Press and release OFF when the system is
in stand by mode or switch the ignition off.

DRIVER ALERT

Principle of Operation

WARNINGS

The system is designed to aid the
driver. It is not intended to replace
your attention and judgment. You are

still responsible to drive with due care and
attention.

At all times, you are responsible for
controlling your vehicle, supervising
the system and intervening, if

required. Failure to take care may result in
the loss of control of your vehicle, serious
personal injury or death.

The system may not function if the
sensor is blocked.

Take regular rest breaks if you feel
tired. Do not wait for the system to
warn you.

Certain driving styles may result in
the system warning you even if you
are not feeling tired.

In cold and severe weather
conditions the system may not
function. Rain, snow and spray can

all limit sensor performance.

The system will not operate if the
sensor cannot track the road lane
markings.

If damage occurs in the immediate
area surrounding the sensor, have
your vehicle checked as soon as

possible.

The system may not correctly
operate if your vehicle is fitted with
a suspension kit not approved by us.

Note: Keep the windshield free from
obstructions for example bird droppings,
insects and snow or ice.

Note: The system assists you when driving
on fast main roads and freeways.

Note: The system calculates an alertness
level at vehicle speeds above approximately
40 mph (65 km/h).

The system automatically monitors your
driving behavior.

The system is designed to alert you if it
detects that you are becoming drowsy or
if your driving deteriorates.

Using Driver Alert

Switching the System On and Off

Switch the system on using the information
display.  See Information Displays (page
91).

Note: The system remains on or off
depending on how it was last set.

The system calculates your alertness level
based upon your driving behavior in relation
to the lane markings and other factors.

System Warnings

Note: The system does not warn you if the
vehicle speed falls below approximately
40 mph (65 km/h).

The warning system has two stages:
1.

A temporary warning is issued to advise
you to take a rest. This message only
appears for a short time.

2. If you do not rest and the system

continues to detect that your driving
deteriorates, it issues a further warning.
This remains in the information display
until you cancel it.  See Information
Messages (page 95).

Press OK on the steering wheel control to
remove the warning.

System Display

When active the system runs automatically
in the background and only issue warnings
if required. You can view the status at any
time using the information display.  See
General Information (page 91).

The alertness level is shown by six steps
as a colored bar.

E131358

Alertness level is fine, no rest required.

E131359

Alertness level is critical, indicating that
you should take a rest as soon as it is safe
to do so.

The status bar travels from left to right as
the calculated alertness level decreases.
As the rest icon is approached, the color
turns from green to yellow and then finally
red when a rest break must be taken.

•

Green: No rest required.

•

Yellow: First (temporary) warning.

•

Red: Second warning.

Your alertness level will be shown in gray
if:
•

The sensor cannot track the road lane
markings.

•

The vehicle speed falls below
approximately 40 mph (65 km/h).

Resetting the System

You can reset the system by:
•

Switching the ignition off and on.

•

Stopping your vehicle and then opening
and closing the driver door.

LANE KEEPING SYSTEM

 (If

Equipped)

WARNINGS

The system is designed to aid the
driver. It is not intended to replace
your attention and judgment. You are

still responsible to drive with due care and
attention.

Always drive with due care and
attention when using and operating
the controls and features on your

vehicle.

At all times, you are responsible for
controlling your vehicle, supervising
the system and intervening, if

required. Failure to take care may result in
the loss of control of your vehicle, serious
personal injury or death.

In cold and severe weather
conditions the system may not
function. Rain, snow and spray can

all limit sensor performance.

The system will not operate if the
sensor cannot track the road lane
markings.

The sensor may incorrectly track lane
markings as other structures or
objects. This can result in a false or

missed warning.

Large contrasts in outside lighting
can limit sensor performance.

The system may not operate
properly if the sensor is blocked.
Keep the windshield free from

obstruction.

WARNINGS

If damage occurs in the immediate
area surrounding the sensor, have
your vehicle checked as soon as

possible.

Note: The system works above 40 mph
(64 km/h).

Note: The system works as long as the
camera can detect one lane marking.

Note: The system may not function if the
camera is blocked or there is damage to the
windshield.

Note: When Aid mode is on and the system
detects no steering activity for a short
period, the system will alert you to put your
hands on the steering wheel. The system
may detect a light grip or touch on the
steering wheel as hands off driving.

The system notifies you to stay in your lane
through the steering system and the
instrument cluster display when the front
camera detects an unintentional drift out
of your lane is likely to occur. The system
automatically detects and tracks the road
lane markings using a camera mounted
behind the interior rear view mirror.

Switching the System On and Off

Note: The system on or off setting is stored
until it is manually changed, unless a MyKey
is detected. If the system detects a MyKey
it defaults to on and the mode is set to Alert.

Note: If a MyKey is detected, pressing the
button will not affect the on or off status of
the system.

E144813

Press the button on the steering
wheel stalk to switch the system
on or off.

System Settings

The system has optional setting menus
available. The system stores the
last-known selection for each of these
settings. You do not need to readjust your
settings each time you turn on the system.

Mode: This setting allows you to select
which of the system features you can
enable.

E165515

Alert only – Provides a steering wheel
vibration when the system detects an
unintended lane departure.

E165516

Aid only – Provides an assistance steering
torque input toward the lane center when
the system detects an unintended lane
departure.
