Ford Fusion Hybrid (2014 year). Manual - part 91

ENTERTAINMENT

E161892

AM 1 and AM AST

FM 1, FM 2 and FM AST

SIRIUS

USB

Touch this button to scroll down for more options, such as SD Card, BT Stereo
and A/V In

These buttons change with the media mode you are in.

Radio memory presets and CD controls.

Note: Some features may not be available
in your area. Contact an authorized dealer
for more information.

You can access these options using the
touchscreen or voice commands.

Browsing Device Content

When listening to audio on a device, you
can browse through other devices without
having to change sources. For example, if
you are currently listening to audio on an
SD card, you can browse all the artists that
are stored on your USB device.

E142599

Press the voice icon on the
steering wheel. When prompted,
you can say:

367

MyFord Touch™

(If Equipped)

"BROWSE" within devices

"Browse"

"Browse <league> games"

"Browse <Sirius category> channels"

"Browse SD card"

"Browse Sirius channel guide"

"Browse USB"

"Help"

If you only say, "Browse", you can then

say any commands in the following chart.

This command is only usable if you have

an active subscription to SIRIUS satellite
radio.

"BROWSE"

"<League> Games"

"<Sirius category> channels"

"SD card"

"Sirius Channel Guide"

"USB"

"Help"

This command is only usable if you have

an active subscription to SIRIUS satellite
radio.

For more commands in SD card or USB

mode, see the "SD Card and USB Port"
section of this chapter.

Your voice system allows you to change
audio sources with a simple voice
command. For example, if you are listening
to music on a USB device, then want to
switch to a satellite radio channel, simply
press the voice button on the steering
wheel controls and say the name of the
SIRIUS station (such as, "the Highway").
The following voice commands are
available at the top level of the voice
session no matter which current audio
source you are listening to (such as a USB
device or SIRIUS satellite radio).

Note: This is only available when your
MyFord Touch system language is set to
North American English.

Sample commands

"<87.7-107.9>"

"<530-1710>"

"<Channel name>"

"AM <530-1710>"

"FM <87.7-107.9>"

"Play [album] <name>"

"Play [artist] <name>"

"Play [genre] <name>"

"Play [playlist] <name>"

"Play [song] <name>"

"Play <name>"

"Play <name (song or album)> by <artist

name>"

368

MyFord Touch™

(If Equipped)

Sample commands

"Sirius <0-223>"

"Sports games"

This command is only usable if you have

an active subscription to SIRIUS satellite
radio.

The commands that have [ ] around the

word means that the word is optional. For
example, if you say, "Play Metallica", this
is the same as the voice command, "Play
[artist] <name>".

AM/FM Radio

E142611

Touch the AM or FM tab to listen
to the radio.

To change between AM and FM presets,
just touch the AM or FM tab.

Memory Presets

Save a station by pressing and holding one
of the memory preset areas. There is a brief
mute while the radio saves the station.
Sound returns when finished.

HD Radio

Touch this button to turn HD Radio on. The
light on the button illuminates when the
feature is on. HD Radio allows you to
receive radio broadcasts digitally, where
available, providing free, crystal-clear
sound. See HD Radio information later in
this chapter.

Scan

Touch this button to go to the next strong
AM or FM radio station. The light on the
button illuminates when the feature is on.

Options

Sound Settings

Touch this button to adjust settings for:

•

Bass

•

Midrange

•

Treble

•

Balance and Fade

•

DSP (Digital Signal processing)

•

Occupancy Mode

•

Speed Compensated Volume.

Note: Your vehicle may not have all these
sound settings.

Set PTY for Seek/Scan

This allows you to select a category of
music you would like to search for. You can
then choose to either seek or scan for the
stations playing that category.

RDS Text Display

This allows you to view the information
broadcast by FM stations.

AST

AST (Autostore) allows you to have the
system automatically store the six
strongest stations in your current location.

TAG Button

This feature is available when HD Radio is
on, and allows you to tag a song to
download later. When you select On, TAG
appears on-screen when HD Radio is
active. You can touch TAG to save the
information of the song that is playing.
When you plug in your portable music
player, the information transfers, if
supported by your device. When you are
connected to iTunes, the tags appear to
remind you of the songs you would like to
download. See HD Radio information later
in this chapter.

369

MyFord Touch™

(If Equipped)

Direct Tune

Touch this button to manually enter the
desired station number. Touch Enter when
you are done.

HD Radio™ Information (If Available)

Note: HD Radio broadcasts are not
available in all markets.

HD Radio technology is the digital
evolution of analog AM/FM radio. Your
system has a special receiver that allows
it to receive digital broadcasts (where
available) in addition to the analog
broadcasts, it already receives. Digital
broadcasts provide a better sound quality
than analog broadcasts with free,
crystal-clear audio and no static or
distortion. For more information, and a
guide to available stations and
programming, please visit
www.hdradio.com.

When HD Radio is on and you tune to a
station broadcasting HD Radio technology,
you may notice the following indicators on
your screen:

E142616

The HD Radio logo blinks when acquiring
a digital station and stays solid when
digital audio is playing. When this logo is
available, you may also see Title and Artist
fields on-screen.

The multicast indicator appears in FM
mode (only) if the current station is
broadcasting multiple digital broadcasts.
The highlighted numbers signify available
digital channels where new or different
content is available. HD1 signifies the main
programming status and is available in
analog and digital broadcasts. Other
multicast stations (HD2 through HD7) are
only available digitally.

TAG allows you to save a song to
download later when you are on an
acquired HD Radio station and the feature
is on. To turn the feature on and use it:

Press AM or FM > Options > TAG
Button > On.

2. When you hear a song you like, touch

TAG.

3. The system automatically saves the

song's information and transfers it to
your portable music player (if
supported) when you connect it to the
system. The system automatically
transfers the tag to your player (if
already connected) and a pop-up
confirms the transfer.

4. When you access iTunes with your

portable music player, the tags appear
to you as a reminder. The system
allows you to tag up to approximately
100 songs. For a list of devices that
support tagging, see
www.SYNCMyRide.com,
www.SYNCMyRide.ca or
www.syncmaroute.ca.

370

MyFord Touch™

(If Equipped)
