Ford Expedition (2018 year). Manual - part 82

E248889

Reverse lamp bulb.

A.

Rear lamp, brake lamp and
direction indicator bulb.

B.

Note:

You cannot separate the bulb from

the bulb holder.

LED Bulbs

 (If Equipped)

Note:

Vehicles with LED headlamps do not

contain serviceable bulbs. See an authorized
dealer if they fail.

These lamps operate at a high voltage.
Contact an authorized dealer.

•

Rear lamp.

•

Brake lamp.

•

Rear direction indicator.

•

Side direction indicator.

•

Reverse lamp.

•

Central high-mounted brake lamp.

•

License plate lamp.

BULB SPECIFICATION CHART

Replacement bulbs are specified in the
chart below.  Headlamp bulbs must be
marked with an authorized D.O.T. marking
for North America to make sure they have
the proper lamp performance, light
brightness, light pattern and safe visibility.
The correct bulbs will not damage the
lamp assembly or void the lamp assembly
warranty and will provide quality bulb
illumination time.

Exterior Lamps

Power (Watt)

Specification

Lamp

5

W5W

Position lamp.

5

7444NA

Front direction indicator.

LED

LED

Daytime running lamps.

55

H11

Halogen headlamp low beam.

55

HB3

Halogen headlamp high beam.

LED

LED

LED headlamps.

55

9140

Halogen front fog lamps.

LED

LED

LED front fog lamps.

5

W5W

Front side marker lamps.

LED

LED

Side direction indicator.

27/6.7

3057

Rear lamp, brake lamp and rear direction indicator.

Power (Watt)

Specification

Lamp

5

912

Central high mounted brake lamp.

27

3156

Reversing lamps.

5

912

License plate lamp.

LED lamps are not serviceable.  Contact an authorized dealer if they fail.

Interior Lamps

Power (Watt)

Specification

Lamp

LED

LED

Glove compartment lamp.

LED

LED

Vanity mirror lamp.

LED

LED

Map lamp.

LED

LED

Interior lamp.

1

LED

LED

Rear dome lamp.

1

Second row rail lamp.

CHANGING THE ENGINE AIR
FILTER

WARNING

To reduce the risk of vehicle damage
and personal burn injuries, do not
start your engine with the air cleaner

removed and do not remove it while the
engine is running.

Note:

 Failure to use the correct air filter

element may result in severe engine
damage.  Resulting component damage
may not be covered by the vehicle Warranty.

When changing the air filter element, use
only the air filter element listed.  See
Motorcraft Parts

 (page 370).

Change the air filter element at the correct
interval.  See Scheduled Maintenance
(page 489).

E248801

1.

Release the two clamps that secure
the cover to the air filter housing. Push
the air filter cover toward the front of
the vehicle and up slightly to release it.

2. Remove the air filter element from the

air filter housing.

3. Install the new air filter element.

E248800

4. Replace the air filter housing cover and

secure all the clamps. Be careful not
to crimp the filter element edges
between the air filter housing and cover
and ensure that you properly align the
tabs on the edge into the slots.

GENERAL INFORMATION

Your dealer has many quality products
available to clean your vehicle and protect
its finishes.

CLEANING PRODUCTS

Materials

For best results, use the following products
or products of equivalent quality:

Specification

Name

Motorcraft® Bug and Tar Remover ZC-42 (U.S. & Canada)

ESR-M5B194-B

Motorcraft® Custom Bright Metal Cleaner ZC-15 (U.S. & Canada)

ESR-M14P4-A

Motorcraft® Detail Wash ZC-3-A (U.S. & Canada)

ESR-M14P3-A

Motorcraft® Engine Shampoo and Degreaser ZC-20 (U.S.)

Motorcraft® Engine Shampoo CXC-66-A (Canada)

WSS-M99P43-B

Motorcraft® Leather and Vinyl Cleaner ZC-56 (U.S. & Canada)

Motorcraft® Multi-Purpose Cleaner CXC-101 (Canada)

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with Bitterant
ZC-32-B2 (U.S.)

WSS-M14P19-A

Motorcraft® Premium Quality Windshield Washer Fluid CXC-37-
A/B/D/F (Canada)

Motorcraft® Professional Strength Carpet & Upholstery Cleaner
ZC-54 (U.S. & Canada)

ESR-M14P5-A

Motorcraft® Premium Glass Cleaner CXC-100 (Canada)

Motorcraft® Spot and Stain Remover ZC-14 (U.S.)

ESR-M14P5-A

Motorcraft® Ultra-Clear Spray Glass Cleaner ZC-23 (U.S.)

Motorcraft® Wheel and Tire Cleaner ZC-37-A (U.S. & Canada)

CLEANING THE EXTERIOR

Wash your vehicle regularly with cool or
lukewarm water and a neutral pH
shampoo, we recommend Motorcraft
Detail Wash.

•

Never use strong household detergents
or soap, for example dish washing or
laundry liquid. These products can
discolor and spot painted surfaces.

•

Never wash your vehicle when it is hot
to the touch, or during strong or direct
sunlight.

•

Dry your vehicle with a chamois or soft
terry cloth towel to eliminate water
spotting.
