Ford Fusion Hybrid (2014 year). Manual - part 14

Anti-Scan Feature

The keypad will go into an anti-scan mode
if you enter the wrong code seven times
(35 consecutive button presses). This
mode disables the keypad for one minute
and the keypad lamp will flash.

The anti-scan feature will turn off after:

•

one minute of keypad inactivity

•

pressing the unlock button on the
remote control

•

switching the ignition on

•

unlocking your vehicle using intelligent
access.

Unlocking and Locking the Doors

To Unlock the Driver Door

Enter the factory-set 5-digit code or your
personal code. You must press each
number within five seconds of each other.
The interior lamps will illuminate.

Note: All doors will unlock if you enable the
all-door unlocking mode. See Locking and
Unlocking (page 54).

To Unlock All Doors

Enter the factory-set code or your personal
code, then press 3·4 within five seconds.

To Lock All Doors

Press and hold 7·8 and 9·0 at the same
time (with the driver door closed). You do
not need to enter the keypad code first.

To Release the Trunk

Enter the factory-set code or your personal
code, then press 5·6 within five seconds.

Displaying the Factory Set Code

With Integrated Keyhead Transmitters

Note: You will need to have two
programmed passive anti-theft keys for this
procedure.

To display the factory-set code in the
information display:

Insert a key into the ignition and switch
the ignition on for a few seconds.

2. Switch the ignition off and remove the

key.

3. Insert the second key into the ignition

and switch the ignition on.

The factory-set code will display for a few
seconds.

Note: The code may not display until after
any other warning messages first display.

With Intelligent Access Keys

Note: You will need to have two
programmed intelligent access keys for this
procedure.

To display the factory-set code in the
information display:

E147165

Place the first programmed key in the
backup slot inside the center console.
The key ring must be at the top with
the buttons facing toward the rear.

2. Press the START/STOP button once

and wait a few seconds.

3. Press the START/STOP button again

and remove the key.

4. Insert the second programmed key into

the backup slot, then press the
START/STOP button.

Locks

The factory-set code will appear in the
information display for a few seconds.

Note: The code may not display until after
any other warning messages first display.

INTERIOR LUGGAGE
COMPARTMENT RELEASE

WARNINGS

Keep vehicle doors and luggage
compartment locked and keep keys
and remote transmitters out of a

child’s reach. Unsupervised children could
lock themselves in the trunk and risk injury.
Children should be taught not to play in
vehicles.

Do not leave children, unreliable
adults, or animals unattended in the
vehicle. On hot days, the

temperature in the trunk or vehicle interior
can rise very quickly. Exposure of people
or animals to these high temperatures for
even a short time can cause death or
serious heat-related injuries, including brain
damage. Small children are particularly at
risk.

Your vehicle is equipped with a release
handle that provides a means of escape
for children and adults if they become
locked inside the luggage compartment.

Adults should familiarize themselves with
the operation and location of the release
handle.

E144403

The handle is located inside the luggage
compartment either on the luggage
compartment door (lid) or near the tail
lamps. It is composed of a material that
will glow for hours in darkness following
brief exposure to ambient light.

Pull the handle and push up on the luggage
compartment door (lid) to open from
within the luggage compartment.

Locks

PASSIVE ANTI-THEFT
SYSTEM

Note: The system is not compatible with
non-Ford aftermarket remote start systems.
Use of these systems may result in vehicle
starting problems and a loss of security
protection.

Note: Metallic objects, electronic devices
or a second coded key on the same key
chain may cause vehicle starting problems
if they are too close to the key when starting
your vehicle. Prevent these objects from
touching the coded key while starting your
vehicle. Switch the ignition off, move all
objects on the key chain away from the
coded key and restart your vehicle if a
problem occurs.

Note: Do not leave a duplicate coded key
in your vehicle. Always take your keys and
lock all doors when leaving your vehicle.

