Dodge Charger (2019 year). Manual - part 1

FRONT VIEW

Front View

1 — Doors

4 — Windshield

2 — Exterior Mirrors

5 — Headlights

3 — Wheels/Tires

6 — Hood/Engine Compartment

GRAPHICAL TABLE OF CONTENTS

REAR VIEW

Rear View

1 — Rear Lights
2 — Trunk

GRAPHICAL TABLE OF CONTENTS

INSTRUMENT PANEL

Instrument Panel

1 — Instrument Cluster Display Controls

7 — Ignition

2 — Paddle Shifters

8 — Switch Panel

3 — Multifunction Lever (Behind Steering Wheel)

9 — Uconnect System

4 — Headlight Switch (Behind Steering Wheel)

10 — Climate Controls

5 — Instrument Cluster

11 — Front Power Outlet

6 — Speed Controls

GRAPHICAL TABLE OF CONTENTS

INTERIOR

Interior

1 — Door Locks

5 — Seats

2 — Door Handles

6 — Gear Selector

3 — Window Switches

7 — Glove Compartment

4 — Memory Seat Switches

GRAPHICAL TABLE OF CONTENTS

VEHICLE USER GUIDE — IF EQUIPPED

Access your Owner’s Information right through your
Uconnect 4C or 4C NAV touchscreen system — If Equipped.

To access the Vehicle User Guide on your Uconnect Touch-
screen: Press the Uconnect Apps button. From there, press
the Vehicle User Guide icon on your touchscreen. No
Uconnect registration is required.

NOTE:

Vehicle User Guide features are not available while

the vehicle is moving. If you try to access while the vehicle
is in motion, the system will display: Feature not available
while the vehicle is in motion.

Pre-Installed Features

Your User Guide —
Updated in real-time

Available when and where
you need it

Touchscreen convenience

Customizable interface

Maintenance schedules
and information

Multilingual

Comprehensive icon &
symbol glossary

Once you launch your Vehicle User Guide, you will be able
to explore your warranty information and radio manual
when and where you need them. Your Uconnect system
displays the Vehicle User Guide on your touchscreen radio
to assist in better understanding your vehicle. There’s no
app to download, no phone to connect and no external
device needed for playback. Plus, it’s updated throughout
the year, in real-time, so it never goes out of date.

Uconnect 4C NAV With 8.4–inch Display Vehicle User

Guide Touchscreen Icon

GETTING TO KNOW YOUR VEHICLE

Features/Benefits
• Pre-installed on your Uconnect touchscreen radio
• Enhanced search and browsing capability
• Robust NAV application — If Equipped
• Add selected topics to a fast-access Favorites category
• Icon and symbol glossary
• Warranty information
• Crucial driver information and assistance:

Operating Instructions

Maintenance Schedules

Warranty Information

Emergency Procedures

Fluid Level Standards

911 Contact and More

Tip:

When viewing a topic, tap the star icon to add it to

your Favorites, for easy access in the future.

KEYS

Key Fob

Your vehicle uses a keyless ignition system. The ignition
system consists of a key fob with Remote Keyless Entry
(RKE) and a START/STOP push button ignition system.
The Remote Keyless Entry system consists of a key fob and
Keyless Enter-N-Go feature if equipped.

NOTE:

The key fob may not be found if it is located next to

a mobile phone, laptop or other electronic device; these
devices may block the key fob’s wireless signal.

The key fob allows you to lock or unlock the doors and
trunk from distances up to approximately 66 feet (20 m)
using a handheld key fob. The key fob does not need to be
pointed at the vehicle to activate the system.

NOTE:

In the ON/RUN position, key fob commands are

disabled if the vehicle is at or above 5 mph (8 km/h).

GETTING TO KNOW YOUR VEHICLE

The key fob also contains an emergency key, which is
stored in the rear of the key fob.

The emergency key allows for entry into the vehicle should
the battery in the vehicle or the key fob go dead. The
emergency key is also for locking/unlocking the glove
compartment. You can keep the emergency key with you
when valet parking.

To remove the emergency key, slide the mechanical release
button on the back of the key fob sideways with your
thumb and then pull the key out with your other hand.

Key Fob

Emergency Key

GETTING TO KNOW YOUR VEHICLE

In case the ignition switch does not change with the push
of a button, the key fob may have a low or fully depleted
battery. A low key fob battery can be verified by referring
to the instrument cluster, which will display directions to
follow.

