Ford Fusion Hybrid (2014 year). Manual - part 21

Settings

Traction Ctrl - check enabled or uncheck disabled

Driver Assist

Blind Spot - check enabled or uncheck disabled

Rear Park Aid - check enabled or uncheck disabled

Hill Start Assist - check enabled or uncheck disabled

Cross Traffic - check enabled or uncheck disabled

Auto Engine Off - check enabled or uncheck disabled

Vehicle

5, 10 or 30 minutes

Fuel History

Off or XX Seconds

Autolamp Delay

Lighting

Settings (cont’d)

Autolock - check enabled or uncheck disabled

Locks

Vehicle
(cont’d)

Autounlock - check enabled or uncheck disabled

Relock - check enabled or uncheck disabled

Mislock - check enabled or uncheck disabled

All Doors or Driver
First

Remote Unlock

Set to XXX %

Oil Life Rest

Switch Inhibit - check enabled or uncheck disabled

Remote Open or Remote Close

Windows

Courtesy Wipe or Rain Sensing

Wipers

Hold OK to Create MyKey

Create MyKey

MyKey

Always On or User Selectable

911 Assist

Always On or User Selectable

Traction
Control

Choose desired speed or Off

Max Speed

Choose desired speed or Off

Speed Minder

87

Information Displays

Settings (cont’d)

On or Off

Volume
Limiter

On or Off

Do Not
Disturb

Hold OK to Clear All MyKeys

Clear MyKeys

Choose your applicable setting

Language

Display

Choose your
applicable setting

Distance

Units

Choose your
applicable setting

Temperature

Information Display Controls
(Type 3)

E144638

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

•

Press and hold the left arrow button at
any time to return to the main menu
display (escape button).

•

Press the OK button to choose and
confirm settings or messages.

Main menu

From the main menu bar on the left side
of the information display, you can choose
from the following categories:

E144639

Display Mode

E138660

Trip 1 & 2

E144640

Fuel Economy

E144642

Information

E100023

Settings

Scroll up/down to highlight one of the
categories, then press the right arrow key
or OK to enter into that category. Press the
left arrow key as needed to exit back to the
main menu.

88

Information Displays

Display Mode

E144639

Use the up/down arrow buttons
to choose between the following
display options.

Option 4

Option 3

Option 2

Option 1

Display mode

-

-

X

X

XXX mi (km) to empty

X

X

X

X

Fuel gauge

X

X

-

-

Round tachometer

-

-

X

-

Vertical tachometer

X

-

-

-

Engine coolant temp gauge

•

XXX mi (km) to empty: Shows the approximate distance the vehicle will travel.

•

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank. The fuel
gauge may vary slightly when the vehicle is in motion or on a grade. When the fuel
level becomes low, the level indicator will change to amber. When the fuel level
becomes critically low, the level indicator will change to red. Note: When a MyKey®
is in use, low fuel warnings will display earlier. The fuel icon and arrow indicates which
side of the vehicle the fuel filler door is located.

•

Round tachometer: Indicates the engine speed in revolutions per minute. Driving with
your tachometer pointer continuously at the top of the scale may damage the engine.
During SelectShift Automatic™ transmission (SST) use, the currently selected gear
will appear in the display.

•

Engine coolant temperature gauge: Indicates engine coolant temperature. At normal
operating temperature, the level indicator will be in the normal range. If the engine
coolant temperature exceeds the normal range, stop the vehicle as soon as safely
possible, switch off the engine and let the engine cool.

Trip 1 & 2

E138660

Choose between the standard
or enhanced trip display.

Enhanced display

Standard display

Trip 1 & 2

X

X

Trip Odometer

X

X

Trip Timer

X

-

Average Fuel

89

Information Displays

Enhanced display

Standard display

Trip 1 & 2

X

-

Fuel Used

-

Press and hold OK to reset the currently
displayed trip information.

•

Trip Odometer — shows the accumulated trip distance.

•

Trip Timer— timer stops when the vehicle is turned off and restarts when the vehicle
is restarted.

•

Average Fuel — shows the average fuel economy for a given trip.

•

Fuel Used — shows the amount of fuel used for a given trip.

Fuel Economy

E144640

Use the left/right arrow buttons
to choose the desired fuel
economy display.

Option 2

Option 1

Fuel Economy

X

X

DTE

-

X

Inst Fuel Econ

X

X

Average Fuel

X

-

Fuel History

5, 10, or 30 minute

Fuel History Duration

•

DTE: Distance To Empty shows the approximate distance the vehicle will travel on
the fuel remaining in the tank. Changes in driving pattern may cause the value to vary.

•

Inst Fuel Econ: This display shows a visual graph of your instantaneous fuel economy.

•

Average Fuel: Indicates the average fuel consumption since the function was last
reset.

•

Fuel History: shows a bar chart of your fuel history.

•

Fuel History Duration: shows fuel usage over a 5, 10, or 30 minute time span.

Note: You can reset your average fuel
economy by pressing and holding the OK
button on the left hand steering wheel
controls.

Info

E144642

In this mode, you can view
different vehicle system
information and perform a

system check.
