Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid (U.S.)
Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid / Liquide de
frein automobile haute performance DOT 4 LV Motorcraft® (Canada)
PM-20 (U.S. & Canada)

Locks

Materials

Specification

Name

-

Motorcraft® Penetrating and Lock Lubricant (U.S.)
Motorcraft® Penetrating Fluid / Liquide dégrippant Motorcraft® (Canada)
XL-1 (U.S.)
CXC-51-A (Canada)

Washer Reservoir

Capacities

Quantity

Variant

Fill as required.

All.

371

Capacities and Specifications

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with Bitterant (U.S.)
Motorcraft® Premium Quality Windshield Washer Fluid / Liquide lave-glace de haute
qualité Motorcraft® (Canada)
ZC-32-B2 (U.S.)
CXC-37-A/B/D/F (Canada)

BULB SPECIFICATION CHART

Replacement bulbs are specified in the chart
below. Headlamp bulbs must be marked with
an authorized “D.O.T.” for North America to
make sure they have the proper lamp
performance, light brightness, light pattern,
and safe visibility. The correct bulbs will not
damage the lamp assembly or void the lamp
assembly warranty and will provide quality
bulb illumination time.

372

Capacities and Specifications

Trade name

Function

LED

Headlamp high beam - high series

HID

Headlamp high beam - low series

LED

Headlamp low beam - high series

HID

Headlamp low beam - low series

LED

Side marker lamp - front

LED

Park lamp - front

LED

Signature lamp

LED

Daytime running lamp

LED

Turn lamp - front

LED

Tail and brake lamp

LED

Reverse lamp

LED

Turn lamp - rear

LED

Side marker lamp - rear

LED

License plate lamp

LED

Trunk lamp

373

Capacities and Specifications

Trade name

Function

LED

High-mount brake lamp

LED

Side repeater lamp

LED

Glove compartment lamp

LED

Interior lamp

To replace any bulb, see your authorized dealer.

374

Capacities and Specifications

CONNECTING THE VEHICLE TO A
MOBILE NETWORK

What Is the Modem

The modem allows you to connect your
vehicle to the Internet to use when you are
on the road.

If you enable the modem using the Lincoln
Way app, you can access the following
services:
•

Locating and remotely starting, locking
and unlocking your vehicle. See the
information in the Lincoln Way app.

•

Automatic system updates.

Note: We may need to update operating
system software on your vehicle to keep
connected services updated without prior
notice to you.

Enabling the Modem Using The Lincoln
Way

1. Open the Lincoln Way app on your

device and log in.

2. Select your vehicle.

3. Select the option for vehicle details.

4. Select the option to activate your vehicle.

5. Switch the ignition on.

6. Make sure that the name on the screen

matches the name shown in your Lincoln
Way account.

7. Confirm the association of your vehicle

with your Lincoln Way account.

Enabling the Modem Using the
Touchscreen

E280315

Select the settings option on the
feature bar.

1. Select Lincoln Connect .

2. Select Connectivity Settings.

3. Switch connectivity features on.

375

Network Connectivity

NETWORK CONNECTIVITY – TROUBLESHOOTING

Wi-Fi Network

Possible Cause and Resolution

Symptom

I cannot connect to a Wi-Fi network.

– Password error.

•

Enter the correct network password.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Multiple access points in range with the same SSID.

•

Use a unique name for your SSID,. Do not use the default name unless it contains a
unique identifier, for example as part of the MAC address.

The Wi-Fi connection disconnects after
successful connection.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

I am close to a Wi-Fi hotspot but the network
signal strength is weak.

– Obstructed network signal.

•

If your vehicle has a heated windshield, position your vehicle so that the windshield
is not facing the Wi-Fi hotspot.

•

If your vehicle has metallic tinting on the windows but not on the windshield, position
your vehicle so that the windshield is facing the Wi-Fi hotspot or open the windows
that are facing the hotspot.

376

Network Connectivity

Possible Cause and Resolution

Symptom

•

If your vehicle has metallic tinting on the windows and the windshield, open the
windows that are facing the hotspot.

•

If your vehicle is in a garage and you have the garage door closed, open the garage
door.

I cannot see a network in the list of available
networks that I expect to see.

– Hidden network.

•

Make the network visible and try again.

I cannot see the Wi-Fi Hotspot name when I
search for Wi-Fi networks on my cell phone
or other device.

– System limitation.

•

Make sure Wi-Fi hotspot visibility is on.

•

The system does not provide a Wi-Fi hotspot at this time.

– Weak network signal

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Wi-Fi hotspot in high demand or has a slow Internet connection.

•

Use an more reliable Wi-Fi hotspot.