NOTE:

In a situation of a low or fully depleted battery, a

backup method can be used to operate the ignition switch.
Put the nose side of the key fob (side opposite of the
Emergency Key) against the ENGINE START/STOP button
and push to operate the ignition switch.

To Unlock The Doors

Push and release the unlock button on the key fob once to
unlock the driver’s door or twice within five seconds to
unlock all doors.

The turn signal lights will flash to acknowledge the unlock
signal. The illuminated entry system will also be activated.

NOTE:

All door unlock settings can be programmed to your

convenience through Uconnect Settings. Refer to “Uconnect
Settings” in “Multimedia” for further information.
• Unlock the driver door on the first push of the key fob

unlock button.

• Unlock all doors on the first push of the key fob unlock

button.

Emergency Key Removal Process

1 — Mechanical Release Button
2 — Emergency Key

GETTING TO KNOW YOUR VEHICLE

NOTE:

To unlock doors and trunk with passive entry, refer

to “Keyless Enter-N-Go — Passive Entry” located in
“Doors” in “Getting To Know Your Vehicle” for further
information.

NOTE:

When you use the key fob to open any door, the

courtesy lights, overhead lights, and approach lighting in
the outside mirrors (if equipped) will turn on. Refer to
“Interior Lights” in “Getting To Know Your Vehicle” for
further information.

1st Press Of Key Fob Unlocks

This feature lets you program the system to unlock either
the driver’s door or all doors on the first push of the unlock
button on the key fob.

To change the current setting, refer to “Uconnect Settings”
in “Multimedia” for further information.

Flash Lights With Lock

This feature will cause the turn signal lights to flash when
the doors are locked with the key fob. This feature can be
turned on or turned off. To change the current setting, refer
to “Uconnect Settings” in “Multimedia” for further infor-
mation.

Headlight Illumination On Approach

This feature activates the headlights for up to 90 seconds
when the doors are unlocked with the key fob. The time for
this feature is programmable, on vehicles equipped,
through Uconnect Settings. To change the current setting,
refer to “Uconnect Settings” in “Multimedia” for further
information.

To Unlatch The Trunk

Push the trunk button on the key fob two times within five
seconds to unlatch the trunk.

If the vehicle is equipped with Passive Entry, refer to
“Keyless Enter-N-Go — Passive Entry” under “Getting To
Know Your Vehicle” for further information.

To Lock The Doors And Trunk

Push and release the lock button on the key fob to lock all
doors.

The turn signal lights will flash and the horn will chirp to
acknowledge the signal if programmed. Refer to “Uconnect
Settings” in “Multimedia” for further programmable infor-
mation.

GETTING TO KNOW YOUR VEHICLE

NOTE:

To lock the doors with passive entry, Refer to

“Keyless Enter-N-Go — Passive Entry” located in “Doors”
in “Getting To Know Your Vehicle” for further information.

If one or more doors are open, or the trunk is open, the
doors will lock. The doors will unlock automatically if the
key fob is left inside the passenger compartment, otherwise
the doors will stay locked.

Sound Horn With Lock

This feature will cause the horn to chirp when the doors are
locked with the key fob. This feature can be turned on or
turned off. To change the current setting, refer to “Uconnect
Settings” in “Multimedia” for further information.

Using The Panic Alarm

To turn the Panic Alarm feature on or off, push the Panic
button on the key fob. When the Panic Alarm is activated,
the turn signals will flash, the horn will pulse on and off,
and the interior lights will turn on.

The Panic Alarm will stay on for three minutes unless you
turn it off by either pushing the Panic button a second time
or drive the vehicle at a speed of 15 mph (24 km/h) or
greater.

NOTE:
• The interior lights will turn off if you place the ignition

in the ACC or ON/RUN position while the Panic Alarm
is activated. However, the exterior lights and horn will
remain on.

• You may need to be less than 35 ft (11 m) from the

vehicle when using the key fob to turn off the Panic
Alarm due to the radio frequency noises emitted by the
system.

Key Fob Battery Replacement

The recommended replacement battery is one CR2032
battery.

NOTE:
• Perchlorate Material — special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate for fur-
ther information.

• Do not touch the battery terminals that are on the back

housing or the printed circuit board.

