• SONG SEEK MENU- Press OK to enter song seek menu.

Press

to scroll through the following options:

a. SAVE THIS SONG?: Press OK to save the currently playing song’s
title in the system’s memory. (If you try to save something other than
a song, CANT SAVE will appear in the display.) When the chosen song
is playing on any satellite radio channel, the system will alert you with
an audible prompt. Press OK while SONG ALERT is in the display and
the system will take you to the channel playing the desired song. You
can save up to 20 song titles. If you attempt to save more than 20
titles, the display will read REPLACE SONG? Press OK to access the
saved titles and press

to cycle through the saved titles. When

the song title appears in the display that you would like to replace,
press OK. SONG REPLACED will appear in the display.
b. DELETE A SONG?: Press OK to delete a song from the system’s
memory. Press

to cycle through the saved songs. When the

song appears in the display that you would like to delete, press OK.
The song will appear in the display for confirmation. Press OK again
and the display will read SONG DELETED. If you do not want to
delete the currently listed song, press

to select either

RETURN or CANCEL.
Note: If there are no songs presently saved, the display will read NO
SONGS.
c. DELETE ALL SONGS?: Press OK to delete all song’s from the
system’s memory. The display will read ARE YOU SURE ? Press OK to
confirm deletion of all saved songs and the display will read ALL
DELETED.
Note: If there are no songs presently saved, the display will read NO
SONGS.
d. DISABLE ALERTS/ENABLE ALERTS?: Press OK to
enable/disable the satellite alert status which alerts you when your
selected songs are playing on a satellite radio channel. (The system
default is disabled.) SONG ALERTS ENABLED/DISABLED will appear
in the display. The menu listing will display the opposite state. For
example, if you have chosen to enable the song alerts, the menu
listing will read DISABLE as the alerts are currently on, so your other
option is to turn them off.

Entertainment Systems

• CHANNEL LOCKOUT MENU- Press OK to enter the Channel

Lockout menu. Press the

to scroll through the following

options:
a. LOCK/UNLOCK THIS CHANNEL: Press OK when
LOCK/UNLOCK THIS CHANNEL is displayed and the display will read
ENTER PIN. Enter your four-digit PIN number (initial PIN is 1234)
and the system will lock/unlock the channel and CHANNEL LOCKED
or UNLOCKED will be displayed.
Note: you must be tuned to the specific channel you want to
lock/unlock when using this feature.
b. CHANGE PIN: Press OK when CHANGE PIN is displayed. The
display will read ENTER OLD PIN. Enter your current (old) PIN
number and when the system accepts your entry it will display
ENTER NEW PIN. Enter your new four-digit PIN and the system will
save the new PIN and PIN SAVED will display.
c. UNLOCK ALL CHANNELS: Press OK when UNLOCK ALL
CHANNELS is displayed and the display will read ENTER PIN. Enter
your four-digit PIN and the system will unlock all channels and the
display will read CHANNEL UNLOCKED.
d. RESET PIN: Press OK when RESET PIN is displayed. The display
will read ARE YOU SURE. Press OK again to automatically reset the
PIN number to its initial password setting (1234). PIN RESET TO
DEFAULT PIN will be displayed.
e. RETURN: Press OK when RETURN is displayed and the system
will exit back to the satellite radio menu.

Sound Adjustments

Press SOUND repeatedly to cycle through the following features:

• BASS: Press

SEEK/TRACK

or turn the tune knob to adjust

the level of bass.

• TREBLE: Press

SEEK/TRACK

or turn the tune knob to

adjust the level of treble.

• BALANCE: Press

SEEK/TRACK

or turn the tune knob to

adjust the audio between the left (L) and right (R) speakers.

• FADE: Press

SEEK/TRACK

or turn the tune knob to adjust

the audio between the back (B) and front (F) speakers.

Entertainment Systems

• SPEED COMPENSATED VOLUME (if equipped): Allows the radio

volume to automatically adjust with vehicle speed to compensate for
road and wind noise. Use

SEEK/TRACK

to select from 1

(lowest) to 7 (highest) or to turn the feature off (SPEED OFF). The
default setting is off.

• ALL SEATS (Occupancy mode, if equipped): Press SOUND

repeatedly to reach the Occupancy mode setting. Press
SEEK/TRACK

to select to optimize sound for ALL SEATS,

DRIVERS SEAT or REAR SEATS.

Extra Features

AUX: Press repeatedly to cycle through LINE IN (auxiliary audio mode),
and SYNC

威 (if equipped).

For location and further information on auxiliary audio mode, refer to
Auxiliary input jack later in this chapter.

If your vehicle is equipped with SYNC

威, refer to the SYNC威 information

included with your vehicle for further information.

TUNE/OK: Your vehicle may be
equipped with special phone and
media features which will require
you to confirm commands by
pressing OK. Refer to the SYNC

威

information included with your
vehicle for further information.

(Phone): If your vehicle is equipped with SYNC

威, press to access

SYNC PHONE features. Refer to the SYNC

威 information included with

your vehicle for further information.
If your vehicle is not equipped with SYNC

威, the display will read NO

PHONE.

Entertainment Systems

Auxiliary input jack (Line in)

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

drivers use extreme caution when using any device or feature that may
take their focus off the road. Your primary responsibility is the safe
operation of the vehicle. We recommend against the use of any
handheld device while driving, encourage the use of voice-operated
systems when possible and that you become aware of applicable state
and local laws that may affect use of electronic devices while driving.

Your vehicle is equipped with an
Auxiliary Input Jack (AIJ). The
Auxiliary Input Jack provides a way
to connect your portable music
player to the in-vehicle audio
system. This allows the audio from a
portable music player to be played
through the vehicle speakers with
high fidelity. To achieve optimal
performance, please observe the
following instructions when
attaching your portable music
device to the audio system.
If your vehicle is equipped with a
navigation system, refer to
Auxiliary input jack section in the
Audio features chapter of your
Navigation system supplement.

Required equipment:

1. Any portable music player designed to be used with headphones

2. An audio extension cable with stereo male 1/8 in. (3.5 mm)
connectors at each end

To play your portable music player using the auxiliary input jack:

1. Begin with the vehicle parked and the radio turned off.

2. Ensure that the battery in your portable music player is new or fully
charged and that the device is turned off.

Entertainment Systems