Software downloads take too long.

– No software update available.
– Wi-Fi network requires a subscription or acceptance of terms and conditions.

•

Test the connection using another device. If the network requires a subscription or
acceptance of terms and conditions, contact the network service provider.

The system seems to connect to a Wi-Fi
network and the signal strength is excellent
but the software does not update.

377

Network Connectivity

Mobile Network

Possible Cause and Resolution

Symptom

– Modem is not enabled.

•

Enable the modem through Lincoln Way.

– Weak network signal.

•

Move your vehicle closer to a place where the network signal is not obstructed.

I cannot confirm association with Lincoln Way
when trying to enable the modem.

378

Network Connectivity

CREATING A WI-FI HOTSPOT

You can create a Wi-Fi hotspot in your
vehicle and allow devices to connect to it for
access to the Internet.

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.
2. Select Vehicle Hotspot.
Note: The vehicle hotspot default setting is
on.

Finding the Wi-Fi Hotspot Name and
Password

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.

2. Select Vehicle Hotspot.

3. Select Settings.

Note: The SSID is the hotspot name.

4. Select View Password.

Connecting a Device to the Wi-Fi
Hotspot

1. On your device, turn on Wi-Fi and select

the hotspot from the list of available Wi-Fi
networks.

2. When prompted, enter the password.

Purchasing a Data Plan

1. Connect a device to the hotspot.
Note: The vehicle network carrier’s portal
opens on your device.

2. If the portal does not open on your

device, open a website and it redirects
to the vehicle network carrier’s portal.

Note: Secure websites do not redirect.

3. Follow the instructions on the carrier

portal to purchase a plan.

Note: If you have an active plan, the system
does not redirect to the vehicle network
carrier’s portal when you connect a device.
Visit the vehicle network carrier’s website to
purchase more data.

Note: If data usage information is available
in the vehicle hotspot menu, it is
approximate.

Note: If you carry out a master reset, the
system does not remove your vehicle from
your vehicle network carrier’s account. To
remove your vehicle from the account,
contact your vehicle network carrier.

Note: The vehicle network carrier provides
Vehicle Hotspot services, subject to your
vehicle network carrier agreement, coverage
and availability.

CHANGING THE WI-FI HOTSPOT
NAME OR PASSWORD

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect .

2. Select Vehicle Hotspot.

3. Select Settings.

4. Select Edit .

5. Select Change SSID Name.

379

Wi-Fi Hotspot

6. Enter your required SSID.

7. Select Done.
8. Select Change Password .

9. Enter your required password.

10.

Select Done.

380

Wi-Fi Hotspot

GENERAL INFORMATION

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the

road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Radio Frequencies and Reception
Factors

Note: Listening to loud audio for long
periods of time could damage your hearing.

Radio Reception Factors

The further you travel from an AM or FM station, the weaker the signal and the weaker the reception.

Distance and strength

Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with the reception.

Terrain

When you pass a ground-based broadcast repeating tower, a stronger signal may overtake a weaker one and
result in the audio system muting.

Station overload

381

Audio System

AUDIO UNIT

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

E287755

Note: Depending on your vehicle option
package, the controls may look different
from what you see here.

Note: Some features, such as satellite radio,
may not be available in your location. Check
with an authorized dealer.

Note:  The touchscreen system controls most
of the audio features.

Adjusting the Volume

E265373

Turn to adjust the volume.

Changing Radio Stations

E265696

In radio mode, turn to search through the
radio frequency band.

In satellite radio mode, turn to find the
previous or next available satellite radio
station.

Ejecting the CD

 (If Equipped)

E265032

Press and release the button to
eject a CD.

382

Audio System

Inserting a CD

 (If Equipped)

Insert a CD into the CD slot.

Playing or Pausing Media

 (If Equipped)

Press and release the button to
either play or pause the audio.

Selecting the Audio Modes

E265276

Press and release the button to
access different audio modes, for
example AM, FM and CD.

Switching the Audio Unit On and Off

Press and release the button.

Using Seek, Fast Forward and Reverse

In radio mode, select a frequency band and
press and release either button. The system
stops at the first station it finds in that
direction.

In CD mode, press and release to select the
next or previous track. Press and hold to
move quickly forward or backward through
the current track.

In satellite radio mode, press and release to
select the next or previous satellite radio
station. If you select a specific category, such
as jazz, rock or news, press to find the next
or previous station in the category you select.

DIGITAL RADIO

 (IF EQUIPPED)

Note: HD Radio broadcasts are not available
in all markets.

