REFILL CAPACITIES

Fluid

Ford Part
Name

Application

Capacity

Brake fluid

High
Performance
DOT 3 Motor
Vehicle Brake
Fluid

All

Fill to line on
reservoir

Engine coolant

1

Motorcraft
Premium Engine
Coolant
(green-colored)
or Motorcraft
Premium Gold
Engine Coolant
(yellow-colored)

Automatic
transaxles

6.0L (6.3
quarts)

Manual
transaxles

5.0L (5.3
quarts)

Engine oil
(includes filter
change)

Motorcraft SAE
5W-20Premium
Synthetic Blend
Motor Oil

All

4.25L (4.5
quarts)

Fuel tank
capacity

N/A

All

48.5L (12.8
gallons)

Power steering
fluid

Motorcraft
MERCON

威 ATF

All

Fill to line on
reservoir

Transmission
fluid

Motorcraft
MERCON

威 ATF

Automatic
transaxles

3.9L (4.1
quarts)

Manual
transaxles

3.35L (3.55
quarts)

Windshield
washer fluid

Motorcraft
Premium
Windshield
Washer
Concentrate

All

2.2L (2.32
quarts)

1

Add the coolant type originally equipped in your vehicle.

Maintenance and Specifications

170

LUBRICANTSPECIFICATIONS

Item

Ford Part
Name or
Equivalent

Ford Part
Number

Ford
Specification

Brake fluid

Motorcraft High
Performance
DOT 3 Motor
Vehicle Brake
Fluid

PM-1

ESA-M6C25-A
and DOT 3

Door latch, hood
latch, auxiliary
hood latch,
trunk latch, seat
tracks.

Multi-Purpose
Grease

XG-4 or XL-5

ESB-M1C93-B or
ESR-M1C159-A

Lock cylinder

Penetrating and
Lock Lubricant

XL-1

none

Automatic
transaxle

Motorcraft
MERCON

威 ATF

XT-2-QDX

MERCON

威

Manual transaxle Motorcraft

MERCON

威 ATF

XT-2-QDX

MERCON

威

Engine oil

Motorcraft SAE
5W-20 Premium
Synthetic Blend
Motor Oil

XO-5W20-QSP

WSS-M2C153-H
and API
Certification
Mark

Constant
velocity joints

CV Joint Grease

XG-5

WSS-M1C258–A1

Engine coolant

1

Motorcraft
Premium Engine
Coolant
(green-colored)

VC-4-A (US) or
CXC-10
(Canada)

ESE-M97B44–A

Motorcraft
Premium Gold
Engine Coolant
(yellow-colored)

VC-7–A (VC-7–B
in Oregon)

WSS-M97B51-A1

Maintenance and Specifications

171

Item

Ford Part
Name or
Equivalent

Ford Part
Number

Ford
Specification

Power steering
fluid

Motorcraft
MERCON

威 ATF

XT-2-QDX

MERCON

威

Windshield
washer fluid

Motorcraft
Premium
Windshield
Washer
Concentrate

ZC-32-A

WSB-M8B16–A2

1

DO NOT USE Motorcraft Specialty Orange Engine Coolant VC-2 or

VC-3, meeting Ford specification WSS-M97B44-D (orange in color) Refer
to Adding engine coolant, in this chapter.

ENGINE DATA

Engine

2.0L DOHC Zetecengine

Cubic inches

121

Required fuel

87 octane

Firing order

1-3-4-2

Spark plug gap

1.22-1.32 mm (0.048-0.052 inch)

Ignition systemDIS

Compression ratio

9.6:1

VEHICLE DIMENSIONS

Vehicle dimensions

mm (in)

(1) Overall length

4451.0 (175.2)

(2) Overall width

1712.0 (67.4)

(3) Overall height

1328.4 (52.3)

(4) Wheelbase

2499.0 (98.4)

(5) Track - Front

1435.1 (56.5)

(5) Track - Rear

1435.1 (56.5)

Maintenance and Specifications

172

2

5

5

4

3

1

Maintenance and Specifications

173
