Ford F-550 (2017 year). Manual - part 31

Settings

AdvanceTrac

Max Speed

Speed Minder

Volume Limiter

Follow onscreen directions to confirm
or modify your settings.

Clear MyKeys

Select Your Setting

Units

Display Setup

Temperature

Tire Pressure

Language

INFORMATION MESSAGES

Note: Depending on your vehicle options
and instrument cluster type, not all of the
messages will display or be available. The
information display may abbreviate or
shorten certain messages.

E184451

Press the OK button to acknowledge and
remove some messages from the
information display. The information
display will automatically remove other
messages after a short time.

You need to confirm certain messages
before you can access the menus.

Active Park

Action

Message

The system requires service due to a malfunction. Have the

system checked by an authorized dealer.

Active Park Fault

Adaptive Cruise Control

Action

Message

A radar malfunction is preventing the adaptive cruise control

from engaging.  See Using Cruise Control (page 239).

Adaptive Cruise

Malfunction

A condition exists such that the adaptive cruise cannot func-

tion properly.  See Using Cruise Control (page 239).

Adaptive Cruise Not

Available

You have a blocked sensor due to bad weather, ice, mud or

water in front of the radar sensor. You can typically clean the

sensor to resolve.  See Using Cruise Control (page 239).

Adaptive Cruise Not

Available Sensor

Blocked See Manual

The system has disabled the automatic braking.

Normal Cruise Active

Automatic Braking

Turned Off

A radar malfunction is preventing the adaptive cruise control

from engaging.

Front Sensor Not Aligned

The adaptive cruise has reinstated controls to the driver.

Adaptive Cruise - Driver

Resume Control

Your vehicle speed is too slow to activate the adaptive cruise.

Adaptive Cruise Speed

Too Low to Activate

The adaptive cruise is automatically adjusting the gap

distance and you need to shift the transmission into a lower

gear.

Adaptive Cruise Shift

Down

Adaptive Steering

Action

Message

The adaptive steering system has detected a difference

between steering wheel angle and the desired road wheel

angle. The steering wheel adjusts itself to correct this differ-

ence. This adjustment is part of normal system operation.

Adaptive Steering Initial-

ization

The adaptive steering system is off. It is possible that the

steering wheel may not be straight when the vehicle is driving

straight ahead. If this message persists, see an authorized

dealer.

Adaptive Steering Fault

Service Required

The adaptive steering system integrity cannot be verified. Do

not drive the vehicle and contact an authorized dealer

immediately.

Adaptive Steering Loss

Do Not Drive

AdvanceTrac and Traction Control

Action

Message

The system detects a condition that requires service. Contact

an authorized dealer as soon as possible.

Service AdvanceTrac

The status of the AdvanceTrac system after you switched it

off.

AdvanceTrac Off

The status of the AdvanceTrac system after you switched it

on.

AdvanceTrac On

The status of the AdvanceTrac sport mode after you switched

it on.

AdvanceTrac SPORT

MODE

The status of the traction control system after you switched

it off.  See Using Traction Control (page 225).

Traction Control Off

The status of the traction control system after you switched

it on.  See Using Traction Control (page 225).

Traction Control On

Airbag

Action

Message

Displays when the system detects a malfunction due to a

blocked sensor.

Occupant Sensor

BLOCKED Remove

Objects Near Passenger

Seat

Alarm and Security

Action

Message

Alarm triggered due to unauthorized entry.  See Anti-Theft

Alarm (page 76).

Vehicle Alarm To Stop

Alarm, Start Vehicle.

Automatic Engine Shutdown

Action

Message

The engine is getting ready to shut off.

Engine Shuts Off In

{seconds to shut off:#0}

Seconds

The engine has shut off to help increase fuel economy.

Engine Shut Off For Fuel

Economy

The engine is getting ready to shut off. You can press OK on

the left steering wheel button to override the shut down.

Engine Shuts Off in

{seconds to shut off:#0}

Seconds Press Ok to

Override

Battery and Charging System

Action

Message

The charging system needs servicing. If the warning stays on

or continues to come on, contact an authorized dealer as soon

as possible.

Check Charging System

The battery management system detects an extended low-

voltage condition. Your vehicle will disable various features

to help preserve the battery. Turn off as many of the electrical

loads as soon as possible to improve system voltage. If the

system voltage has recovered, the disabled features will

operate again as normal.

Low Battery Features

Temporarily Turned Off

The battery management system determines that the battery

is at a low state of charge. Turn your ignition off as soon as

possible to protect the battery. This message will clear once

you restart your vehicle and the battery state of charge has

recovered. Turning off unnecessary electrical loads will allow

faster battery state-of-charge recovery.

Turn Power Off To Save

Battery
