Ford Fusion (2018 year). Manual - part 118

At Every Oil Change Interval as Indicated by the Information Display

1

Inspect the tires, tire wear and measure the tread depth.

Inspect the wheels and related components for abnormal noise, wear, looseness or
drag.

1

 Do not exceed one year or 10,000 mi (16,000 km) between service intervals.

2

 Reset the Intelligent Oil-Life Monitor after engine oil and filter changes.  See Oil Change

Indicator Reset (page 260).

Other Maintenance Items

1

Replace cabin air filter.

Every 20,000 mi
(32,000 km)

Replace engine air filter.

Every 30,000 mi
(48,000 km)

Change engine coolant.

2

At 100,000 mi
(160,000 km)

Replace spark plugs.

Every 100,000 mi
(160,000 km)

Inspect accessory drive belt(s).

3

Change automatic transmission fluid.

Every 150,000 mi
(240,000 km)

Replace accessory drive belt(s).

4

Replace timing belt (1.5L engine).

1

 Perform these maintenance items within 3,000 mi (4,800 km) of the last engine oil and

filter change. Do not exceed the designated distance for the interval.

2

 Initial replacement at six years or 100,000 mi (160,000 km), then every three years or

50,000 mi (80,000 km).

3

 After initial inspection, inspect every other oil change until replaced.

4

 If not replaced within the last 100,000 mi (160,000 km).

SPECIAL OPERATING
CONDITIONS SCHEDULED
MAINTENANCE

If you operate your vehicle primarily in any
of the following conditions, you need to
perform extra maintenance as indicated.
If you operate your vehicle occasionally
under any of these conditions, it is not
necessary to perform the extra
maintenance. For specific
recommendations, see your dealership
service advisor or technician.

Perform the services shown in the
following tables when specified or within
3,000 mi (4,800 km) of the message
appearing in the information display
prompting you to change your oil.

•

Example 1: The message comes on at
28,751 mi (46,270 km). Perform the
30,000 mi (48,000 km) automatic
transmission fluid replacement.

•

Example 2: The message has not
come on, but the odometer reads
30,000 mi (48,000 km) (for example,
the Intelligent Oil-Life Monitor was
reset at 25,000 mi (40,000 km)).
Perform the engine air filter
replacement.

Towing a Trailer or Using a Car-top Carrier

Change engine oil and filter as indicated by the information
display and perform services listed in the Normal Sched-
uled Maintenance chart.

As required

Inspect rear axle and U-joints (All-Wheel Drive only).

Inspect frequently, service
as required

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

Replace spark plugs.

Every 60,000 mi
(96,000 km)

Extensive Idling or Low-speed Driving for Long Distances, as in Heavy Commercial Use

(Such as Delivery, Taxi, Patrol Car or Livery)

Change engine oil and filter as indicated by the information
display and perform services listed in the Normal Sched-
uled Maintenance chart.

As required

Replace cabin air filter.

Inspect frequently, service
as required

Replace engine air filter.

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

Replace spark plugs.

Every 60,000 mi
(96,000 km)

Operating in Dusty or Sandy Conditions (Such as Unpaved or Dusty Roads)

Replace cabin air filter.

Inspect frequently, service
as required

Replace engine air filter.

Inspect the wheels and related components for abnormal
noise, wear, looseness or drag.

Every 5,000 mi (8,000 km)

Rotate tires, inspect tires for wear and measure tread
depth.

Change engine oil and filter.

*

Every 5,000 mi (8,000 km)
or six months

Perform multi-point inspection.

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

*

Reset your Intelligent Oil-Life Monitor after engine oil and filter changes.  See Oil Change

Indicator Reset (page 260).

Exceptions

There are several exceptions to the Normal
Schedule:

Rear Axle and PTU Maintenance

The Power Transfer Unit (PTU) and rear
axle (All-Wheel Drive only) in your vehicle
does not require any normal scheduled
maintenance, unless the vehicle has
experienced extended periods of extreme
or severe duty cycle driving or both PTU
and the axle has been submerged in water.
Checking the PTU and rear axle fluid is not
necessary unless the unit shows signs of
leakage. Contact an authorized dealer for
service.

California Fuel Filter Replacement

If you register your vehicle in California, the
California Air Resources Board has
determined that the failure to perform this
maintenance item does not nullify the
emission warranty or limit recall liability
before the completion of your vehicle's
useful life. Ford Motor Company, however,
urges you to have all recommended
maintenance services performed at the
specified intervals and to record all vehicle
service.

Hot Climate Oil Change Intervals

Vehicles operating in the Middle East,
North Africa, Sub-Saharan Africa or
locations with similar climates using an
American Petroleum Institute (API)
Certified for Gasoline Engines (Certification
mark) oil of SM or SN quality, the normal
oil change interval is 3,000 mi (4,800 km).

If the available API SM or SN oils are not
available, then the oil change interval is
1,800 mi (2,900 km).

Engine Air Filter and Cabin Air Filter
Replacement

The life of the engine air filter and cabin air
filter is dependent on exposure to dusty

and dirty conditions. Vehicles operated in
these conditions require frequent
inspection and replacement of the engine
air filter and cabin air filter.

SCHEDULED MAINTENANCE RECORD

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp
