Ford Escape (2018 year). Manual - part 18

E171615

Intermittent wipe.

A

Low speed wipe.

B

Off.

C

Depending on your vehicle, when you
switch on the front wipers and move the
gearshift lever to reverse (R), the rear
intermittent wipe may turn on.

Rear Window Washer

E167407

Push the lever away from you to operate
the rear window washer.

When you release the lever, wiping
continues for a short period of time.

GENERAL INFORMATION

Condensation in the Exterior Front
Lamps and Rear Lamps

Exterior front lamps and rear lamps have
vents to accommodate normal changes
in air pressure.

Condensation can be a natural by-product
of this design. When moist air enters the
lamp assembly through the vents, there is
a possibility that condensation can occur
when the temperature is cold. When
normal condensation occurs, a fine mist
can form on the interior of the lens. The
fine mist eventually clears and exits
through the vents during normal operation.

Clearing time may take as long as 48 hours
under dry weather conditions.

Examples of acceptable condensation are:
•

The presence of a fine mist (no streaks,
drip marks or large droplets).

•

A fine mist covers less than 50% of the
lens.

Examples of unacceptable condensation
are:
•

A water puddle inside the lamp.

•

Streaks, drip marks or large droplets
present on the interior of the lens.

If you see any unacceptable condensation,
have your vehicle checked by an authorized
dealer.

LIGHTING CONTROL

E142449

Off.

A

Parking lamps, instrument panel
lamps, license plate lamps and
tail lamps.

B

Headlamps.

C

Headlamp High Beam

E162679

Push the lever away from you to switch
the high beam on.

Push the lever forward again or pull the
lever toward you to switch the high beams
off.

Headlamp Flasher

E162680

Slightly pull the lever toward you and
release it to flash the headlamps.

AUTOLAMPS

WARNING

The system does not relieve you of
your responsibility to drive with due
care and attention. You may need to

override the system if it does not turn the
headlamps on in low visibility conditions,
for example daytime fog.

E142451

When the lighting control is in the
autolamps position, the headlamps turn
on in low light situations, or when the
wipers turn on.

The headlamps remain on for a period of
time after you switch the ignition off.  Use
the information display controls to adjust
the period of time that the headlamps
remain on.

Note:  If you switch the autolamps on, you
cannot switch the high beams on until the
system turns the low beams on.

Windshield Wiper Activated
Headlamps

When you switch the autolamps on, the
headlamps turn on within 10 seconds of
switching the wipers on.  They turn off
approximately 60 seconds after you switch
the windshield wipers off.

The headlamps do not turn on with the
wipers:
•

During a single wipe.

•

When using the windshield washers.

•

If the wipers are in intermittent mode.

Note: If you switch the autolamps and the
autowipers on, the headlamps turn on when
the windshield wipers continuously operate.

INSTRUMENT LIGHTING
DIMMER

E231828

Press repeatedly or press and hold until
you reach the desired level.

HEADLAMP EXIT DELAY

After you switch the ignition off, you can
switch the headlamps on by pulling the
direction indicator lever toward you. You
will hear a short tone. The headlamps will
switch off automatically after three
minutes with any door open or 30 seconds
after the last door has been closed. You
can cancel this feature by pulling the
direction indicator toward you again or
switching the ignition on.

DAYTIME RUNNING LAMPS

WARNING

The daytime running lamps system
does not activate the rear lamps and
may not provide adequate lighting

during low visibility driving conditions.
Make sure you switch the headlamps on,
as appropriate, during all low visibility
conditions. Failure to do so may result in a
crash.

Type One - Conventional (Non-
Configurable)

The daytime running lamps turn on when:
1.

Switching the ignition on.

2. The transmission is not in park (P) for

vehicles with automatic transmissions,
or releasing the parking brake for
vehicles with manual transmissions.

3. The lighting control is in the off, parking

lamp or autolamps positions.

4. The headlamps are off.

Type Two - Configurable

Switch the daytime running lamps on or
off using the information display.  See
Information Displays (page 92).

The daytime running lamps turn on when:
1.

The lamps are on in the information
display.

2. Switching the ignition on.
3. The transmission is not in park (P) for

vehicles with automatic transmissions,
or releasing the parking brake for
vehicles with manual transmissions.

4. The lighting control is in the autolamps

position.

5. The headlamps are off.

The other lighting control switch positions
do not turn on the daytime running lamps.

If the daytime running lamps are off in the
information display, the lamps stay off in
all switch positions.

AUTOMATIC HIGH BEAM
CONTROL

 (If Equipped)

WARNING

The system does not relieve you of
your responsibility to drive with due
care and attention. You may need to

override the system if it does not turn the
high beams on or off.

The system turns on high beams if it is dark
enough and no other traffic is present. If it
detects an approaching vehicle’s
headlamps or tail lamps, or street lighting
ahead, the system turns off high beams
before they can distract other road users.
Low beams remain on.

Note: The system may not operate properly
if the sensor is blocked. Keep the windshield
free from obstruction or damage.
