Lincoln MKX (2018 year). Manual - part 33

Check Every Month

Engine oil level.

Function of all interior and exterior lights.

Tires (including spare) for wear and proper pressure.

Windshield washer fluid level.

Fuel and water separator. Drain if necessary (or if indicated by the information display).

Holes and slots in the tail pipe to make sure they are functional and clear of debris.

Check Every Six Months

Battery connections. Clean if necessary.

Body and door drain holes for obstructions. Clean if necessary.

Cooling system fluid level and coolant strength.

Door weatherstrips for wear. Lubricate if necessary.

Hinges, latches and outside locks for proper operation. Lubricate if necessary.

Parking brake for proper operation.

519

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

Check Every Six Months

Safety belts and seat latches for wear and function.

Safety warning lamps (brake, ABS, airbag and safety belt) for operation.

Washer spray and wiper operation. Clean or replace blades as necessary.

Multi-Point Inspection

In order to keep your vehicle running right,
it is important to have the systems on your
vehicle checked regularly. This can help
identify potential issues and prevent major
problems. We recommend having the
following multi-point inspection performed
at every scheduled maintenance interval to
help make sure your vehicle keeps running
great.

Multi-Point Inspection

Hazard warning system operation

Accessory drive belt(s)

Horn operation

Battery performance

Radiator, cooler, heater and air conditioning hoses

Engine air filter

Suspension components for leaks or damage

Exhaust system

520

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

Multi-Point Inspection

Steering and linkage

Exterior lamps operation

Tires (including spare) for wear and proper pressure

2

Fluid levels

1

; fill if necessary

Windshield for cracks, chips or pits

For oil and fluid leaks

Washer spray and wiper operation

Half-shaft dust boots

1

 Brake, coolant recovery reservoir, automatic transmission and window washer

2

If your vehicle is equipped with a temporary mobility kit, check the tire sealant expiration Use By date on the canister. Replace as needed.

Be sure to ask your dealership service
advisor or technician about the multi-point
vehicle inspection. It is a comprehensive way
to perform a thorough inspection of your
vehicle. Your checklist gives you immediate
feedback on the overall condition of your
vehicle.

NORMAL SCHEDULED
MAINTENANCE

Intelligent Oil-Life Monitor™

Your vehicle is equipped with an Intelligent
Oil-Life Monitor that determines when you
should change the engine oil based on how
you use your vehicle. By using several
important factors in its calculations, the
monitor helps reduce the cost of owning your
vehicle and reduces environmental waste at
the same time.

This means you do not have to remember to
change the oil on a mileage-based schedule.
Your vehicle lets you know when an oil
change is due by displaying a message in
the information display.

The following table provides examples of
vehicle use and its impact on oil change
intervals. It is a guideline only. Actual oil
change intervals depend on several factors
and generally decrease with severity of use.

521

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

When to expect the OIL CHANGE REQUIRED Message

Vehicle Use and Example

Interval

Normal

7,500–10,000 mi (12,000–16,000 km)

Normal commuting with highway driving
No, or moderate, load or towing
Flat to moderately hilly roads
No extended idling

Severe

5,000–7,500 mi (8,000–12,000 km)

Moderate to heavy load or towing
Mountainous or off-road conditions
Extended idling
Extended hot or cold operation

Extreme

3,000–5,000 mi (5,000–8,000 km)

Maximum load or towing
Extreme hot or cold operation

522

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

Normal Maintenance Intervals

At Every Oil Change Interval as Indicated by the Information Display

1

Change engine oil and filter.

2

Rotate the tires.

Perform a multi-point inspection (recommended).

Inspect the automatic transmission fluid level (if equipped with a dipstick). Consult your dealer for requirements.

Inspect the brake pads, rotors, hoses and parking brake.

Inspect the engine cooling system strength and hoses.

Inspect the exhaust system and heat shields.

Inspect the rear axle and U-joints (All-wheel Drive only).

Inspect the half-shaft boots.

Inspect the steering linkage, ball joints, suspension, tie-rod ends, driveshaft and U-joints (All-wheel Drive only).

Inspect the tires, tire wear and measure the tread depth.

Inspect the wheels and related components for abnormal noise, wear, looseness or drag.

1

 Do not exceed one year or 10,000 mi (16,000 km) between service intervals.

2

 Reset the Intelligent Oil-Life Monitor after engine oil and filter changes.  See Oil Change Indicator Reset (page 315).

523

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

Other Maintenance Items

1

Replace cabin air filter.

2

Every 20,000 mi
(32,000 km)

Replace engine air filter.

Every 30,000 mi
(48,000 km)

Change engine coolant.

3

At 100,000 mi (160,000 km)

Replace spark plugs.

