Settings

Auto or Last
Settings

Heater – A/C

Climate Control

Remote Start

Auto Heated or
Off

Steering Wheel

Auto or Off

Front Defrost

Auto or Off

Rear Defrost

Auto or Off

Driver Seat

Auto or Off

Passenger Seat

5, 10 or 15 minutes

Duration

On or Off

Quiet Start

Enable or Disable

System

On or Off

Switch Inhibit

Select number of years

Tire Mobility
Kit

On or Off

Remote Open

Windows

On or Off

Remote Close

On or Off

Courtesy Wipe

Wipers

On or Off

Rain Sensing

Hold OK to Create MyKey

Create MyKey

MyKey

Always On or User Selectable

911 Assist

Always On or User Selectable

Advancetrac

Choose desired speed or off

Max Speed

Choose desired speed or off

Speed Minder

On or Off

Volume
Limiter

Always On or User Selectable

Do Not
Disturb

Hold OK to Clear All MyKeys

Clear MyKeys

Select the desired language - Hold OK to Set

Language

Display

Settings

Miles & GAL, l/100km or km/L

Distance

Units

Fahrenheit (°F) or Celsius (°C)

Temperature

psi, kPa or bar

Tire Pressure

On or Off

Brake Coach

On or Off

Battery
Display

On or Off

Regen Display

Hold OK to Reset

Driving History

*

Energi only.

Right Information Display Controls

E179396

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

•

Press the OK button to choose and
confirm your selection.

Main menu

From the main menu bar on the right side
of the information display, you can choose
from the following categories:

Entertainment

See General Information (page 366).

Phone

See General Information (page 366).

Navigation or Compass

See General Information (page 366).

Fuel Economy

Use the up or down arrow buttons to
choose between the following display
options.

Note: The information display will remember the menu level 2 state when you change the
individual key state from the RUN to the OFF position.

Fuel Economy

Menu level 5

Menu level 4

Menu level 3

Menu level 2

—

—

Help

Efficiency Leaves

—

5, 10 or 30 minutes

Duration

Fuel History

(Instantaneous Fuel

Economy + Fuel

Economy History + Avg

Fuel Economy)

—

—

Help

—

—

Help

Coach

Efficiency Leaves

Efficiency leaves indicate short term driving
efficiency measured over the last few
minutes. The more leaves and vines that
appear on the display, the better your fuel
economy. Leaves and vines will
occasionally appear and disappear to
indicate a change in your driving efficiency.

Fuel History

From left to right this view includes an
instantaneous fuel economy gauge,
historical fuel economy data and average
fuel economy. The historical data
represents an average over time intervals
of either 1, 2 or 6 minutes, with the leftmost
interval being the most recent. Shown at
the bottom of the view is the total time
duration for the 5 intervals. You can select
total duration in the options menu.
Intervals shown in grey color are from the
previous drive. The blue horizontal line
represents the average fuel economy value
shown to the right.

Note: Hold OK to reset fuel history and
average fuel economy.

Coach

This view provides a comparison of your
recent acceleration, braking and cruising
behavior, then recommends the most
efficient use of energy under present
conditions. The horizontal bars fill from left
to right with best behavior and appear blue
when at least half full. When the bars are
less than half full, the color is amber,
suggesting that you need a change in your
driving behavior to achieve better energy
efficiency.

Note: Fuel Economy will be impacted by
your use of brakes, accelerator and
accessories, as well as environmental
conditions such as hills and weather.

Note: Fuel economy is not always a
measure of appropriate driving behavior. For
example, when driving uphill and
maintaining an appropriate speed, your
instant fuel economy may not be good
(losing leaves) but the Coach may show a
blue bar for Acceleration and Cruising.

Common Displays

Both Average fuel economy and an
instantaneous fuel economy gauge are
included in Engage, Empower, MyView (if
selected) and Fuel Economy (shown in
Hybrid Mode) on the left-hand information
display. They are also included in Fuel
History on the right-hand information
display.

Average Fuel Economy

Average Fuel Economy is continuously
averaged since the last reset. You can reset
your average fuel economy by pressing and
holding the OK button on the
corresponding steering wheel controls. For
Energi vehicles both Hybrid and Plug-in
Power mode operation will be included in
the calculation.

Note: Average fuel economy cannot be
reset in MyView.

Instantaneous Fuel Economy

If your instantaneous fuel economy is
greater than the maximum value
displayed, a + sign will be shown next to
the maximum scale number. When your
vehicle is operating on battery power only,
EV will display and the gauge fill will show
in blue.

INFORMATION MESSAGES

Note:  Depending on your vehicle options
and instrument cluster type, not all of the
messages will display or be available.
Certain messages may be abbreviated or
shortened depending upon which cluster
type you have.

E144636

Press the OK button to acknowledge and
remove some messages from the
information display. Other messages will
be removed automatically after a short
time.

Certain messages need to be confirmed
before you can access the menus.

Active Park

Action

Message

The system requires service due to a malfunction. Have the

system checked by an authorized dealer.

Active Park Fault
