Ford Explorer (2018 year). Manual - part 58

System Limitations

WARNING

The Pre-Collision Assist system’s
brake support only reduces collision
speed if you first apply your brakes.

You must brake as you would in any typical
braking situation.

Due to the nature of radar technology,
there may be certain instances where
vehicles do not provide a collision warning.
These include:

•

Stationary vehicles or vehicles moving
below 6 mph (10 km/h).

•

Pedestrians or objects in the roadway.

•

Oncoming vehicles in the same lane.

•

Severe weather conditions (see
blocked sensor section).

•

Debris build-up on the grille near the
headlamps (see blocked sensor
section).

•

Small distance to vehicle ahead.

•

Large steering wheel and pedal
movements (very active driving style).

Damage to the front end of your vehicle
may alter the radar sensor's coverage area.
This may result in missed or false collision
warnings. Have an authorized dealer check
your radar sensor for proper coverage and
operation.

REAR UNDER FLOOR
STORAGE

Cargo Management System

 (If

Equipped)

The system is located in the floor of the
cargo area. Lift the handle to open.

Adjustable Load Floor

 (If Equipped)

Vehicles with the standard size spare tire
can adjust the load floor to two positions.
The front of the load floor can be placed
either on (for high position) or below (for
low position) the ledges behind the rear
seats. The rear of the load floor always sits
on the two small shelves located on the
liftgate trim.

CARGO NETS

 (If Equipped)

WARNING

This net is not designed to restrain
objects during a collision or heavy
braking.

The cargo net secures lightweight objects
in the cargo area. Attach the net to the
anchors provided. Repeat the attachment
on both sides of the vehicle.

LUGGAGE COVERS

 (If Equipped)

WARNINGS

Make sure that the posts are properly
latched in mounting features. The
cover may cause injury in a sudden

stop or accident if it is not securely
installed.

Do not place any objects on the
cargo area shade. They may obstruct
your vision or strike occupants of

your vehicle in a sudden stop or crash.

Use the cargo shade to cover items in the
cargo area of your vehicle.

Insert the ends of the cargo shade into the
mounting features located behind the rear
seat on the rear trim panels to install the
cargo shade.

To operate the cargo shade:

1.

Pull the rear edge of the cargo shade
rearward.

2. Secure both ends of the support rod

into the retention slots located on the
rear quarter trim panels.

ROOF RACKS AND LOAD
CARRIERS

 (If Equipped)

WARNING

When loading the roof racks, we
recommend you evenly distribute the
load, as well as maintain a low

center of gravity. Loaded vehicles, with
higher centers of gravity, may handle
differently than unloaded vehicles. Take
extra precautions, such as slower speeds
and increased stopping distance, when
driving a heavily loaded vehicle.

The maximum recommended load, evenly
distributed on the crossbars, is:
•

100 lb (45 kg) for vehicles without a
moonroof.

•

45 lb (20 kg) for vehicles with a
moonroof.

For correct roof rack system function, you
must place loads directly on crossbars
affixed to the roof rack side rails. When
using the roof rack system, we recommend
you use Ford Genuine Accessory crossbars
designed specifically for your vehicle.

Make sure that you securely fasten the
load.  Check the tightness of the load
before driving and at each fuel stop.

Thumbwheel Kit

A thumbwheel kit is included in your
vehicle for tying light loads to your roof.
The kit is located in the glovebox.

Make sure to check that the thumbwheels
are tight each time you add or remove load
from the roof rack, and periodically while
traveling. Make sure that the load is secure
before traveling.

Note: There may be snap caps in the side
rail, which must be removed before
installing the thumbwheels. These caps can
be removed by using a T25 torx tool or a
similar tool.

Adjusting the Crossbar

 (If Equipped)

Note: For less wind noise and better
aerodynamics, only install the crossbars
when you need them for carrying cargo.
Follow the steps to reposition or remove the
rear crossbar. You can remove the front
crossbar fasteners by unscrewing the
assembly.

1.

Remove the crossbar bolts at both
sides of the front crossbar by using a
T25 torx tool or a similar tool.

2. Remove the crossbar by sliding the

ends off of the side rails.

3. Move the crossbar to the new side rail

position and slide onto rail.

4. Replace and tighten the bolts at both

sides of the crossbar by using a T25
torx tool or a similar tool.

Note: There may be snap caps in the new
side rail position, which must be removed
before installing the crossbar. You can
remove these caps by using a T25 torx tool
or a similar tool.

LOAD LIMIT

Vehicle Loading - with and
without a Trailer

This section guides you in the
proper loading of your vehicle,
trailer, or both. Keep your loaded
vehicle weight within its design
rating capability, with or without
a trailer. Properly loading your
vehicle provides maximum return
of vehicle design performance.
Before you load your vehicle,
become familiar with the
following terms for determining
your vehicle’s weight rating, with
or without a trailer, from the
vehicle’s Tire and Loading
Information label or Safety
Compliance Certification label.
