Fig. 634: Disconnecting Lower Radiator Hose From Oil Filter Adapter 39. Lower the vehicle. Automatic Transmission Vehicles 40. Support the transmission. 41. Remove the upper two transmission-to-engine bolts and the wiring harness bracket. All Vehicles 42. Release the wiring retainers from the heater outlet tube bracket. 1. Release the knock sensor electrical connector retainer. 2. Release the engine harness routing clip.
2003 Ford Pickup F150 2003 ENGINE Engine - 4.6L & 5.4L - F150 Pickup
|
