Ford Fusion (2018 year). Manual - part 20

POWER WINDOWS

WARNINGS

Do not leave children unattended in
your vehicle and do not let them play
with the power windows. Failure to

follow this instruction could result in
personal injury.

When closing the power windows,
verify they are free of obstruction and
make sure that children and pets are

not in the proximity of the window
openings.

E146043

Note: You may hear a pulsing noise when
just one of the windows is open. Lower the
opposite window slightly to reduce this
noise.

Press the switch to open the window.

Lift the switch to close the window.

One-Touch Down

Press the switch fully and release it.  Press
again or lift it to stop the window.

One-Touch Up

Lift the switch fully and release it. Press or
lift it again to stop the window.

Resetting One-Touch Up

Start the engine.

1.

Lift and hold the window control switch
until the door window is fully closed.
Continue to hold the switch for a few
seconds after window is closed.

2. Release the window control switch.

3. Press and hold the window control

switch until the door window is fully
open.

4. Release the window control switch.

5. Lift and hold the window control switch

until the window is fully closed.

6. Test for correct window operation by

carrying out the one-touch down and
one-touch up features.

Bounce-Back

The window will stop automatically while
closing. It reverses some distance if there
is an obstacle in the way.

Overriding the Bounce-Back Feature

WARNING

When you override the bounce-back
feature the window will not reverse
if it detects an obstacle. Take care

when closing the windows to avoid
personal injury or damage to your vehicle.

Pull up the window switch and hold within
a few seconds of the window reaching the
bounce-back position. The window travels
up with no bounce-back protection. The
window stops if you release the switch
before the window closes fully.

Window Lock

E144072

Press the control to lock or unlock the rear
window controls.  It will illuminate when
you lock the rear window controls.

Accessory Delay

You can use the window switches for
several minutes after you switch the
ignition off or until you open either front
door.

GLOBAL OPENING AND
CLOSING

You can use the remote control to operate
the windows with the ignition off.

Note: You can enable or disable this feature
in the information display or see an
authorized dealer.  See General
Information (page 96).

Note: To operate this feature, accessory
delay must not be active.

Opening the Windows

You can only open the windows for a short
time after you unlock your vehicle with the
remote control. After you unlock your
vehicle, press and hold the remote control
unlock button to open the windows and
vent the moonroof. Release the button
once movement starts. Press the lock or
unlock button to stop movement.

Closing the Windows

WARNING

When closing the windows and
moonroof, you should verify they are
free of obstructions and make sure

that children and pets are not in the
proximity of the window openings.

To close the windows and moonroof, press
and hold the remote control lock button.
Release the button once movement starts.
Press the lock or unlock button to stop
movement.

EXTERIOR MIRRORS

Power Exterior Mirrors

WARNING

Do not adjust the mirrors when your
vehicle is moving.

E144073

Left-hand mirror

A

Adjustment control

B

Right-hand mirror

C

To adjust a mirror:

1.

Select the mirror you want to adjust.
The control will illuminate.

2. Adjust the position of the mirror.
3. Press the mirror switch again.

Fold-Away Exterior Mirrors

Push the mirror toward the door window
glass. Make sure that you fully engage the
mirror in its support when returning it to its
original position.

Heated Exterior Mirrors

 (If Equipped)

See Heated Windows and Mirrors (page
128).

Memory Mirrors

 (If Equipped)

You can save and recall the mirror
positions through the memory function.
See Memory Function (page 134).

Auto-Dimming Feature

 (If Equipped)

The driver exterior mirror automatically
dims when the interior auto-dimming
mirror turns on.

Signal Indicator Mirrors

 (If Equipped)

The outer portion of the appropriate mirror
housing will blink when you switch on the
turn signal.

Puddle Lamps

 (If Equipped)

The lamps on the bottom part of the mirror
housing light when you use your
transmitter to unlock the doors or when
you open a door.

Integrated Blind Spot Mirrors

WARNING

Objects in the blind spot mirror are
closer than they appear.

Blind spot mirrors have an integrated
convex mirror built into the upper outboard
corner of the exterior mirrors. They can
increase your visibility along the side of
your vehicle.

Check the main mirror first before a lane
change, then check the blind spot mirror.
If the blind spot mirror does not show any
vehicles in its viewing area and the traffic
in the adjacent lane is at a safe distance,
signal that you intend to change lanes.
Glance over your shoulder to verify traffic
is clear and carefully change lanes.

A

B

C

E138665

The image of the approaching vehicle is
small and near the inboard edge of the
main mirror when it is at a distance. The
image becomes larger and begins to move
outboard across the main mirror as the
vehicle approaches (A). The image will
transition from the main mirror and begin
to appear in the blind spot mirror as the
vehicle approaches (B). The vehicle will
transition to your peripheral field of view
as it leaves the blind spot mirror (C).

Blind Spot Monitor

 (If Equipped)

See Blind Spot Information System
(page 208).

INTERIOR MIRROR

WARNING

Do not adjust the mirrors when your
vehicle is moving. This could result
in the loss of control of your vehicle,

serious personal injury or death.

Note: Do not clean the mirror housing or
glass with harsh abrasives, fuel or other
petroleum-based cleaning products.

You can adjust the interior mirror to your
preference. Some mirrors also have a
second pivot point. This lets you move the
mirror head up or down and from side to
side.

Pull the tab below the mirror toward you
to reduce glare at night.

Auto-Dimming Mirror

 (If Equipped)

Note:  Do not block the sensors on the front
and back of the mirror.  A rear center
passenger or raised rear center head
restraint may also block light from reaching
the sensor.

The mirror dims to reduce glare when
bright lights are detected from behind your
vehicle. It will automatically return to
normal reflection when you select reverse
gear to make sure you have a clear view
when backing up.
