Ford Escape (2018 year). Manual - part 29

E138647

Power Lumbar

 (If Equipped)

E138648

MEMORY FUNCTION

 (If Equipped)

WARNINGS

Before activating the memory seat,
make sure that the area immediately
surrounding the seat is clear of

obstructions and that all occupants are
clear of moving parts.

Do not use the memory function
when your vehicle is moving.

This function automatically recalls the
position of the following:

•

Driver seat.

•

Power mirrors.

The memory control is on the driver door.

E142554

Saving a PreSet Position

1.

Switch the ignition on.

2. Adjust the memory features to your

desired position.

3. Press and hold the desired memory

button until you hear a single tone.

You can save up to three memory position
presets. You can save a memory preset at
any time.

Recalling a Pre-Set Position

Press and release the memory button
associated with your desired driving
position. The memory features move to
the position stored for that preset.

Note: You can only recall a preset memory
position when you switch the ignition off, or
when the transmission is in park (P) or
neutral (N) (and your vehicle is not moving)
if you switch the ignition on.

You can also recall a preset memory
position by:
•

Pressing the unlock button on your
intelligent access keyfob if it is linked
to a preset position.

•

Unlocking the intelligent driver door
handle if a linked key fob is present.

Note: Using a linked key fob to recall your
memory position when the ignition is off
moves the seat to the Easy Entry position.

Note: Pressing any active memory feature
adjustment control (or any memory button)
during a memory recall cancels the
operation.

Linking a PreSet Position to your
Remote Control or Intelligent Access
Key Fob

You can save preset memory positions for
up to three remote controls or intelligent
access (IA) keys.

1.

With the ignition on, move the memory
positions to the desired positions.

2. Press and hold the desired preset

button for about five seconds. A tone
sounds after about two seconds.
Continue holding until you hear a
second tone.

3. Within three seconds, press the lock

button on the remote control you are
linking.

To unlink a remote control, follow the
same procedure – except in step 3, press
the unlock button on the remote control.

Note: If more than one linked remote
control or intelligent access key is in range,
the memory function moves to the settings
of the first key to initiate a memory recall.

Easy Entry and Exit Feature

If you enable the easy entry and exit
feature, it automatically moves the driver
seat position rearward up to 2 in (5 cm)
when you switch the ignition off.

The driver seat will return to its previous
position when you switch the ignition on.

You can enable or disable this feature in
the information display.  See Information
Displays (page 92).

REAR SEATS

E155554

Folding the Seatback

With the seat empty, pull the lever up to
fold the seatback forward. You may need
to fold the outboard head restraints and
lower the center head restraint first.

Unfolding the Seatback

Pull the seatback upward to unfold the
seatback.

Recline Adjustment

 (If Equipped)

With the seat occupied, pull the lever up
to recline the seatback.

HEATED SEATS

 (If Equipped)

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must exercise care when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that insulates against
heat, such as a blanket or cushion. This
may cause the heated seat to overheat.
Do not puncture the seat with pins, needles
or other pointed objects. This may damage
the heating element which may cause the
heated seat to overheat. An overheated
seat may cause serious personal injury.

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid is spilled on the seat. Allow
the seat to dry thoroughly.

•

Operate the heated seats unless the
engine is running. Doing so can cause
the battery to lose charge.

E146941

Press the heated seat symbol to cycle
through the various heat settings and off.
Warmer settings are indicated by more
indicator lights.

REAR SEAT ARMREST

 (If Equipped)

E138656

Fold the armrest down to use the armrest
and cupholder.