SecuriLock®

The system helps prevent your vehicle
from starting unless you use a coded key
programmed to your vehicle. Using the
wrong key may prevent your vehicle from
starting. A message may appear in the
information display.

If you are unable to start your vehicle with
a correctly coded key, a malfunction has
happened. A message may appear in the
information display.

Automatic Arming

Your vehicle arms immediately after
switching the ignition off.

Automatic Disarming

Switching the ignition on with a coded key
disarms your vehicle.

Replacement Keys

Note: Your vehicle comes equipped with
two integrated keyhead transmitters or two
intelligent access keys.

The integrated keyhead transmitter
functions as a programmed ignition key
that operates all the locks and starts your
vehicle, as well as a remote control.

The intelligent access key functions as a
programmed key that operates the driver
door lock and activates the intelligent
access with push button start system, as
well as a remote control.

If your programmed transmitters or
standard SecuriLock coded keys
(integrated keyhead transmitters only) are
lost or stolen and you do not have an extra
coded key, you will need to have your
vehicle towed to an authorized dealer. You
need to erase the key codes from your
vehicle and program new coded keys.

Store an extra programmed key away from
your vehicle in a safe place to help prevent
any inconveniences. See your authorized
dealer to purchase additional spare or
replacement keys.

Programming a Spare Integrated
Keyhead Transmitter

Note: You can program a maximum of eight
coded keys to your vehicle. All eight can be
integrated keyhead transmitters.

You can program your own integrated
keyhead transmitter or standard
SecuriLock coded keys to your vehicle. This
procedure will program both the vehicle
immobilizer keycode and the remote entry
portion of the remote control to your
vehicle.

Only use integrated keyhead transmitters
or standard SecuriLock keys.

Security

You must have two previously
programmed coded keys and the new
unprogrammed key readily accessible. See
an authorized dealer to have the spare key
programmed if two previously
programmed coded keys are not available.

Read and understand the entire procedure
before you begin.

Insert the first previously programmed
coded key into the ignition.

2. Switch the ignition from off to on. Keep

the ignition on for at least three
seconds, but no more than 10 seconds.

3. Switch the ignition off and remove the

first coded key from the ignition.

4. After three seconds but within 10

seconds of switching the ignition off,
insert the second previously coded key
into the ignition.

5. Switch the ignition from off to on. Keep

the ignition on for at least three
seconds, but no more than 10 seconds.

6. Switch the ignition off and remove the

second previously programmed coded
key from the ignition.

After three seconds but within 10
seconds of switching the ignition off
and removing the previously
programmed coded key, insert the new
unprogrammed key into the ignition.

8. Switch the ignition from off to on. Keep

the ignition on for at least six seconds.

9. Remove the newly programmed coded

key from the ignition.

If the key has been successfully
programmed it will start your vehicle and
operate the remote entry system (if the
new key is an integrated keyhead
transmitter).

If programming was not successful, wait
10 seconds and repeat Steps 1 through 8.
If you are still unsuccessful, take your
vehicle to an authorized dealer.

Programming a Spare Intelligent
Access Key

Note: You can program a maximum for four
intelligent access keys to your vehicle.

You must have two previously
programmed intelligent access keys inside
your vehicle and the new unprogrammed
intelligent access keys readily accessible.
See an authorized dealer to have the spare
key programmed if two previously
programmed keys are not available.

Make sure that your vehicle is off before
beginning this procedure. Make sure that
you close all the doors before beginning
and that they remain closed throughout
the procedure. Perform all steps within 30
seconds of starting the sequence. Stop
and wait for at least one minute before
starting again if you perform any steps out
of sequence.

Read and understand the entire procedure
before you begin.

E147165

Place a programmed intelligent access
key in the backup slot in the center
console. The key ring must be at the
top with the buttons facing toward the
rear.

2. Wait 5 seconds, and then press the

START/STOP button.

3. Remove the intelligent access key.

Security
