Ford Contour (2000 year). Manual - part 15

Controls and features

58

Wipers

Lift the windshield wiper lever to
the desired speed interval.

• Intermittent: push lever up to the
first position.

• Low: push lever up to the second
position.

• High: push lever up to the third
position.

For a single wipe, push the lever
downward.

Windshield wipers and washer

Intermittent wiper control
(if equipped)

Rotate the variable intermittent
wiper control to the desired speed.

1 = Short time interval

6 = Extended time interval

Washer

Pull the lever toward the steering
wheel. The washer operates in
conjunction with the windshield
wipers.

13CCfen  17.6.99 10:53 Uhr  Seite 58

Controls and features

59

Do not use the speed control
in heavy traffic or on roads

that are winding, slippery, or
unpaved.

Off

On

Speed control (if equipped)

To turn speed control off

• Press Off, or

• turn off the vehicle ignition.

Once the speed control is switched
off, the previously programmed set
speed will be erased.

To turn speed control on

• Press On.

M

IRRORS

OFF

LO

PNL/FLR

PANEL

A/C

FLOOR

DEF

FLR

       DEF

MAX

A/C

HI

/

POWER

AUDIO

AM/FM

SCAN

SEEK

3

1

2

4

5

ANS

SIDE

1-2

EJECT

VOLUME

0 0 0 1 2 3

0 0 0 0

10

20

30

40

50

60 70 80

90

100

110

120

130

MPH

20

40

60

55

80

120

100

140

160

180

200

E

F

1

2

0

3

x 1000

4

5

6

7

8

BRAKE

CHECK
ENGINE

TRACTION
CONTROL

O/D
OFF

CLOCK

Res

Set

Acc

Coast

Off

On

TRACTION

      TROL

C

H

13CCfen  17.6.99 10:53 Uhr  Seite 59

Controls and features

60

To set a speed

Press Set Acc and release. For
speed control to operate, the speed
control must be on and the vehicle
speed must be greater than 48
km/h (30 mph).

If you drive up or down a steep hill,
your vehicle speed may vary
momentarily slower or faster than
the set speed. This is normal.

Speed control cannot reduce the
vehicle speed if it increases above
the set speed on a downhill. If your
vehicle speed is faster than the set
speed while driving on a downhill
in overdrive, you may want to shift
to the next lower gear to reduce
your vehicle speed.

Res

Set

Acc

Coast

Res

Set

Acc

Coast

If your vehicle slows down more
than 16 km/h (10 mph) below your
set speed on an uphill, your speed
control will disengage. This is
normal. Press Res to re-engage it.

13CCfen  17.6.99 10:53 Uhr  Seite 60

Controls and features

61

Res

Set

Acc

Coast

To set a lower speed

• Press and hold Coast. Release the
control when the desired vehicle
speed is reached, or

• press and release Coast. Each
press will decrease the set speed
by 1.6 km/h (1 mph), or

• depress the brake pedal. When
the desired vehicle speed is
reached, press Set Acc.

To set a higher speed

• Press and hold Set Acc. Release
when the desired set speed is
reached, or

• press and release Set Acc. Each
press will increase the set speed by
1.6 km/h (1 mph), or

• accelerate with your accelerator
pedal, then press Set Acc.

You may accelerate with the
accelerator pedal at any time
during speed control usage.
Releasing the accelerator pedal will
return your vehicle speed to the
previously set speed.

Res

Set

Acc

Coast

13CCfen  17.6.99 10:53 Uhr  Seite 61
