Fuel Tank

Capacities

Quantity

Variant

18.0 gal (68.1 L)

All.

Grease

Materials

Specification

Name

ESA-M1C75-B

Motorcraft® Premium Long-Life Grease (U.S.)
Motorcraft® Premium Long-Life Grease / Graisse longue durée de qualité première
Motorcraft® (Canada)
XG-1-E1 (U.S. & Canada)

ESB-M1C93-B

Motorcraft® Multi-Purpose Grease Spray (U.S.)
Motorcraft® Multi-Purpose Grease Spray / Graisse tout usage en aérosol Motorcraft®
(Canada)
XL-5-A (U.S. & Canada)

419

Capacities and Specifications

Hydraulic Brake System

Note: We recommend using DOT 4 Low
Viscosity (LV) High Performance Brake Fluid
or equivalent meeting WSS-M6C65-A2. Use
of any fluid other than the recommended
fluid could cause reduced brake
performance and not meet our performance
standards. Keep brake fluid clean and dry.
Contamination with dirt, water, petroleum
products or other materials could result in
brake system damage and possible failure.

Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid (U.S.)
Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid / Liquide de
frein automobile haute performance DOT 4 LV Motorcraft® (Canada)
PM-20 (U.S. & Canada)

Locks

420

Capacities and Specifications

Materials

Specification

Name

-

Motorcraft® Penetrating and Lock Lubricant (U.S.)
Motorcraft® Penetrating Fluid / Liquide dégrippant Motorcraft® (Canada)
XL-1 (U.S.)
CXC-51-A (Canada)

Power Transfer Unit

Capacities

Quantity

Variant

15.2 fl oz (0.45 L)

1

All.

1

Contact an authorized dealer for fluid level checking and filling.

421

Capacities and Specifications

Materials

Specification

Name

WSL-M2C192-A

Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant (U.S.)
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant / Lubrifiant synthétique
pour pont arrière SAE 75W-140 Motorcraft® (Canada)
XY-75W140-QL (U.S.)
CXY-75W140-1L (Canada)

Rear Axle

Capacities

Quantity

Variant

1.0 qt (0.95 L)

All.

422

Capacities and Specifications

Materials

Specification

Name

WSP-M2C197-A

Motorcraft® SAE 80W-90 Premium Rear Axle Lubricant (U.S.)
Motorcraft® SAE 80W-90 Premium Axle Lubricant / Lubrifiant pour essieux de très
haute qualité SAE 80W-90 Motorcraft® (Canada)
XY-80W90-QL (U.S.)
CXY-80W90-1L (Canada)

Washer Reservoir

Capacities

Quantity

Variant

Fill as required.

All.

423

Capacities and Specifications

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with Bitterant (U.S.)
Motorcraft® Premium Quality Windshield Washer Fluid / Liquide lave-glace de haute
qualité Motorcraft® (Canada)
ZC-32-B2 (U.S.)
CXC-37-A/B/D/F (Canada)

BULB SPECIFICATION CHART

The specified replacement bulbs are in the
chart below. Headlamp bulbs have an
authorized D.O.T. (Department of
Transportation) marking for North America
to affirm lamp performance, light brightness
and pattern and safe visibility. The correct
bulbs will not damage the lamp assembly or
void the lamp assembly warranty and will
provide quality bulb burn time.

424

Capacities and Specifications

Trade Number

Function

D3S.

Headlamp low and high - HID.

1

LED.

Headlamp low and high - LED.

1

LED.

Sidemarker - front.

1

LED.

Park lamp - front.

1

7444NA.

Direction indicator - front.

LED.

Signal indicator mirror lamp.

1

LED.

Approach lamp.

1

LED.

Tail and brake lamp.

1

LED.

Direction indicator - rear.

1

LED.

Backup lamp.

1

LED.

License plate lamp.

1

425

Capacities and Specifications

Trade Number

Function

LED.

High-mount brake lamp.

1

LED.

Interior lamps.

1

1

To replace these lamps, see an authorized dealer.

Note: To replace instrument panel lights, see an authorized dealer.

426

Capacities and Specifications

INSTALLING THE VEHICLE
IDENTIFICATION CARD

Install the vehicle identification card to the
specified area on the windshield.

Note: Follow the manufacturer’s installation
instructions.

Note: When installing the radio frequency
identification device, do not block objects
such as the rain sensor and the
auto-dimming sensor.

E292412

Dimension

Dimension Description

Item

1 in (25 mm)

The center of the windshield to the left edge of the identification card.

A

2 in (40 mm)

The top edge of the windshield to the top edge of the identification card.

B

427

Vehicle Identification

CONNECTING THE VEHICLE TO A
MOBILE NETWORK

What Is the Modem

The modem allows you to connect your
vehicle to the Internet to use when you are
on the road.

If you enable the modem using the Lincoln
Way app, you can access the following
services:
•

Locating and remotely starting, locking
and unlocking your vehicle. See the
information in the Lincoln Way app.

•

Automatic system updates.

Note: We may need to update operating
system software on your vehicle to keep
connected services updated without prior
notice to you.

Enabling the Modem Using The Lincoln
Way

1. Open the Lincoln Way app on your

device and log in.

