REAR SEATS

Folding Up the Rear Seats (SuperCab)

E162737

1.

Pull the control to release the seat
cushion.

2. Rotate the seat cushion up until it locks

into the vertical storage position.

Returning the Seat to the Seating
Position

WARNING

Make sure that cargo or any objects
are not trapped underneath the seat
cushion before returning the seat

cushion to its original position, and that the
seat cushion locks into place. Failure to do
so may prevent the seat from operating
properly in the event of a crash, which
could increase the risk of serious injury.

1.

Pull the control on the side of the seat
to release the seat cushion from the
storage position.

2. Push the seat cushion down until it

locks into the horizontal position.

Folding the Rear Seat Back (Crew
Cab)

E162738

1.

Pull forward on the control to fold
down the seatback.

2. Pull down on the handle and lift up on

the seatback to return it to the original
position.

Folding up the Rear Seat Cushion

1.

Pull the control to release the seat
cushion.

2. Rotate the seat cushion up until it locks

into the vertical storage position.

Returning the Seat to the Seating
Position

WARNING

Make sure that cargo or any objects
are not trapped underneath the seat
cushion before returning the seat

cushion to its original position, and that the
seat cushion locks into place. Failure to do
so may prevent the seat from operating
properly in the event of a crash, which
could increase the risk of serious injury.

1.

Pull the control on the side of the seat
to release the seat cushion from the
storage position.

2. Push the seat cushion down until it

locks into the horizontal position.

FRONT SEAT ARMREST

E162745

Press the button on the right-hand side of
the seat and pull the seatback down to
release the armrest. You can also gain
access to the cupholders and seatback
storage bin.

E162746

Pull up on the tab to open the storage bin

Lift up on the seatback to return it to the
upright position.

E162747

If your vehicle has an under-seat storage
compartment in the seat cushion, lift the
latch to open the lid of the compartment.
You cannot open the lid when the armrest
is down.

E162748

The under-seat storage compartment has
a programmable lock. Use the ignition key
to program the lock to the compartment.
You can power or charge electronics using
the under-seat storage compartment
auxiliary power point.  See Auxiliary
Power Points (page 83).

REAR SEAT ARMREST

 (If Equipped)

Type 1

E162744

Type 2

E208775

Fold the armrest down to use it.

12 Volt DC Power Point

WARNING

Do not plug optional electrical
accessories into the cigar lighter
socket. Incorrect use of the cigar

lighter can cause damage not covered by
the vehicle warranty, and can result in fire
or serious injury.

Note: When you switch the ignition on, you
can use the socket to power 12 volt
appliances with a maximum current rating
of 15 amps.

If the power supply does not work after you
switch the ignition off, switch the ignition
on.
Note: Do not hang any accessory from the
accessory plug.

Note: Do not use the power point over the
vehicle capacity of 12 volt DC 180 watts or
a fuse may blow.

Note: Always keep the power point caps
closed when not in use.

Do not insert objects other than an
accessory plug into the power point.  This
damages the power point and may blow
the fuse.

Run the vehicle for full capacity use of the
power point.

To prevent the battery from running out of
charge:
•

Do not use the power point longer than
necessary when the vehicle is not
running.

•

Do not leave devices plugged in
overnight or when you park your vehicle
for extended periods.

Locations

Power points may be in the following
locations:
•

On the instrument panel (two
locations).

•

Inside the front under-seat storage
compartment.

•

Inside the rear under-seat storage
compartment.

110 Volt AC Power Point

 (If Equipped)

WARNING

Do not keep electrical devices
plugged in the power point whenever
the device is not in use. Do not use

any extension cord with the 110 volt AC
power point, since it will defeat the safety
protection design. Doing so may cause the
power point to overload due to powering
multiple devices that can reach beyond
the 150 watt load limit and could result in
fire or serious injury.

Note: The power point turns off when you
switch the ignition off, or when the battery
voltage drops below 11 volts.

You can use the power point for electric
devices that require up to 150 watts.  It is
in the center of the instrument panel.

E193395
