Replacing Side Marker Bulbs

E142472

1.

Remove the bulb socket from the
headlamp assembly by turning it
counterclockwise.

2. Remove the bulb by gently pulling the

bulb straight out of the socket.

Install the new bulb in reverse order.

Replacing Fog, Park and Turn
Signal Bulbs

A

B

E245248

Fog Lamp

A

Park/Turn Lamp

B

1.

Remove fog lamp bezel by prying away
from the bumper fascia.

E255385

2. Remove the screws and remove the

fog lamp assembly.

E245249

3. Remove the bulb holder from the lamp

assembly by turning it
counterclockwise.

4. Remove the bulb from the bulb holder

by pulling it straight out.

Install the new bulbs in reverse order from
the steps above.

Replacing Turn Signal Bulbs

E255368

Turn lamp

A

Side marker

B

2

3

E142473

1.

Make sure the headlamp control is in
the off position and open the liftgate.

2. Remove the two bolt covers using a

standard flat tip screwdriver.

3. Remove the two bolts from the lamp

assembly.

4. Gently pull the lamp assembly away

from the vehicle.

5. Disconnect the electrical connector.

6. Remove the turn signal bulb by turning

the lower bulb socket
counterclockwise. Gently pull the bulb
straight out of the socket.

Install the new bulb in reverse order.

Replacing Reverse Lamp Assembly

For bulb replacement, see your authorized
dealer.

Replacing License Plate Lamp Bulb

3

2

1

E72789

1.

Carefully release the spring clip.

2. Remove the lamp.

3. Remove the bulb.

Reverse steps to reinstall bulb.

Replacing High-Mount Brake Lamp
Bulb

Your vehicle is equipped with an LED
center high-mount stop lamp located in
the spoiler. It is designed to last the life of
the vehicle. If replacement is required, see
your authorized dealer.

BULB SPECIFICATION CHART

Replacement bulbs are specified in the
chart below. Headlamp bulbs must be
marked with an authorized “D.O.T.” for

North America to ensure lamp
performance, light brightness and pattern
and safe visibility. The correct bulbs will
not damage the lamp assembly or void the
lamp assembly warranty and will provide
quality bulb burn time.

Trade number

Function

9005LL

Headlamps high beam (Halogen Reflector)

H9

Headlamps high beam (Halogen Protector)

H1

* Headlamps cornering (HID)

H11LL

Headlamp low beam (Halogen Reflector)

9005HL+

Headlamp low beam (Halogen Protector)

D3S

* Headlamp low beam (HID)

168

Sidemarker - front

7444NA

Turn lamp - front (with fog lamp)

W21/5W

Turn lamp - front (without fog lamp)

H11

Fog lamps

LED

Tail/brake lamp

WY21W

Turn lamp - rear

921

Backup lamp

W5W

License plate lamp

W5W

Rear side marker

LED

* High-mount brake lamp

LED

* Interior lamps

* To replace these lamps - see your authorized dealer.

To replace all instrument panel lights - see your authorized dealer

CHANGING THE ENGINE AIR
FILTER

WARNING

To reduce the risk of vehicle damage
and personal burn injuries, do not
start your engine with the air cleaner

removed and do not remove it while the
engine is running.

When changing the air filter element, use
only the air filter element listed.  See
Capacities and Specifications (page
297).

For EcoBoost equipped vehicles: When
servicing the air cleaner, it is important that
no foreign material enter the air induction
system. The engine and turbocharger are
susceptible to damage from even small
particles.

Change the air filter element at the proper
interval.  See Scheduled Maintenance
(page 449).

Note: Failure to use the correct air filter
element may result in severe engine
damage. The customer warranty may be
void for any damage to the engine if the
correct air filter element is not used.

EcoBoost Engines

E171370

1.

Loosen the four fasteners and remove
the air cleaner assembly lid.

2. Remove the air filter element from the

air filter housing.

3. Wipe any dirt or debris from the air

cleaner assembly to make sure no dirt
gets in the engine and to make sure you
have a good seal.

E170433

4. Install the new air filter element. Slide

the open end of the air filter element
in first, below the tab. Then push the
closed end of the air filter into the
bottom of the tray. The closed end
should fit inside the groove in the tray.
The tab of the closed end of the air
filter should be oriented down and fit
between the forks on the tray as shown
at the arrow above.
