Ford Contour (2000 year). Manual - part 4





Instrumentation

14

These temporary malfunctions can
be corrected by filling the fuel tank
with good quality fuel and/or
properly tightening the fuel cap.
After three drive cycles without
these or any other temporary
malfunctions present, the check
engine
light should turn off. (A
driving cycle consists of a cold
engine startup followed by mixed
city/highway driving.) No
additional vehicle service is
required.

If the check engine light remains
on, have your vehicle serviced at
the first available opportunity.

Light is blinking:

Engine misfire is occuring which
could damage your catalytic
converter. You should drive in a
moderate fashion (avoid heavy
acceleration and deceleration) and
have your vehicle serviced at the
first available opportunity.

Under engine misfire
conditions, excessive

exhaust temperatures could
damage the catalytic converter,
the fuel system, interior floor
coverings or other vehicle com-
ponents, possibly causing a fire.

Instrumentation

15

CHECK

ENGINE

Air bag readiness

Briefly illuminates when the
ignition is turned on. If the light
fails to illuminate, continues to
flash, or remains on, have the
system serviced immediately.

Low fuel reminder

Illuminates as an early reminder of
a low fuel condition indicated on
the fuel gauge (refer to Fuel
Gauge
in this chapter for more
information). When refueling the
vehicle after the light first comes
on, the amount of fuel that can be
added will be less than the
advertised capacity since there is
still fuel in the tank. The ignition
must be in the ON position for this
lamp to illuminate. The lamp will
also illuminate for several seconds
immediately after the ignition is
turned to the ON position
regardless of the fuel level for bulb
verification.

CHECK

ENGINE

CHECK

ENGINE

Front foglamps (if equipped)

Illuminates when foglamps are
switched on.

Refer to Foglamp control in the
Controls and features chapter for
notes on use.

Instrumentation

16

Brake system warning

Extinguishes when the parking
brake is released. Illuminates after
releasing the parking brake to
indicate low brake fluid level.

Illumination while driving may
indicate that one of the braking
circuits has failed. The second
braking circuit will remain intact.
However, you will need to brake
harder and allow for increased
stopping distances.

BRAKE

BRAKE

Alternative design

E

F

BRAKE

O/D
OFF

0 0 0 1 2 3

0 0 0 0

10

20

30

40

50

60 70 80

90

110

120

130

MPH

20

40

60

55

80

120

100

140

160

180

200

100

CHECK

ENGINE

TRACTION

CONTROL

C

H

0 0 0 1 2 3

0 0 0 0

10

20

30

40

50

60 70 80

90

110

120

130

MPH

20

40

60

55

80

120

100

140

160

180

200

100

E

F

1

2

0

3

x 1000

4

5

6

7

8

O/D
OFF

CHECK

ENGINE

BRAKE

TRACTION

CONTROL

C

H

Instrumentation

17

Anti-lock brake system (ABS)
(if equipped)

Momentarily illuminates when the
ignition is turned on and the engine
is off. If the light stays on or
continues to flash, the ABS needs
to be serviced.

BRAKE

BRAKE

Alternative design

Brake system and ABS warning
lights

If both warning lights illuminate at
the same time while driving, stop
the vehicle
as soon as it is safe to
do so. Have the braking system
checked by your dealer or qualified
service technician before
continuing your journey.

When stopping the vehicle, slowly
reduce the speed. Use the brakes
with great care.

Have the system checked by your
dealer or qualified technician
before continuing your journey.

BRAKE

BRAKE

Alternative design
