Ford Fusion Hybrid (2014 year). Manual - part 94

"CD"

"Pause"

"Play"

"Play next track"

"Play previous track"

"Play track <1-512>"

"Repeat"

"Repeat folder"

*

"Repeat off"

"Repeat track"

"Shuffle"

"Shuffle CD"

*

"Shuffle folder"

*

"Shuffle off"

"Help"

*

This applies to WMA or MP3 files only.

SD Card Slot and USB Port

SD Card

Note: Your SD card slot is spring-loaded.
To remove the SD card, press the card in
and the system ejects it. Do not attempt to
pull the card to remove it as this could cause
damage.

Note: The navigation system also uses this
card slot.  See Navigation (page 402).

E142619

The SD card slot is located either in the
center console or behind a small access
door in the instrument panel. To access
and play music from your device, press the
lower left corner of the touchscreen.

E142620

SD logo is a trademark of SD-3C, LLC.

USB Port

E142621

The USB ports are located either in the
center console or behind a small access
door in the instrument panel. To access
and play music from your device, press the
lower left corner of the touchscreen.

379

MyFord Touch™

 (If Equipped)

This feature allows you to plug in media
playing devices, memory sticks, flash drives
or thumb drives, and charge devices if they
support this feature.

In order to playback video from your iPod
or iPhone, you must have a special
combination USB/RCA composite video
cable (which you can buy from Apple).
When you connect the cable to your iPod
or iPhone, plug the other end into both the
RCA jacks and the USB port.

Playing Music from Your Device

E142611

Insert your device and select the
SD Card or USB tab once the
system recognizes it. You can

then select from the following options:

Repeat

This feature replays the currently playing
song or album.

Shuffle

Touch this button to play music on the
selected album or folder in random order.

Similar Music

This feature allows you to choose music
similar to what is currently playing.

More Info

Touch this button to see disc information
such as current track, artist name, album
and genre.

Options

Touch this button to view and adjust
various media settings.

Sound Settings allows you to adjust
settings for:

•

Bass

•

Midrange

•

Treble

•

Balance and Fade

•

DSP (Digital Signal processing)

•

Occupancy Mode

•

Speed Compensated Volume.

Note: Your vehicle may not have all these
sound settings.

Media Player Settings allows you to
select more settings, which is under Media
Player. See Settings (page 357).

Device Information displays software
and firmware information about the
currently connected media device.

Update Media Index indexes your device
when you connect it for the first time and
each time the content changes (such as
adding or removing tracks) to make sure
you have the latest voice commands
available for all media on the device.

Browse

This feature allows you to view the
contents of the device. It also allows you
to search by categories, such as genre,
artist or album.

If you want to view song information such
as Title, Artist, File, Folder, Album, and
Genre, touch the on-screen album art.

You can also touch What’s Playing to
hear how the system pronounces the
current band and song. This can be helpful
when using voice commands to make sure
the system correctly plays your request.

Playing Video from Your Device

To access and play video from your device,
your vehicle's transmission must be in
position P (vehicle equipped with an
automatic transmission) or neutral
(vehicle equipped with a manual
transmission) with the ignition in accessory
mode.  See Starting and Stopping the
Engine (page 134).

380

MyFord Touch™

 (If Equipped)

SD Card and USB Voice Commands

E142599

If you are listening to a USB
device or an SD card, press the
voice button on the steering

wheel controls. When prompted, say any
of the following commands.

If you are not listening to a USB device or
an SD card, press the voice button and,
after the tone, say "USB" or "SD card",
then any of the following commands.

"USB" or "SD CARD"

"Browse"

*

"Next"

"Pause"

"Play"

"Play album <name>"

"Play all"

"Play artist <name>"

"Play audiobook <name>"

"Play author <name>"

"Play composer <name>"

"Play folder <name>"

"Play genre <name>"

"Play movie <name>"

**

"Play music video <name>"

**

"Play playlist <name>"

"Play podcast <name>"

"Play podcast episode <name>"

"Play similar music"

"Play song <name>"

"USB" or "SD CARD"

"Play TV show <name>"

**

"Play TV show episode <name>"

**

"Play video <name>"

**

"Play video podcast <name>"

**

"Play video podcast episode <name>"

**

"Play video playlist <name>"

**

"Previous"

"Repeat all"

"Repeat off"

"Repeat one"

"Shuffle"

"Shuffle album"

"Shuffle off"

"What's this?"

"Help"

*

 If you have said you would like to browse

your USB or SD card, the system prompts
you to specify what you would like to
browse. When prompted, see the following
"Browse" chart.

**

 These commands are only available in

USB mode and are device-dependent.

"BROWSE"

"Album <name>"

"All albums"

"All artists"

"All audiobooks"

381

MyFord Touch™

 (If Equipped)

"BROWSE"

"All authors"

"All composers"

"All folders"

"All genres"

"All movies"

*

"All music videos"

*

"All playlists"

"All podcasts"

"All songs"

"All TV shows"

*

"All video playlists"

*

"All video podcasts"

*

"All videos"

*

"Artist <name>"

"Audiobook <name>"

"Author <name>"

"Composer <name>"

"Folder <name>"

"Genre <name>"

"Playlist <name>"

"Podcast <name>"

"TV show <name>"

*

"Video <name>"

*

"Video playlist <name>"

*

"BROWSE"

"Video podcast <name>"

*

"Help"

*

 This command is only available in USB

mode and is device-dependent.

Supported Media Players, Formats
and Metadata Information

SYNC is capable of hosting nearly any
digital media player, including iPod,
Zune™, plays from device players, and
most USB drives. Supported audio formats
include MP3, WMA, WAV and AAC.

It is also able to organize your indexed
media from your playing device by
metadata tags. Metadata tags, which are
descriptive software identifiers embedded
in the media files, provide information
about the file.

If your indexed media files contain no
information embedded in these metadata
tags, SYNC may classify the empty
metadata tags as Unknown.

In order to playback video from your iPod
or iPhone, you must have a special
combination USB/RCA composite video
cable (which you can buy from Apple).
When you connect the cable to your iPod
or iPhone, plug the other end into both the
RCA jacks and the USB port.

Bluetooth Audio

Your system allows you to stream audio
over your vehicle's speakers from your
connected, Bluetooth-enabled cellular
phone.

E142611

To access, press the lower left
corner on the touchscreen, then
select the BT Stereo tab.

382

MyFord Touch™

 (If Equipped)
