Ford Escape (2018 year). Manual - part 23

Settings

Quiet Start

Restore Default

Courtesy Wipe

Wipers

Rain Sensing

Hold OK to Create MyKey

Create MyKey

MyKey

Select Your Setting

Traction Ctrl

Max Speed

Speed Warning

Volume Limiter

Select Your Setting

Do Not Disturb

Hold OK to Clear All MyKeys

Clear MyKeys

Navigation info

Display

Select Your Setting

Language

Vehicle graphic

Select Your Setting

Distance

Temperature

System Check

All active warnings will display first if
applicable. The system check menu may
appear different based upon equipment
options and current vehicle status. Use the
up/down arrow buttons to scroll through
the list.

TRIP COMPUTER

Resetting the Trip Computer

Press and hold OK on the current screen
to reset the respective trip distance, time,
average fuel and average speed
information.

Distance to E

Indicates the approximate distance the
vehicle will travel on the fuel remaining in
the tank. Changes in driving pattern may
cause the value to vary.

Trip Odometer

Registers the distance traveled of
individual journeys.

Trip Timer

Registers the time of individual journeys.

Instantaneous Fuel

 (If Equipped)

Shows your instantaneous fuel usage.

Average Fuel

Indicates the average fuel consumption
since the function was last reset.

Digital Speedo

Shows a digital display of your vehicle
speed.

All Value

 (If Equipped)

Indicates all the respective remaining fuel,
distance, instantaneous fuel and average
fuel information.

INFORMATION MESSAGES

Note: Depending on your vehicle options
and instrument cluster type, not all of the
messages display or are available.
Additionally, the information display may
abbreviate or shorten certain messages.

E184814

Press the OK button to acknowledge and
remove some messages from the
information display. The information
display automatically removes other
messages after a short time.

You need to confirm certain messages
before you can access the menus.

Message Indicator

 (If Equipped)

The message indicator
illuminates to supplement some
messages.  It is red or amber

depending on the severity of the message
and remains on until you or your authorized
dealer have fixed the vehicle concern.

A system specific symbol with a message
indicator may supplement some
messages.

Airbag

Action

Message

Indicator

Message

Displays when the system requires service due

to a malfunction. Contact your authorized

dealer.

Amber

Airbag fault Service now

Alarm

Action

Message

Indicator

Message

Displays when the alarm has been triggered

due to unauthorized entry.  See Anti-Theft

Alarm (page 69).

Amber

Alarm Activated Check

Vehicle

Displays when the system requires service due

to a malfunction. Contact your authorized

dealer.

-

Alarm fault Service

required

Automatic Engine Shutdown

Action

Message

Indicator

Message

Displays when the engine has shut off to help

increase fuel economy.

-

Engine Shut Off For Fuel

Economy

Displays when the engine is getting ready to

shut off. You can press OK on the left steering

wheel button to override the shut down.

-

Engine Shuts Off in

{seconds to shut off:#0}

Seconds Press Ok to

Override

Auto Start-Stop

Action

Message

Indicator

Message

Switch the ignition off before leaving your

vehicle if the system has shut down the engine.

See Auto-Start-Stop (page 136).

Red

Auto StartStop Switch

ignition off

Have your vehicle checked by an authorized

dealer.

Amber

Auto StartStop

malfunction Service

required

The engine needs to be restarted, press the

clutch pedal to start.  See Auto-Start-Stop

(page 136).

-

Auto StartStop Press a

Pedal to Start Engine

Select neutral for the system to restart the

engine. See Auto-Start-Stop (page 136).

-

Auto StartStop Select

Neutral To Start Engine

The system is not functioning. A manual restart

is required.

-

Auto StartStop Manual

Restart Required

Battery and Charging System

Action

Message

Indicator

Message

Stop your vehicle as soon as it is safe to do so

and switch off the ignition. Contact your

authorized dealer.

Red

Electrical System Over-

voltage Stop Safely

Displays to warn of a low battery condition.

Turn off all unneeded electrical accessories.

Contact your authorized dealer.

Amber

Battery Low See Manual
