4. Locate the cargo tie-down near the

seatback. Push the loop of the retainer
strap through the tie-down. Thread the
non-loop end through the loop.

E157926

5. Weave the retainer strap through the

wheel openings.

6. Locate the front cargo tie-down at the

opposite corner of the cargo area to
the tie-down used in Step 4. Thread
the retainer strap through the tie-down
and pull tight.

7.

Secure by tying a 2-half hitch knot.

E143746

TECHNICAL SPECIFICATIONS

Wheel Lug Nut Torque Specifications

WARNING

When a wheel is installed, always remove any corrosion, dirt or foreign materials
present on the mounting surfaces of the wheel or the surface of the wheel hub,
brake drum or brake disc that contacts the wheel. Make sure that any fasteners

that attach the rotor to the hub are secured so they do not interfere with the mounting
surfaces of the wheel. Installing wheels without correct metal-to-metal contact at the
wheel mounting surfaces can cause the wheel nuts to loosen and the wheel to come off
while your vehicle is in motion, resulting in loss of control.

Ib-ft (Nm)

*

Bolt size

100 (135)

M12 x 1.5

*

Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford

recommended replacement fasteners.

Retighten the lug nuts to the specified torque within 100 miles (160 kilometers) after any
wheel disturbance (such as tire rotation, changing a flat tire, wheel removal).

E145950

Wheel pilot bore.

A

Inspect the wheel pilot bore and
mounting surface prior to installation.
Remove any visible corrosion or loose
particles.

ENGINE SPECIFICATIONS - 1.5L ECOBOOST™

Specification

Measurement

92

Cubic inches

10.0:1

Compression ratio

1-3-4-2

Firing order

0.025-0.029 in. (0.65- 0.75 mm)

Spark plug gap

Drivebelt Routing

E251823

ENGINE SPECIFICATIONS - 2.0L ECOBOOST™

Specification

Measurement

122

Cubic inches

Minimum 87 octane

Required fuel

9.3:1

Compression ratio

0.027 - 0.031 in. (0.70 - 0.80 mm)

Spark plug gap

Drivebelt Routing

E161383

A

B

The long drivebelt is on the first
pulley groove closest to the
engine.

A.

The short drivebelt is on the
second pulley groove farthest
from engine.

B.

ENGINE SPECIFICATIONS - 2.5L

Specification

Measurement

152

Cubic inches

Minimum 87 octane

Required fuel

9.7:1

Compression ratio

0.049 - 0.053 in. (1.25 - 1.35 mm)

Spark plug gap
