Number of Admin Keys

Indicates how many admin keys are
programmed to your vehicle. Use this
feature to determine how many admin
keys you have for your vehicle, and detect
if an additional MyKey has been
programmed.

USING MYKEY WITH REMOTE
START SYSTEMS

MyKey is not compatible with non
Ford-approved, aftermarket remote start
systems. If you choose to install a remote
start system, see an authorized dealer for
a Ford-approved remote start system.

MYKEY TROUBLESHOOTING

Potential causes

Condition

· The key or transmitter used to start the
vehicle does not have admin privileges.

I cannot create a MyKey.

· Vehicles with keyless start: Make sure you
place the transmitter into the backup posi-
tion.  See Starting a Gasoline Engine
(page 147).
· The key or transmitter used to start the
vehicle is the only admin key. There always
has to be at least one admin key.
· SecuriLock passive anti-theft system is
disabled or in unlimited mode.

· The key or transmitter used to start the
vehicle does not have admin privileges.

I cannot program the configurable settings.

· There are no MyKeys programmed to the
vehicle. See Creating a MyKey (page 57).

· An admin transmitter is present when you
started your vehicle.

For vehicles with keyless start: No MyKey
restrictions are available when starting the
vehicle.

· There are no MyKeys programmed to the
vehicle.  See Creating a MyKey (page 57).

· The key or transmitter used to start the
vehicle does not have admin privileges.

I cannot clear the MyKeys.

· No MyKeys are created.  See Creating a
MyKey (page 57).

Potential causes

Condition

· Purchase a new key or transmitter from
your authorized dealer.

I lost the only admin key.

· Program a spare key or transmitter. You
may need to see your authorized dealer.
See Passive Anti-Theft System (page
68).

I lost a key.

· The MyKey user is not using the MyKey.

MyKey distances do not accumulate.

· An admin key holder cleared the MyKeys
and created new MyKeys.
· The key system has been reset.

LOCKING AND UNLOCKING

You can use the power door lock control
or the remote control to lock and unlock
your vehicle.

Power Door Locks

The power door lock control is on the driver
and front passenger door panels.

E138628

Unlock.

A

Lock.

B

Door Lock Indicator

An LED on the door window trim
illuminates when you lock the door.  It
remains illuminated for up to five minutes
after you switch the ignition off.

Door Lock Switch Inhibitor

When you electronically lock your vehicle,
the power door lock switch no longer
operates after 20 seconds.  You must
unlock your vehicle with the remote control
or keyless keypad, or switch the ignition
on, to restore function to these switches.
You can switch this feature off in the
information display.

See General Information (page 96).

Note: Switch the ignition on and off after
changing the setting in the information
display.

Rear Door Unlocking and Opening

Pull the interior door handle twice to
unlock and open a rear door.  The first pull
unlocks the door and the second pull
opens the door.

Remote Control

You can use the remote control at any
time. The luggage compartment release
button only works when your vehicle speed
is less than 3 mph (5 km/h).

Unlocking the Doors (Two-Stage
Unlock)

E138629

Press the button to unlock the
driver door. Press the button
again within three seconds to

unlock all doors. The direction indicators
flash.

Press and hold both the lock and unlock
buttons on the remote control for three
seconds to change between driver door or
all doors unlock mode. The direction
indicators flash twice to indicate a change
to the unlocking mode. Driver door mode
only unlocks the driver door when you
press the unlock button once. All door
mode unlocks all doors when you press
the unlock button once. The unlocking
mode applies to the remote control,
keyless entry keypad and intelligent
access. You can also change between the
unlocking modes using the information
display.  See General Information (page
96).

Locking the Doors

E138623

Press the button to lock all
doors.  The direction indicators
will flash.

Press the button again within three
seconds to confirm that all the doors are
closed.  The doors will lock again, the horn
will sound and the direction indicators will
flash if all the doors and the luggage
compartment are closed.

E112203

If the central locking function does not
operate, lock the doors individually using
the key in the position shown.  On the
left-hand side, turn the key clockwise to
lock.  On the right-hand side, turn the key
counterclockwise to lock.

Mislock

If any door or the luggage compartment is
open, or if the hood is open on vehicles
with an anti-theft alarm or remote start,
the horn sounds twice and the lamps do
not flash. You can enable or disable this
feature in the information display.  See
General Information (page 96).

Opening the Luggage Compartment

E138630

Press twice within three seconds
to open the luggage
compartment.

Activating Intelligent Access

 (If

Equipped)

General Information

You can unlock and lock the vehicle
without taking the keys out of your pocket
or purse when your intelligent access key
is within 3 ft (1 m) of your vehicle.
Intelligent access uses a sensor on the
back of the door handle for unlocking and
a separate sensor on the face of each door
handle for locking.

The system will not function if:
•

Your vehicle battery has no charge.

•

The key battery has no charge.

•

The passive key frequencies are
jammed.

Note: The system may not function if the
passive key is close to metal objects or
electronic devices, for example keys or a cell
phone.

Note: If the system does not function, use
the key blade to lock and unlock your
vehicle.  See Remote Control (page 50).

Unlocking Using Intelligent Access

E248553

With your intelligent access key within 3 ft
(1 m) of your vehicle, touch the unlock
sensor on the back of the door handle for
a brief period and then pull on the door
handle to unlock, being careful to not
touch the lock sensor at the same time or
pulling the door handle too quickly. The
intelligent access system requires a brief
delay to authenticate your intelligent
access key fob.