Every 100,000 mi
(160,000 km)

Inspect accessory drive belt(s).

4

Change automatic transmission fluid.

Every 150,000 mi
(240,000 km)

Replace accessory drive belt(s).

5

1

 Perform these maintenance items within 3,000 mi (4,800 km) of the last engine oil and filter change. Do not exceed the designated distance

for the interval.

2

 Inspect every 6,200 mi (10,000 km).

3

 Initial replacement at six years or 100,000 mi (160,000 km), then every three years or 50,000 mi (80,000 km).

4

 After initial inspection, inspect every other oil change until replaced.

5

 If not replaced within the last 100,000 mi (160,000 km).

524

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

SPECIAL OPERATING CONDITIONS
SCHEDULED MAINTENANCE

If you operate your vehicle primarily in any
of the following conditions, you need to
perform extra maintenance as indicated. If
you operate your vehicle occasionally under
any of these conditions, it is not necessary
to perform the extra maintenance. For
specific recommendations, see your
dealership service advisor or technician.

Perform the services shown in the following
tables when specified or within 3,000 mi
(4,800 km) of the message appearing in the
information display prompting you to change
your oil.
•

Example 1: The message comes on at
28,750 mi (46,270 km). Perform the
30,000 mi (48,000 km) automatic
transmission fluid replacement.

•

Example 2: The message has not come
on, but the odometer reads 30,000 mi
(48,000 km) (for example, the Intelligent
Oil-Life Monitor was reset at 25,000 mi
(40,000 km). Perform the engine air filter
replacement.

525

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

Towing a Trailer or Using a Car-top Carrier

Change engine oil and filter as indicated by information display and perform services listed in the Normal
Scheduled Maintenance chart.

As required

Inspect U-joints (AWD only).

Inspect frequently, service
as required

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

Replace spark plugs.

Every 60,000 mi
(96,000 km)

Extensive Idling or Low-speed Driving for Long Distances, as in Heavy Commercial Use Such as Delivery, Taxi, Patrol Car or Livery

Change engine oil and filter as indicated by information display and perform services listed in the Normal
Scheduled Maintenance chart.

As required

Replace cabin air filter.

Inspect frequently, service
as required

Replace engine air filter.

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

Replace spark plugs.

Every 60,000 mi
(96,000 km)

526

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

Operating in Dusty or Sandy Conditions Such as Unpaved or Dusty Roads

Replace cabin air filter.

Inspect frequently, service
as required

Replace engine air filter.

Inspect the wheels and related components for abnormal noise, wear, looseness or drag.

Every 5,000 mi (8,000 km)

Rotate tires, inspect tires for wear and measure tread depth.

Change engine oil and filter.

1

Every 5,000 mi (8,000 km)
or six months

Perform multi-point inspection.

Change automatic transmission fluid.

Every 30,000 mi
(48,000 km)

1

Reset your Intelligent Oil-Life Monitor after engine oil and filter changes.  See Oil Change Indicator Reset (page 315).

Exceptions

There are several exceptions to the Normal
Schedule:

Axle and PTU Maintenance

The Power Transfer Unit (PTU) and rear axle
(AWD only) in your vehicle does not require
any normal scheduled maintenance.
Changing or checking the PTU lubricant is
not necessary unless the unit has been
submerged in water or shows signs of
leakage. Contact your authorized dealer for
service.

527

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

California Fuel Filter Replacement

If you register your vehicle in California, the
California Air Resources Board has
determined that the failure to perform this
maintenance item does not nullify the
emission warranty or limit recall liability
before the completion of your vehicle's
useful life. Ford Motor Company, however,
urges you to have all recommended
maintenance services performed at the
specified intervals and to record all vehicle
service.

Hot Climate Oil Change Intervals

Vehicles operating in the Middle East, North
Africa, Sub-Saharan Africa or locations with
similar climates using an American Petroleum
Institute (API) Certified for Gasoline Engines
(Certification mark) oil of SM or SN quality,
the normal oil change interval is 5,000 mi
(8,000 km).

If the available API SM or SN oils are not
available, then the oil change interval is
3,000 mi (4,800 km).

Engine Air Filter and Cabin Air Filter
Replacement

The life of the engine air filter and cabin air
filter is dependent on exposure to dusty and
dirty conditions. Vehicles operated in these
conditions require frequent inspection and
replacement of the engine air filter and cabin
air filter.

SCHEDULED MAINTENANCE
RECORD

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

528

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

529

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

530

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

531

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

532

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

533

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance

E146852

Repair Order #:

Distance:

Engine hours (optional):

Multi-point inspection (recommended):

Signature:

Dealer stamp

534

MKX (CD9) Canada/United States of America, enUSA, Edition date: 201707, Second Printing

Scheduled Maintenance
