Specification

Name

WSS-M2C942-A

Rear axle fluid (10.50 inch axle) (E-Locker/non E-Locker):
Motorcraft® SAE 75W-85 Premium Synthetic Hypoid
Gear Lubricant
XY-75W85-QL

WSL-M2C192-A

Rear axle fluid (Dana M275) (U.S. and Mexico):
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant
XY-75W140-QL

WSL-M2C192-A

Rear axle fluid (Dana M275) (Canada):
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant
CXY-75W140-1L

WSP-M2C197-A

Rear axle fluid (Dana M300) (U.S. and Mexico):
Motorcraft® SAE 80W-90 Premium Rear Axle Lubricant
XY-80W90-QL

WSP-M2C197-A

Rear axle fluid (Dana M300) (Canada):
Motorcraft® SAE 80W-90 Premium Rear Axle Lubricant
CXY-80W90-1L

EST-M2C118-A

Friction Modifier
Motorcraft® Additive Friction Modifier
XL-3

WSS-M2C938-A

Automatic transmission fluid (U.S.) :

MERCON LV

Motorcraft® MERCON LV Automatic Transmission Fluid
XT-10-QLVC

WSS-M2C938-A

Automatic transmission fluid (Canada):

MERCON LV

Motorcraft® MERCON LV Automatic Transmission Fluid
CXT-10-LV12

WSS-M2C938-A

Transfer case fluid (U.S.):

MERCON LV

Motorcraft® Transfer Case Fluid
XT-10-QLVC

WSS-M2C938-A

Transfer case fluid (Canada):

MERCON LV

Motorcraft® Transfer Case Fluid
CXT-10-LV12

WSS-M2C938-A

Power steering fluid:

MERCON LV

Motorcraft® MERCON LV
XT-10-QLVC

WSS-M2C192-A

Spindle bearing:
High Temperature 4x4 Front Axle and Wheel Bearing
Grease
XG-11

Specification

Name

WSB-M8B16-A2

Windshield washer fluid (U.S.):
Motorcraft® Premium Windshield Wash Concentrate
with Bitterant
ZC-32-B2

WSB-M8B16-A2

Windshield washer fluid (Canada):
Motorcraft® Premium Quality Windshield Washer Fluid
CXC-37-(A, B, D, F)

WSH-M17B19-A

A/C refrigerant (U.S.):
Motorcraft® R-134a Refrigerant
YN-19

WSH-M17B19-A

A/C refrigerant (Canada):
Motorcraft® R-134a Refrigerant
CYN-16-R

WSH-M1C231-B

A/C refrigerant compressor oil:
Motorcraft® PAG Refrigerant Compressor Oil
YN-12-D

ESB-M1C93-B

Multi-purpose grease:
Motorcraft® Multi-Purpose Grease Spray
XL-5-A

--

Lock cylinders (U.S.):
Penetrating and Lock Lubricant
XL-1

--

Lock cylinders (Canada):
Penetrating Fluid
CXC-51-A

--

Lock cylinders (Mexico):
Penetrating and Lock Lubricant
MXL-1

WSD-M1C227-A

Transmission, parking brake linkages and pivots, brake
pedal shift:
Motorcraft® Premium Long-Life Grease
XG-1-E

If you use oil and fluids that do not meet
the defined specification and viscosity
grade, this may lead to:
•

Component damage which is not
covered by the vehicle warranty.

•

Longer engine cranking periods.

•

Increased emission levels.

•

Reduced engine performance.

•

Reduced fuel economy.

•

Degraded brake performance.

We recommend Motorcraft® motor oil for
your vehicle. If Motorcraft® oil is not
available, use motor oils of the
recommended viscosity grade that meet
API SN requirements and display the API
Certification Mark for gasoline engines. Do
not use oil labeled with API SN service
category unless the label also displays the
API certification mark.

E142732

An oil that displays this symbol conforms
to current engine, emission system and
fuel economy performance standards of
the International Lubricants Specification
Advisory Committee (ILSAC).

Do not use supplemental engine oil
additives because they are unnecessary
and could lead to engine damage that may
not be covered by your vehicle warranty.

Note: Ford recommends using DOT 4 Low
Viscosity (LV) High Performance Brake Fluid
or equivalent meeting WSS-M6C65-A2. Use
of any fluid other than the recommended
fluid may cause degraded brake
performance and not meet the Ford
performance standards. Keep brake fluid
clean and dry. Contamination with dirt,
water, petroleum products or other
materials may result in brake system
damage and possible failure.

Note:  Automatic transmissions that require
MERCON® LV transmission fluid should
only use MERCON® LV transmission fluid.
The use of any other fluid may cause
transmission damage.

CAPACITIES AND SPECIFICATIONS - 6.8L

Capacities

WARNING

The air conditioning refrigerant system contains refrigerant under high pressure.
Only qualified personnel should service the air conditioning refrigerant system.
Opening the air conditioning refrigerant system can cause personal injury.

Capacity

Item

7.0 qt (6.6 L)

1

Engine oil (with oil filter)

26.7 qt (25.3 L)

Engine coolant

Between MIN and MAX on brake fluid

reservoir

Brake fluid

2.7 qt (2.6 L)

Front axle

3.3–3.5 qt (3.1–3.3 L)

Rear axle-10.5 inch (E-Locker)

3.5–3.6 qt (3.3–3.4 L)

Rear axle-10.5 inch (non E-Locker)

3.8 qt (3.63 L)

Rear axle-Dana M275

4.5 qt (4.26 L)

2

Rear axle-Dana M300

17.4 qt (16.5 L)

3

Automatic transmission fluid

1.9 qt (1.8 L)

Transfer case fluid

Fill as required

Windshield washer fluid

26.5 gal (100.3 L)

Fuel tank (incomplete vehicle, middle
location)

40 gal (151.4 L)

Fuel tank (incomplete vehicle, Aft- axle -
location)

27 oz (0.77 kg)

A/C refrigerant

4.1 fl oz (120 ml)

A/C refrigerant compressor oil

1

Reference the reservoir cap for proper fluid.

2

For complete refill of limited slip Ford axles add 8.8 fl oz. (260ml) of Additive Friction

Modifier XL-3 or equivalent meeting Ford Specification EST-M2C118-A.

3

Approximate dry fill capacity. Actual amount may vary during fluid changes.
