For Energi vehicles, you can switch on ECO
Cruise using the information display.

For Hybrid vehicles, press ECO on the
center console.

For additional information, refer to ECO
Cruise and EcoSelect.

DRIVER ALERT

 (If Equipped)

PRINCIPLE OF OPERATION

WARNINGS

The system is designed to aid the
driver. It is not intended to replace
your attention and judgment. You are

still responsible to drive with due care and
attention.

At all times, you are responsible for
controlling your vehicle, supervising
the system and intervening, if

required. Failure to take care may result in
the loss of control of your vehicle, serious
personal injury or death.

The system may not function if the
sensor is blocked.

Take regular rest breaks if you feel
tired. Do not wait for the system to
warn you.

Certain driving styles may result in
the system warning you even if you
are not feeling tired.

In cold and severe weather
conditions the system may not
function. Rain, snow and spray can

all limit sensor performance.

The system will not operate if the
sensor cannot track the road lane
markings.

If damage occurs in the immediate
area surrounding the sensor, have
your vehicle checked as soon as

possible.

The system may not correctly
operate if your vehicle is fitted with
a suspension kit not approved by us.

The sensor is near the rear view mirror.

Note: Keep the windshield free from
obstructions for example bird droppings,
insects and snow or ice.

Note: If the camera is blocked or if the
windshield is damaged, the system may not
function.

Note: The system will store the on or off
setting in the information display menu
through ignition cycles.

Note: If enabled in the menu, the system
will be active at speeds above 40 mph
(64 km/h). When below the activation
speed, the information display will inform
the driver that the system is unavailable.

The system automatically monitors your
driving behavior using various inputs
including the front camera sensor.

If the system detects that your driving
alertness is reduced below a certain
threshold, the system will alert you using
a chime and a message in the cluster
display.

USING DRIVER ALERT

Switching the System On and Off

Switch the system on or off using the
information display.  See General
Information (page 97).

When activated, the system will monitor
your alertness level based upon your
driving behavior in relation to the lane
markings, and other factors.

System Warnings

Note: The system will not issue warnings
below approximately 40 mph (64 km/h).

The warning system has two stages. At
first, the system issues a temporary
warning that you need to take a rest. This
message will only appear for a short time.
If the system detects further reduction in
driving alertness, it may issue another
warning that will remain in the information
display for a longer time. You can press OK
on the steering wheel control to clear the
warning.

System Display

When active the system will run
automatically in the background and only
issue a warning if required. You can view
the status at any time using the
information display. See General
Information (page 97).

The alertness level is shown by six steps
in a colored bar.

E131358

The current assessment of your alertness
is within a typical range.

E131359

The current assessment of your alertness
indicates that you should rest as soon as
safely possible.

The status bar will travel from left to right
as the calculated alertness level
decreases. As the rest icon is approached
the color turns from green to yellow to red.

The yellow position indicates the first
warning is active and the red position
indicates the second warning is active.

Note: If you have recently received a
warning; you should consider resting, even
if the current assessment is within the
typical range.

Note: If the camera sensor cannot track the
road lane markings or if your vehicle speed
drops below approximately 40 mph
(64 km/h), the alertness level will change
to grey for a short time and the information
display will inform you that the system is
unavailable.

Resetting the System

You can reset the system by either:

•

Switching the ignition off and on.

•

Stopping the vehicle and then opening
and closing the driver’s door.

LANE KEEPING SYSTEM

 (If

Equipped)

WARNINGS

The system is designed to aid the
driver. It is not intended to replace
your attention and judgment. You are

still responsible to drive with due care and
attention.

Always drive with due care and
attention when using and operating
the controls and features on your

vehicle.

At all times, you are responsible for
controlling your vehicle, supervising
the system and intervening, if

required. Failure to take care may result in
the loss of control of your vehicle, serious
personal injury or death.

In cold and severe weather
conditions the system may not
function. Rain, snow and spray can

all limit sensor performance.

The system will not operate if the
sensor cannot track the road lane
markings.

WARNINGS

The sensor may incorrectly track lane
markings as other structures or
objects. This can result in a false or

missed warning.

Large contrasts in outside lighting
can limit sensor performance.

The system may not operate
properly if the sensor is blocked.
Keep the windshield free from

obstruction.

If damage occurs in the immediate
area surrounding the sensor, have
your vehicle checked as soon as

possible.

Note: The system works above 40 mph
(64 km/h).

Note: The system works as long as the
camera can detect one lane marking.

Note: The system may not function if the
camera is blocked or there is damage to the
windshield.

Note: When Aid mode is on and the system
detects no steering activity for a short
period, the system will alert you to put your
hands on the steering wheel. The system
may detect a light grip or touch on the
steering wheel as hands off driving.

E249505

The system notifies you to stay in your lane
through the steering system and the
instrument cluster display when the front
camera detects an unintentional drift out
of your lane is likely to occur. The system
automatically detects and tracks the road
lane markings using a camera mounted
behind the interior rear view mirror.

Switching the System On and Off

Note: The system on or off setting is stored
until it is manually changed, unless a MyKey
is detected. If the system detects a MyKey
it defaults to on and the mode is set to Alert.

E144813

Press the button on the steering
wheel stalk to switch the system
on or off.

System Settings

The system has optional setting menus
available. The system stores the
last-known selection for each of these
settings. You do not need to readjust your
settings each time you turn on the system.

Mode: This setting allows you to select
which of the system features you can
enable.

E165515

Alert only – Provides a steering wheel
vibration when the system detects an
unintended lane departure.