2. Select your vehicle.

3. Select the option for vehicle details.

4. Select the option to activate your vehicle.

5. Switch the ignition on.

6. Make sure that the name on the screen

matches the name shown in your Lincoln
Way account.

7. Confirm the association of your vehicle

with your Lincoln Way account.

Enabling the Modem Using the
Touchscreen

Select the settings option on the
feature bar.

1. Select FordPass Connect.

2. Select Connectivity Settings.

3. Switch connectivity features on.

428

Network Connectivity

NETWORK CONNECTIVITY – TROUBLESHOOTING

Wi-Fi Network

Possible Cause and Resolution

Symptom

I cannot connect to a Wi-Fi network.

– Password error.

•

Enter the correct network password.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Multiple access points in range with the same SSID.

•

Use a unique name for your SSID,. Do not use the default name unless it contains a
unique identifier, for example as part of the MAC address.

The Wi-Fi connection disconnects after
successful connection.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

I am close to a Wi-Fi hotspot but the network
signal strength is weak.

– Obstructed network signal.

•

If your vehicle has a heated windshield, position your vehicle so that the windshield
is not facing the Wi-Fi hotspot.

•

If your vehicle has metallic tinting on the windows but not on the windshield, position
your vehicle so that the windshield is facing the Wi-Fi hotspot or open the windows
that are facing the hotspot.

429

Network Connectivity

Possible Cause and Resolution

Symptom

•

If your vehicle has metallic tinting on the windows and the windshield, open the
windows that are facing the hotspot.

•

If your vehicle is in a garage and you have the garage door closed, open the garage
door.

I cannot see a network in the list of available
networks that I expect to see.

– Hidden network.

•

Make the network visible and try again.

I cannot see the Wi-Fi Hotspot name when I
search for Wi-Fi networks on my cell phone
or other device.

– System limitation.

•

Make sure Wi-Fi hotspot visibility is on.

•

The system does not provide a Wi-Fi hotspot at this time.

– Weak network signal

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Wi-Fi hotspot in high demand or has a slow Internet connection.

•

Use an more reliable Wi-Fi hotspot.

Software downloads take too long.

– No software update available.
– Wi-Fi network requires a subscription or acceptance of terms and conditions.

•

Test the connection using another device. If the network requires a subscription or
acceptance of terms and conditions, contact the network service provider.

The system seems to connect to a Wi-Fi
network and the signal strength is excellent
but the software does not update.

430

Network Connectivity

Mobile Network

Possible Cause and Resolution

Symptom

– Modem is not enabled.

•

Enable the modem through Lincoln Way.

– Weak network signal.

•

Move your vehicle closer to a place where the network signal is not obstructed.

I cannot confirm association with Lincoln Way
when trying to enable the modem.

431

Network Connectivity

CREATING A WI-FI HOTSPOT

You can create a Wi-Fi hotspot in your
vehicle and allow devices to connect to it for
access to the Internet.

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.
2. Select Vehicle Hotspot.
Note: The vehicle hotspot default setting is
on.

Finding the Wi-Fi Hotspot Name and
Password

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.

2. Select Vehicle Hotspot.

3. Select Settings.

Note: The SSID is the hotspot name.

4. Select View Password.

Connecting a Device to the Wi-Fi
Hotspot

1. On your device, turn on Wi-Fi and select

the hotspot from the list of available Wi-Fi
networks.

2. When prompted, enter the password.

Purchasing a Data Plan

1. Connect a device to the hotspot.
Note: The vehicle network carrier’s portal
opens on your device.

2. If the portal does not open on your

device, open a website and it redirects
to the vehicle network carrier’s portal.

Note: Secure websites do not redirect.

3. Follow the instructions on the carrier

portal to purchase a plan.

Note: If you have an active plan, the system
does not redirect to the vehicle network
carrier’s portal when you connect a device.
Visit the vehicle network carrier’s website to
purchase more data.

Note: If data usage information is available
in the vehicle hotspot menu, it is
approximate.

Note: If you carry out a master reset, the
system does not remove your vehicle from
your vehicle network carrier’s account. To
remove your vehicle from the account,
contact your vehicle network carrier.

Note: The vehicle network carrier provides
Vehicle Hotspot services, subject to your
vehicle network carrier agreement, coverage
and availability.

CHANGING THE WI-FI HOTSPOT
NAME OR PASSWORD

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect .

2. Select Vehicle Hotspot.

3. Select Settings.

4. Select Edit .

5. Select Change SSID Name.

432

Wi-Fi Hotspot

6. Enter your required SSID.

7. Select Done.
8. Select Change Password .

9. Enter your required password.

10.

Select Done.

433

Wi-Fi Hotspot

GENERAL INFORMATION

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the

road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Radio Frequencies and Reception
Factors

Note: Listening to loud audio for long
periods of time could damage your hearing.

Radio Reception Factors

The further you travel from an AM or FM station, the weaker the signal and the weaker the reception.

Distance and strength

Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with the reception.

Terrain

When you pass a ground-based broadcast repeating tower, a stronger signal may overtake a weaker one and
result in the audio system muting.

Station overload

434

Audio System
