Electric System EL-6 Combined Switches Replacement It is not necessary to dismount the combined switch base while replacing each switch. When dismount the combined switches, first dismount the connecting Front Head Lights Bulb replacement The front head light is half sealed, using a replaceable halogen osram lamp.The lamp can be replaced from the inner end without releasing off Hold the plastic bracket while replacing, do not touch the glass cover. 1.Release off the connecting wire harness from the rear end. 2.Turn the bulb anti-clockwise until it loose and off. 3.Open the rubber cover. 4.Be careful not shake or turn the bulb while removing. 5.The steps for installing is just on the contrary of removing. Note: otherwise, dust, gas or smoke will go into the light to affect the function of Focus adjustment Use a focus device, focus screen or head light tester when focusing. |
