

W5W

*Park lamp - front

PWY24W

*Turn lamp - front

H11

*Fog lamp - front

LED

*Tail and brake lamp - high series

LED

*Tail and brake lamp - low series

921

Reverse lamp

Trade name

Function

LED

*Turn lamp - rear - high series

LED

*Turn lamp - rear - low series

LED

*Side marker lamp - rear

W5W

License plate lamp

W5W or LED**

*Trunk lamp

LED

*High-mount brake lamp

LED

*Side repeater lamp

LED

*Interior lamp

*To replace these bulbs, see your authorized dealer.

To replace all instrument panel bulbs, see your authorized dealer.

**If so equipped.

CHANGING THE ENGINE AIR
FILTER

WARNING

To reduce the risk of vehicle damage
and/or personal burn injuries do not
start your engine with the air cleaner

removed and do not remove it while the
engine is running.

When changing the air filter element, use
only the air filter element listed.  See
Capacities and Specifications (page
305).

Change the air filter element at the proper
interval.  See Scheduled Maintenance
(page 467).

Note: Failure to use the correct air filter
element may result in severe engine
damage. The customer warranty may be
void for any damage to the engine if the
correct air filter element is not used.

E146048

1.

Loosen the 5 bolts on the air cleaner
cover.

2. Remove the air cleaner cover.
3. Remove the engine air filter element

from the engine air cleaner assembly.

4. Wipe any dirt or debris from the air filter

housing and cover to make sure no dirt
gets in the engine and to make sure you
have a good seal.

5. Install the new engine air filter element

to the engine air cleaner assembly.

6. Install the air cleaner cover.
7.

Tighten the 5 bolts to the air cleaner
cover.

GENERAL INFORMATION

Your dealer has many quality products
available to clean your vehicle and protect
its finishes.

CLEANING PRODUCTS

Materials

For best results, use the following products
or products of equivalent quality:

Specification

Name

Motorcraft® Bug and Tar Remover ZC-42 (U.S. & Canada)

Motorcraft® Custom Bright Metal Cleaner ZC-15 (U.S. & Canada)

ESR-M14P4-A

Motorcraft® Detail Wash ZC-3-A (U.S. & Canada)

Motorcraft® Engine Shampoo and Degreaser ZC-20 (U.S.)

Motorcraft® Engine Shampoo CXC-66-A (Canada)

Motorcraft® Leather and Vinyl Cleaner ZC-56 (U.S. & Canada)

Motorcraft® Multi-Purpose Cleaner CXC-101 (Canada)

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with Bitterant
ZC-32-B2 (U.S.)

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with Bitterant
CXC-37-A/B/D/F (Canada)

Motorcraft® Professional Strength Carpet & Upholstery Cleaner
ZC-54 (U.S. & Canada)

ESR-M14P5-A

Motorcraft® Premium Glass Cleaner CXC-100 (Canada)

Motorcraft® Spot and Stain Remover ZC-14 (U.S.)

ESR-M14P5-A

Motorcraft® Ultra-Clear Spray Glass Cleaner ZC-23 (U.S.)

Motorcraft® Wheel and Tire Cleaner ZC-37-A (U.S. & Canada)

CLEANING THE EXTERIOR

Wash your vehicle regularly with cool or
lukewarm water and a neutral pH
shampoo, we recommend Motorcraft
Detail Wash.

•

Never use strong household detergents
or soap, for example dish washing or
laundry liquid. These products can
discolor and spot painted surfaces.

•

Never wash your vehicle when it is hot
to the touch, or during strong or direct
sunlight.

•

Dry your vehicle with a chamois or soft
terry cloth towel to eliminate water
spotting.
