The moon roof has a sliding shade that can be opened or closed when the
glass panel is shut. To close the shade, pull it toward the front of the vehicle.

Accessory delay:

With accessory delay, the window switches, audio system, and moon roof
(if equipped) may be used for up to 10 minutes after the ignition switch
is turned off or until either front door is opened.

UNIVERSAL GARAGE DOOR OPENER (IF EQUIPPED)

Your vehicle may be equipped with a universal garage door opener which
can be used to replace the common hand-held transmitter.

Car2U

姞 Home Automation System (if equipped)

The Car2U

威 Home Automation

System is a universal transmitter
located in the driver’s visor that
includes two primary features – a
garage door opener and a platform
for remote activation of devices
within the home. The Car2U

威

system’s garage door opener
function replaces the common
hand-held garage door opener with a three-button transmitter that is
integrated into the interior of your vehicle. After being programmed for
garage doors, the Car2U

威 system transmitter can be programmed to

operate security devices and home lighting systems.

WARNING: Make sure that people and objects are clear of the
garage door or security device you are programming. Do not

program the Car2U

威 system with the vehicle in the garage.

Do not use the Car2U

威 system with any garage door opener that lacks safety

stop and reverse features as required by U.S. Federal Safety Standards (this
includes any garage door opener manufactured before April 1, 1982).

Be sure to keep the original remote control transmitter for use in other
vehicles as well as for future Car2U

威 system programming. It is also

recommended that upon the sale or lease termination of the vehicle, the
programmed Car2U

威 system buttons should be erased for security

reasons. Refer to Erasing the Car2U

威 Home Automation System

buttons later in this section.

Read the instructions completely before attempting to program the
Car2U

威 system. Because of the steps involved, it may be helpful to have

another person assist you in programming the transmitter.

Driver Controls

Additional Car2U

威 system information can be found on-line at

www.learcar2U.com or by calling the toll-free Car2U

威 system help line at

1-866-572-2728.

Types of garage door openers (rolling code and fixed code)

The Car2U

威 Home Automation System may be programmed to operate

rolling code and fixed code garage door openers.
• Rolling code garage door openers were produced after 1996 and are

code protected. Rolling code means the coded signal is changed every
time your remote control garage door opener is used.

• Fixed code garage door openers were produced prior to 1996. Fixed

code uses the same coded signal every time. It is manually
programmed by setting DIP switches for a unique personal code.

If you do not know if your garage
door opener is a rolling code or fixed
code device, open your garage door
opener’s remote control battery
cover. If a panel of DIP switches is
present your garage door opener is a
fixed code device. If not, your garage
door opener is a rolling code device.

Note: Programming the Car2U

威

system to a community gate will
require a unique set of instructions
depending on the gate system model. Contact the Car2U

威 help line at

1-866-572-2728 to program your Car2U

威 system.

Note: Accidentally entering the program mode may override previously
programmed buttons. This can happen by pressing and releasing the
outer two buttons, or all three buttons, simultaneously. If this happens,
do not press any button until the module times out after approximately
2.5 seconds and resets to normal mode. When time-out occurs, all three
LEDs will flash rapidly for a few seconds then turn off. Any settings
should remain as previously set.

Rolling code programming

Note: Programming the rolling code garage door opener involves
time-sensitive actions. Read the entire procedure prior to beginning so
you will know which actions are time-sensitive. If you do not follow the
time-sensitive actions, the device will time out and you will have to
repeat the procedure.

Note: Do not program the Car2U

威 system with the vehicle in the garage.

2 3 4

9 10 11 12

CTS 206-12 T124

Driver Controls

Make sure that your key is on and engine off while programming the
transmitter.

1. Firmly press the two outer
Car2U

威 system buttons for

1–2 seconds, then release.

威

system help line at 1-866-57Car2U (1-866-572-2728).

3. Return to your vehicle. Press and
hold the Car2U

威 system button you

would like to use to control the
garage door. You may need to hold
the button from 5–20 seconds,
during which time the selected
button indicator light will blink
slowly. Immediately (within
1 second) release the button once the garage door moves. When the
button is released, the indicator light will begin to blink rapidly until
programming is complete.

4. Press and release the button again. The garage door should move,
confirming that programming is successful. If your garage door does not
operate, repeat the previous steps in this section.

After successful programming, you will be able to operate your Car2U

威

system by pressing the button you programmed to activate the opener.

Driver Controls

The indicator light above the selected button will turn on to confirm that
the Car2U

威 system is responding to the button command.

To program another rolling code device such as an additional garage door
opener, a security device or home lighting, repeat Steps 1 through 4
substituting a different function button in Step 3 than what you used for
the garage door opener. For example, you could assign the left-most
button to the garage door, the center button to a security device, and
the right-most button to another garage door opener.

Note: The Car2U

威 system allows for three devices to be programmed. If

you need to change or replace any of the three devices after it has been
initially programmed, it is necessary to erase the current settings using
the Erasing the Car2U

威 Home Automation System buttons procedure

and then programming all of the devices being used.

Fixed code programming

Note: Do not program the Car2U

威 system with the vehicle in the garage.

Make sure that your key is on and engine off while programming the
transmitter.

1. To program units with fixed code DIP switches, you will need the
garage door hand-held transmitter, paper and a pen or pencil.

2. Open the battery cover and record the switch settings from left to
right for all 8 to 12 switches. Use the figure below:

When a switch is in the up, on, or + position, circle “L.”

When a switch is in the middle, neutral, or 0 position, circle “M.”

When a switch is in the down, off, or – position, circle “R.”

Switch position

Up, on or +

Middle, neutral or 0

Down, off or –

L=left; M=middle; R=right

Driver Controls
