PRINCIPLE OF OPERATION

Cruise control lets you maintain a set
speed without keeping your foot on the
accelerator pedal. You can use cruise
control when your vehicle speed is greater
than 20 mph (30 km/h).

USING CRUISE CONTROL

WARNINGS

Do not use cruise control on winding
roads, in heavy traffic or when the
road surface is slippery. This could

result in loss of vehicle control, serious
injury or death.

When you are going downhill, your
vehicle speed could increase above
the set speed. The system does not

apply the brakes.

Note: Cruise control disengages if the
vehicle speed decreases more than 10 mph
(16 km/h) below the set speed when driving
uphill.

E191246

The cruise controls are on the steering
wheel.

Switching Cruise Control On

Press ON.

E71340

The indicator appears in the
information display.

Setting the Cruise Speed

1.

Drive to desired speed.

2. Press SET+ or SET-.

3. Take your foot off the accelerator

pedal.

Note: The indicator changes color.

Changing the Set Speed

Note:  If you accelerate by pressing the
accelerator pedal, the set speed will not
change.  When you release the accelerator
pedal, your vehicle returns to the speed that
you previously set.

•

Press SET+ or SET- to change the set
speed in small increments.

•

Press the accelerator or brake pedal
until you reach the desired speed. Press
SET+ or SET-.

•

Press and hold SET+ or SET-. Release
the control when you reach the desired
speed.

Canceling the Set Speed

Press CNCL or tap the brake pedal.  The
set speed does not erase.

Resuming the Set Speed

Press RES.

Switching Cruise Control Off

Note: You erase the set speed when you
switch the system off.

Press OFF when the system is in standby
mode, or switch the ignition off.

USING ADAPTIVE CRUISE
CONTROL

 (If Equipped)

WARNINGS

Always pay close attention to
changing road conditions when using
adaptive cruise control. The system

does not replace attentive driving. Failing
to pay attention to the road may result in
a crash, serious injury or death.

Do not use the adaptive cruise
control when entering or leaving a
highway, on roads with intersections

or roundabouts or non-vehicular traffic or
roads that are winding, slippery, unpaved,
or steep slopes.

Do not use the system in poor
visibility, for example fog, heavy rain,
spray or snow.

Do not use the system when towing
a trailer with aftermarket trailer
brake controls. Aftermarket trailer

brakes will not function properly when you
switch the system on because the brakes
are electronically controlled. Failing to do
so may result in loss of vehicle control,
which could result in serious injury.

Do not use tire sizes other than those
recommended because this can
affect the normal operation of the

system. Failure to do so may result in a loss
of vehicle control, which could result in
serious injury.

Adaptive cruise control may not
detect stationary or slow moving
vehicles below 6 mph (10 km/h).

Adaptive cruise control does not
detect pedestrians or objects in the
road.

Adaptive cruise control does not
detect oncoming vehicles in the
same lane.

WARNINGS

Adaptive cruise control is not a crash
warning or avoidance system.

Note: It is your responsibility to stay alert,
drive safely and be in control of the vehicle
at all times.

The system adjusts your vehicle speed to
maintain the set gap between you and the
vehicle in front of you in the same lane.
You can select four gap settings.

The system uses a radar sensor that
projects a beam directly in front of your
vehicle.

E222797

The adaptive cruise controls are on the
steering wheel.

Switching Adaptive Cruise Control
On

Press ON.

E144529

The indicator, current gap setting
and set speed appear in the
information display.

E164805

Setting the Adaptive Cruise Speed

Note: When adaptive cruise control is
active, the speedometer may vary slightly
from the set speed displayed in the
information display.

1.

Drive to desired speed.

2. Press SET-.

3. A green indicator light, the current gap

setting and your set speed appear in
the information display.

4. Take your foot off the accelerator

pedal.

E164805

5. A vehicle image illuminates if the

system detects a vehicle in front of you.

Setting the Adaptive Cruise Speed
When Your Vehicle is Stationary

1.

Follow a vehicle to a complete stop.

2. Keep the brake pedal fully pressed.

3. Press RES+.

4. The set speed adjusts to 20 mph

(30 km/h).

5. A green indicator light, the current gap

setting and your set speed appear in
the information display.

Following a Vehicle

WARNINGS

When following a vehicle, your
vehicle does not always decelerate
quickly enough to avoid a crash

without driver intervention. Always apply
the brakes when necessary. Failing to do
so may result in a crash, serious injury or
death.

Adaptive cruise control only warns
of vehicles detected by the radar
sensor. In some cases there may be

no warning or a delayed warning. You
should always apply the brakes when
necessary. Failure to do so may result in a
crash, serious injury or death.

Note: When you are following a vehicle and
you switch on a direction indicator, adaptive
cruise control may provide a small
temporary acceleration to help you pass.

Note: The brakes may emit noise when
applied by the system.

When a vehicle ahead of you enters the
same lane or a slower vehicle is ahead in
the same lane, the vehicle speed adjusts
to maintain a preset gap distance.  A
vehicle graphic illuminates in the
instrument cluster.

Your vehicle maintains a consistent gap
from the vehicle ahead until:
•

The vehicle in front of you accelerates
to a speed above the set speed.

•

The vehicle in front of you moves out
of the lane you are in.

•

You set a new gap distance.

The system applies the brakes to slow your
vehicle to maintain a safe gap distance
from the vehicle in front.  The system only
applies limited braking.  You can override
the system by applying the brakes.

If the system determines that its maximum
braking level is not sufficient, an audible
warning sounds when the system
continues to brake.  A red warning bar
displays on the windshield and you must
take immediate action.

Following a Vehicle to a Complete
Stop

If your vehicle follows a vehicle to a
complete stop and remains stationary for
less than three seconds, your vehicle
accelerates from a stationary position to
follow the vehicle ahead.

If your vehicle follows a vehicle to a
complete stop and remains stationary for
more than three seconds, press RES+ or
the accelerator pedal to follow the vehicle
ahead.

Setting the Gap Distance

Note: The gap setting is time dependent
and therefore the distance adjusts with your
vehicle speed.

Note: It is your responsibility to select a gap
appropriate to the driving conditions.

You can decrease or increase the distance
between your vehicle and the vehicle in
front by pressing the gap control.

A

B

E222791

Gap decrease.

A

Gap increase.

B

E164805

Adaptive Cruise Control Gap Settings

Dynamic behavior

Graphic display,

bars indicated

between vehicles

Sport.

1

Normal.

2

Normal.

3

Comfort.

4

Each time you switch the system on, it
selects the last chosen gap setting.