HD Radio technology is the digital evolution
of analog AM/FM radio. Your system has a
special receiver that allows it to receive
digital broadcasts, where available, in
addition to the analog broadcasts, it already
receives. Digital broadcasts provide a better
sound quality than analog broadcasts with
free, crystal-clear audio and no static or
distortion. For more information, and a guide
to available stations and programming,
please visit www.hdradio.com.

When HD Radio is on and you tune to a
station broadcasting HD Radio technology,
you may notice the HD Radio logo on your
screen. When this logo is available, you may
also see Title and Artist fields on-screen.

The multicast indicator appears in FM mode,
only, if the current station is broadcasting
multiple digital broadcasts. The highlighted
numbers signify available digital channels
where new or different content is available.
HD1 signifies the main programming status
and is available in analog and digital
broadcasts. Other multicast stations, HD2
through HD7, are only available digitally.

383

Audio System

When HD Radio broadcasts are active, you
can access the following functions:
•

Memory presets allow you to save an
active channel as a memory preset.
Touch and hold a memory preset slot
until the sound returns. There is a brief

mute while the radio saves the station.
Sound returns when finished. When
switching to an HD2 or HD3 memory
preset, the sound mutes before the
digital audio plays, because the system
has to reacquire the digital signal.

Note: As with any saved radio station, you
cannot access the saved station if your
vehicle is outside the station’s reception
area.

HD Radio Reception and Station Troubleshooting

Potential reception issues

If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute
due to weak signal strength.

Reception area

If you are listening to HD1, the system switches back to the analog broadcast until the digital broadcast is
available again. However, if you are listening to any of the possible HD2-HD7 multicast channels, the station
mutes and stays muted unless it is able to connect to the digital signal again.

When the system first receives a station, aside from HD2-HD7 multicast stations, it first plays the station in the
analog version. Once the receiver verifies the station is an HD Radio station, it shifts to the digital version.
Depending on the station quality, you may hear a slight sound change when the station changes from analog
to digital. Blending is the shift from analog to digital sound or digital back to analog sound.

Station blending

384

Audio System

In order to provide the best possible
experience, use the contact form to report
any station issues found while listening to a
station broadcasting with HD Radio

technology. Independent entities own and
operate each station. These stations are
responsible for the accuracy of all audio
streams and data fields.

Potential station issues

Action

Cause

Issues

No action required.  This is a broadcast issue.

This is poor time alignment by the radio
broadcaster.

Echo, stutter, skip or repeat in audio.
Increase or decrease in audio volume.

No action required.  The reception issue may
clear up as you continue to drive.

The radio is shifting between analog and
digital audio.

Sound fading or blending in and out.

No action required.  This is normal behavior.
Wait until the audio is available.

The digital multicast is not available until the
HD Radio broadcast is decoded. Once
decoded, the audio is available.

There is an audio mute delay when selecting
HD2 or HD3, multicast preset or Direct Tune.

No action required.  The station is not avail-
able in your current location.

The previously stored multicast preset or
direct tune is not available in your current
reception area.

Cannot access HD2 or HD3 multicast channel
when recalling a preset or from a direct tune.

Fill out the station issue form at website listed

below.

1

Data service issue by the radio broadcaster.

Text information does not match currently
playing audio.

Fill out the station issue form at website listed

below.

1

Data service issue by the radio broadcaster.

There is no text information shown for
currently selected frequency.

1

http://hdradio.com/stations/feedback

385

Audio System

HD Radio Technology manufactured under
license from iBiquity Digital Corporation and
foreign patents. HD Radio and the HD and
HD Radio logos are proprietary trademarks
of DTS Ford Motor Company and DTS are
not responsible for the content sent using
HD Radio technology. Content may be
changed, added or deleted at any time at
the station owner's discretion.

SATELLITE RADIO

 (IF EQUIPPED)

SiriusXM® Satellite Radio broadcasts a
variety of music, news, sports, weather, traffic
and entertainment satellite radio channels.
For more information and a complete list of
SiriusXM satellite radio channels, visit
www.siriusxm.com in the United States,
www.siriusxm.ca in Canada, or call SiriusXM
at 1-888-539-7474.

Note: This receiver includes the eCos
real-time operating system. eCos is
published under the eCos License.

Satellite Radio Reception Factors

Potential satellite radio reception issues

For optimal reception performance, keep the antenna clear of snow and ice build-up and keep luggage and
other material as far away from the antenna as possible.

Antenna obstructions

Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with your reception.

Terrain

When you pass a ground-based broadcast-repeating tower, a stronger signal may overtake a weaker one and
the audio system may mute.

Station overload

Your display may show ACQUIRING . . . to indicate the interference and the audio system may mute.

Satellite radio signal interfer-
ence

386

Audio System
