Ford Excursion (2000 year). Manual - part 52

LUBRICANT SPECIFICATIONS

Item

Ford part
name or
equivalent

Ford part
number

Ford
specification

Front axle

Motorcraft SAE
75W-90
Premium 4x4
Front Axle
Lubricant

XY-75W90-TQL

WSP-M2C201-A

Rear axle

Motorcraft SAE
75W-140 High
Performance
Synthetic Rear
Axle Lubricant

F1TZ-19580-B

WSL-M2C192-A

Brake fluid

High
Performance
DOT 3 Motor
Vehicle Brake
Fluid

C6AZ-19542-AB

ESA-M6C25-A
and DOT 3

Engine
coolant-Gasoline
engines

Ford Premium
Engine Coolant

E2FZ-19549-AA
(in Canada,
Motorcraft
CXC-8-B)

ESE-M97B44-A

Engine
coolant-Diesel
engine

Refer to your 7.3L Diesel Supplement

Engine
oil-Gasoline
engines

Motorcraft SAE
5W-30 Super
Premium Motor
Oil

XO-5W20-QSP

WSS-M2C153-G
and API
Certification
Mark

Engine oil-Diesel
engine

Refer to your 7.3L Diesel Supplement

Capacities and specifications

207

Item

Ford part
name or
equivalent

Ford part
number

Ford
specification

Hinges, latches,
striker plates,
fuel filler door
hinge and seat
tracks

Multi-Purpose
Grease

DOAZ-19584-AA
or
F5AZ-19G209-AA

ESB-M1C93-B or
ESR-M1C159-A

Transmission
/steering/parking
brake linkages
and pivots,
brake pedal
shaft

Premium
Long-Life Grease

XG-1-C or
XG-1-K

ESA-M1C75-B

Power steering
fluid and
transfer case
fluid (if
equipped)

Motorcraft
MERCON

t ATF

XT-2-QDX

MERCON

Automatic
transmission

Motorcraft
MERCON

t ATF

XT-2-QDX

MERCON

Windshield
washer fluid

Ultra-clear
Windshield
Washer
Concentrate

C9AZ-19550-AC

ESR-M17P5-A

Add 236 ml (8 oz.) of Additive Friction Modifier C8AZ-19B546-A or

equivalent meeting Ford specification EST-M2C118-A for complete refill
of Traction-Lok axles. Ford design rear axles contain a synthetic
lubricant that does not require changing unless the axle has been
submerged in water.

Ensure the correct automatic transmission fluid is used. Transmission

fluid requirements are indicated on the dipstick or on the dipstick
handle. Check the container to verify the fluid being added is of the
correct type. Refer to your scheduled maintenance guide to determine
the correct service interval.

Capacities and specifications

208

Some transmission fluids may be labeled as dual usage, such as
MERCON

t and MERCONt V. These dual usage fluids are not to be used

in an automatic transmission that requires use of the MERCON

t type

fluid. However, these dual usage fluids may be used in transmissions that
require the MERCON

t V type fluid.

MERCON

t and MERCONt V type fluids are not interchangeable.

DO NOT mix MERCON

t and MERCONt V. Use of a transmission

fluid that indicates dual usage (MERCON

t and MERCONt V) in

an automatic transmission application requiring MERCON

t may

cause transmission damage. Use of any fluid other than the
recommended fluid may cause transmission damage.

ENGINE DATA

Engine*

5.4L V8 engine

6.8L V10 engine

Cubic inches

330

415

Required fuel

87 octane

Firing order

1-3-7-2-6-5-4-8

1-6-5-10-2-7-3-8-4-9

Spark plug gap

1.3-1.4 mm
(0.052-0.056 inch)

Ignition system

Coil on plug

Compression ratio

9.0:1

VEHICLE DIMENSIONS

EXCURSION

Dimension

4x2 mm (in)

4x4 mm (in)

(1) Overall length

5 757 (226.7)

(2) Overall width

2 031 (80.0)

(3) Overall height

1 967 (77.4)

2 043 (80.4)

(4) Wheelbase

3 480 (137.0)

(5) Track (Front /
Rear)

1 738 (68.4)/
1 729 (68.1)

Capacities and specifications

209

Capacities and specifications

210
