Ford F-53 Motorhome Chassis (2017 year). Manual - part 3

WINDSHIELD WIPERS

Note: Fully defrost the windshield before
switching on the windshield wipers.

Note: Make sure the windshield wipers are
switched off before entering a car wash.

Note: Clean the windshield and wiper
blades if they begin to leave streaks or
smears. If that doesn't resolve the issue,
install new wiper blades.

Note: Do not operate the wipers on a dry
windshield. This may scratch the glass,
damage the wiper blades or cause the wiper
motor to burn out. Always use the
windshield washers before wiping a dry
windshield.

E161461

Rotate the end of the control:

•

away from you to increase the wiper
speed

•

toward you to decrease the wiper
speed

WINDSHIELD WASHERS

Note: Do not operate the wipers on a dry
windshield. This may scratch the glass,
damage the wiper blades or cause the wiper
motor to burn out. Always use the
windshield washer before wiping a dry
windshield.

Note: Do not operate the washers when
the washer reservoir is empty. This may
cause the washer pump to overheat.

Press the end of the stalk to activate the
washer.

•

A brief press causes a single wipe
without washer fluid.

•

A quick press and hold causes the
wipers to swipe three times with
washer fluid.

•

A long press and hold will activate the
wipers and washer fluid for up to 10
seconds.

E161462

LIGHTING CONTROL

E161456

A

B

C

P

Off.

A

Parking lamps, instrument panel
lamps, license plate lamps and
tail lamps.

B

Headlamps.

C

High Beams

E161457

Push the lever away from you to switch
the high beam on.

Push the lever forward again or pull the
lever toward you to switch the high beams
off.

Headlamp Flasher

E161458

Slightly pull the lever toward you and
release it to flash the headlamps.

INSTRUMENT LIGHTING
DIMMER

Note: If you disconnect the battery or it
becomes discharged, the dimmer switch
will require re-calibration. Rotate the
dimmer switch from the full dim position to
the full dome/on position to reset.

Note: Move the control to the full upright
position, past detent, to turn on the interior
lamps.

E161459

Move the control up or down to adjust the
intensity of the panel lighting.

DAYTIME RUNNING LAMPS

 (If

Equipped)

WARNING

The daytime running lamps system
does not activate the rear lamps and
may not provide adequate lighting

during low visibility driving conditions. Also,
the autolamps switch position may not
activate the headlamps in all low visibility
conditions, such as daytime fog. Make sure
the headlamps are switched to auto or on,
as appropriate, during all low visibility
conditions. Failure to do so may result in a
crash.

The system switches the low beam
headlamps on at a reduced intensity in
daylight conditions.

To switch the system on, switch the
ignition on, and switch the lighting control
to the off or parking lamp position.

DIRECTION INDICATORS

E161460

Push the lever up or down to use the
direction indicators.

Note: Tap the lever up or down to make the
direction indicators flash three times to
indicate a lane change.

GAUGES

E192271

Engine oil pressure gauge.

A

Tachometer.

B

Information display.

C

Speedometer.

D

Transmission fluid temperature gauge.

E

Engine coolant temperature gauge.

F

Fuel gauge.

G
