Description Item Door check strap retaining bolt 4 Door hinge retaining bolts See Removal Detail 5 Description Item See Installation Detail Door (left-hand door shown) See Removal Detail 6 8 Nm E51750 8 13 12 9 10 11 7 8 Nm 8 Nm Description Item Front door handle, lock and latch retaining 7 Front door latch retaining bolts 8 Front door wiring harness retaining clip See Removal Detail 9 Front door latch remote control cable See Removal Detail 10 Description Item Front door wiring harness See Removal Detail 11 Front door lock actuator retaining screw See Removal Detail 12 Front door inner panel See Removal Detail 13 G413499en 501-14- 95 Handles, Locks, Latches and Entry Systems 501-14- 95 REMOVAL AND INSTALLATION |
