F-250 Light Duty (1999 year). Manual - part 38

Fuse/Relay

Location

Fuse Amp

Rating

Description

(Gasoline

only)

30A*

(Diesel

only)

Gasoline only-Not Used
Diesel only-Injector Driver Module

30A**

Trailer Tow Electronic Brake Controller

20A**

Radio

PCM Power Relay

Blower Motor Relay

Two Speed Fuel Pump Relay (Gasoline
only), Injector Driver Module Power Relay
(Diesel only)

Washer Pump Relay

Windshield Wiper Park/Run Relay

Windshield Wiper HI/LO Relay

Not Used

PCM Relay Diode

Trailer Tow Backup Lamp Relay

Trailer Tow Battery Charge Relay

Electronic Shift On The Fly Relay #1,
Electronic Shift On The Fly Relay #2

* Mini Fuses ** Maxi Fuses ***Circuit Breaker

CHANGING THE TIRES

If you get a flat tire while driving, do not apply the brake heavily.
Instead, gradually decrease your speed. Hold the steering wheel firmly
and slowly move to a safe place on the side of the road.

Spare tire information

Your vehicle may be equipped with a spare tire that can be used as
either a spare or a regular tire. The spare tire is not equipped with wheel
trim. The wheel trim from the original wheel/tire may be used on the
spare.

Roadside emergencies

152

If your vehicle is equipped with 4WD, a spare tire of a different
size than the road tires should not be used. Such a tire could
result in damage to driveline components and make the vehicle
difficult to control.

Location of the spare tire and tools

The spare tire and tools for your vehicle are stowed in the following
locations:

Tool

Location

Spare tire (pick-up

trucks only)

Under the vehicle, just forward of the rear
bumper

Jack

Regular cab, crew cab and SuperCab without
rear bench seat: Fastened to floor pan behind
rearmost seat on passenger side

SuperCab with rear bench seat: Under rear
bench on passenger side

Jack handle and lug

wrench

On top of the radiator support at the front of
the engine compartment

Removing the spare tire (with spare tire carrier only)

1. The following tools are required to remove the spare tire:
• one handle extension and one

typical extension. To assemble,
align button with hole and slide
parts together. To disconnect,
depress button and pull apart.

• one wheel nut wrench. Slide over

square end of jack handle.

Roadside emergencies

153

2. The following steps are required to move the support bracket (if
equipped) away from the spare tire:
• With tapered end of lug wrench,

loosen the eyebolt on the support
bracket.

• Line up the eyebolt with the slot

in the support bracket.

• Slide the support bracket off the

eyebolt and move the support
bracket away from the spare tire.

3. Insert the hooked end of the jack
handle into the rear bumper
opening.

The handle will stop moving and
you will feel forward resistance to
turning when properly engaged.

4. Turn the handle counterclockwise
and lower the spare until you can
slide the tire rearward and the cable
is slack.

5. Remove the retainer through the center of the wheel.

Stowing the spare

1. Lay the tire on the ground with the valve stem facing up.

2. Slide the wheel under the vehicle
and install the retainer through the
wheel center.

3. Turn the jack handle clockwise
until the tire is raised to its original
position underneath the vehicle. The
effort to turn the jack handle
increases significantly and the spare
tire carrier ratchets when the tire is
raised to the stowed position. The spare tire carrier has a built-in ratchet
feature that will not allow you to overtighten.

4. Check that the tire lies flat to the frame assembly. Push against the
tire to make sure it is tightly seated under the vehicle. Loosen or
retighten if necessary.

Roadside emergencies

154

5. The following steps are required to secure the support bracket (if
equipped) under the spare tire:
• Move the support bracket over the spare tire.
• Slide the support bracket over the eyebolt into the slot on the support

bracket.

• Tighten the eyebolt with tapered end of lug wrench leaving it

positioned at a right angle of the slot on the support bracket.

Tire change procedure

1. Park on a level surface, activate
hazard flashers and set the parking
brake.
• Automatic transmission: Place

gearshift lever in P (Park).

• Manual transmission: Place

gearshift lever in R (Reverse).

• Electronic Shift On the Fly four

wheel drive: Place transfer case
in 2WD, 4x4 HIGH or 4x4 LOW.

• Manual shift transfer case four

wheel drive: Place transfer case
in 2H, 4H or 4L.

To prevent the vehicle from
moving when you change a

tire, be sure the parking brake is
set, then block (in both
directions) the wheel that is
diagonally opposite (other side
and end of the vehicle) to the tire
being changed.

2. Turn engine OFF and block the diagonally opposite wheel (block not
provided).

3. Remove the jack, jack handle, lug wrench and spare tire from the
stowage locations.

4. Use the tip of the lug wrench to remove any wheel trim.

Roadside emergencies

155