GETTING TO KNOW YOUR VEHICLE

1. Remove the emergency key by sliding the mechanical

latch on the back of the key fob sideways with your
thumb and then pull the emergency key out with your
other hand.

2. Separate the key fob halves using the tip of the emer-

gency key, a #2 flat blade screwdriver, or a coin and
gently pry the two halves of the key fob apart. Make
sure not to damage the seal during removal.

Emergency Key Removal

1 — Emergency Key Release Button
2 — Emergency Key

Emergency Key Removal

GETTING TO KNOW YOUR VEHICLE

Separating Case With A Coin

NOTE:

Separating the case can also be done with a key

blade or a flat head screwdriver.

Separating Case With A Key Blade

GETTING TO KNOW YOUR VEHICLE

3. Remove the battery by turning the back cover over

(battery facing downward) and tapping it lightly on a
solid surface such as a table or similar surface, and then
replace the battery. When replacing the battery, match
the + sign on the battery to the + sign on the inside of the
battery clip, located on the back cover. Avoid touching
the new battery with your fingers because skin oils may
cause battery deterioration. If you touch a battery, clean
it with rubbing alcohol.

4. To assemble the key fob case, snap the two halves together.

Separating Case With A Flat Blade Screwdriver

Key Fob Battery Replacement

GETTING TO KNOW YOUR VEHICLE

Programming Additional Key Fobs

Programming the key fob may be performed by an autho-
rized dealer.

NOTE:

Once a key fob is programmed to a vehicle, it cannot

be repurposed and reprogrammed to another vehicle.

Request For Additional Remote Controls

NOTE:

Only key fobs that are programmed to the vehicle

electronics can be used to start and operate the vehicle.
Once a key fob is programmed to a vehicle, it cannot be
programmed to any other vehicle.

WARNING!

• Always remove the key fobs from the vehicle and

lock all doors when leaving the vehicle unattended.

• For vehicles equipped with Keyless Enter-N-Go —

Ignition, always remember to place the ignition in
the OFF mode.

Duplication of key fobs may be performed at an authorized
dealer. This procedure consists of programming a blank
key fob to the vehicle electronics. A blank key fob is one
that has never been programmed.

NOTE:

When having the Sentry Key Immobilizer System

serviced, bring all vehicle keys with you to an authorized
dealer.

General Information

The following regulatory statement applies to all radio
frequency (RF) devices equipped in this vehicle:

This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-
tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

GETTING TO KNOW YOUR VEHICLE

IGNITION SWITCH

Keyless Push Button Ignition

This feature allows the driver to operate the ignition with
the push of a button as long as the key fob is in the
passenger compartment.

The Keyless Push Button Ignition has four operating
positions, three of which are labeled and will illuminate
when in position. The three positions are OFF, ACC, and
ON/RUN. The fourth position is START. During start,
ON/RUN will illuminate.

NOTE:

If the ignition switch does not change with the

push of a button, the key fob may have a low or dead
battery. In this situation, a back up method can be used to
operate the ignition switch. Put the nose side (side opposite
of the emergency key) of the key fob against the ENGINE
START/STOP button and push to operate the ignition
switch.

The push button ignition can be placed in the following
modes:

OFF
• The engine is stopped.
• Some electrical devices (e.g. central locking, alarm, etc.)

are still available.

START/STOP Ignition Button

1 — OFF
2 — ACC
3 — ON/RUN

GETTING TO KNOW YOUR VEHICLE

ACC
• Engine is not started.
• Some electrical devices are available.
ON/RUN
• Driving position.
• All the electrical devices are available.
START
• The engine will start.

WARNING!

• When exiting the vehicle, always remove the key fob

from the vehicle and lock your vehicle.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

(Continued)

WARNING! (Continued)

• Do not leave the key fob in or near the vehicle, or in

a location accessible to children, and do not leave the
ignition of a vehicle equipped with Keyless Enter-
N-Go in the ON/RUN mode. A child could operate
power windows, other controls, or move the vehicle.

• Do not leave children or animals inside parked

vehicles in hot weather. Interior heat build-up may
cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for thieves. Al-
ways remove key fob from the vehicle and lock all
doors when leaving the vehicle unattended.

NOTE:

Refer to

⬙Starting The Engine,⬙ in ⬙Starting And

Operating

⬙ for further information.

GETTING TO KNOW YOUR VEHICLE

Content .. 1 2 ..
