Dodge Challenger (2019 year). Manual

Setting Name

Selectable Options

Electric Power Steering

Default— If Equipped

Sport

Normal

Comfort

NOTE:
When

⬙Electric Power Steering Default⬙ is selected, it allows you to change the default setting of your vehicle to either

normal, sport, or comfort.

ParkSense — If Equipped

Sound Only

Sound and Display

NOTE:
The ParkSense system will scan for objects behind the vehicle when the gear selector is in REVERSE and the vehicle
speed is less than 7 mph (11 km/h). It will provide an alert (audible and/or visual) to indicate the proximity to other
objects. The system can be enabled with Sound Only, or Sound and Display.

Rear ParkSense Volume —

If Equipped

Low

Medium

High

NOTE:
The Rear ParkSense Chime Volume settings can be selected from the instrument cluster display or Uconnect System.
The chime volume settings include LOW, MEDIUM, and HIGH. The factory default volume setting is MEDIUM. To
make your selection, press the “Rear ParkSense Vol.” button on the touchscreen, until a check-mark appears next to
setting, indicating that the setting had been selected. ParkSense will retain its last known configuration state through
ignition cycles.

Rear ParkSense Braking

Assist— If Equipped

Off

MULTIMEDIA

429

Setting Name

Selectable Options

Blind Spot Alert — If

Equipped

Off

Lights

Lights and Chimes

NOTE:

• When this feature is selected, the Blind Spot Alert feature Provides alerts, visual and/or audible, to indicate objects

in your blind spot. The Blind Spot Alert feature can be activated in “Lights” mode. When this mode is selected, the
Blind Spot Monitor (BSM) system is activated and will only show a visual alert in the exterior mirrors. When
“Lights & Chime” mode is activated, the Blind Spot Monitor (BSM) will show a visual alert in the exterior mirrors
as well as an audible alert when the turn signal is on. When “Off” is selected, the Blind Spot Monitor (BSM) sys-
tem is deactivated.

• If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not dam-

aged, the sensor may have become misaligned. Take your vehicle to an authorized dealer to verify sensor align-
ment. Having a sensor that is misaligned will result in the BSM not operating to specification.

ParkView Backup Camera

Active Guidelines

Off

NOTE:
Your vehicle may be equipped with the ParkView Rear Back Up Camera Active Guidelines that allows you to see ac-
tive guidelines over the ParkView Back up camera display whenever the gear selector is put into REVERSE. The im-
age will be displayed on the radio touchscreen display along with a caution note to “check entire surroundings”
across the top of the screen. After five seconds, this note will disappear.

430

MULTIMEDIA

Setting Name

Selectable Options

ParkView Backup Camera

Delay

Off

NOTE:
When the vehicle is shifted out of REVERSE (with camera delay turned OFF), the rear camera mode is exited and the
navigation or audio screen appears again. When the vehicle is shifted out of REVERSE (with camera delay turned
ON), the rear view image with dynamic grid lines will be displayed for up to ten seconds after shifting out of “RE-
VERSE” unless the forward vehicle speed exceeds 8 mph (12 km/h), the transmission is shifted into “PARK” or the
ignition is switched to the OFF position. To set the ParkView Backup Camera Delay, press the “Controls” button on
the touchscreen, the “settings” button on the touchscreen, then the “Safety & Driving Assistance” button on the
touchscreen.

Rain Sensing Auto Wipers

Off

NOTE:
When this feature is selected and the wipers are on, the system will automatically activate the windshield wipers if it
senses moisture on the windshield.

Hill Start Assist — If

Equipped

Off

NOTE:
When this feature is selected, the Hill Start Assist (HSA) system is active.

MULTIMEDIA

431

Lights

After pressing the “Lights” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Headlight Off Delay

Headlight Illumination On Ap-

proach

Headlights With Wipers — If

Equipped

Off

Auto Dim High Beams — If

Equipped

Off

Daytime Running Lights — If

Equipped

Off

Steering Directed Lights

Off

Flash Lights With Lock

Off

432

MULTIMEDIA

Doors & Locks

After pressing the “Doors & Locks” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Auto Door Locks — If

Equipped

Off

Auto Unlock On Exit

Off

Flash Lights With Lock

Off

NOTE:
When this feature is selected, the exterior lights flashes when the doors are locked or unlocked with the key fob. This
feature may be selected with or without the sound horn on lock feature selected.

Sound Horn With Lock

Off

1st Press

2nd Press

Sound Horn With Remote

Start

Off

1st Press of Key Fob Un-

locks

All

Driver

NOTE:
This feature allows you to program your remote door locks to open “All doors” or only the “Driver door” with the
first push of the key fob or grabbing the Passive Entry door handle.

MULTIMEDIA

433

Setting Name

Selectable Options

Passive Entry — If

Equipped

Off

NOTE:
This feature allows you to lock and unlock the vehicle’s door(s) without having to push the key fob lock or unlock
buttons. It automatically unlocks the doors when the outside door handle is grabbed.

Personal Settings Linked

To Key Fob — If

Equipped

Off

NOTE:

• This feature provides automatic recall of all settings stored to a memory location (driver’s seat, exterior mirrors,

steering column position and radio station pre-sets) to enhance driver mobility when entering and exiting the ve-
hicle.

• The seat returns to the memorized seat location (if Personal Settings Linked to Key Fob is set to on) when the key

fob is used to unlock the door.

434

MULTIMEDIA

Auto Comfort Systems — If Equipped

After pressing the “Auto-On Comfort” button on the
touchscreen, the following settings will be available:

Setting Name

Selectable Options

Auto-On Driver Heated/Vented Seat &

Steering Wheel — If Equipped

Off

Remote Start

All Starts

NOTE:
When this feature is selected the driver’s heated seat and heated steering wheel will automatically turn on when tem-
peratures are below 40° F (4.4° C). When temperatures are above 80° F (26.7° C) the driver vented seat will turn on.

Engine Off Options

After pressing the “Engine Off Options” button on the
touchscreen, the following settings will be available:

Setting Name

Selectable Options

Headlight Off Delay

Engine Off Power Delay

0 sec

5 mins

45 sec

10 mins

NOTE:
When this feature is selected, the power window switches, radio, Uconnect phone system (if equipped), DVD video
system (if equipped), power sunroof (if equipped), and power outlets remain active for up to ten minutes after the
ignition is cycled to OFF. Opening either front door cancels this feature.

MULTIMEDIA

435

Compass Settings — If Equipped

After pressing the “Compass Settings” button on the
touchscreen, the following settings will be available:

NOTE:

Before compass calibration is performed, the com-

pass variance zone should be set for best results.

Setting Name

Selectable Options

Compass Variance

NOTE:
When the “Compass Variance” feature is selected, it allows the compass variance to be set to any number from 1 to
15 per the compass variance zone map figure.
Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differ-
ences, the variance should be set for the zone where the vehicle is being driven, illustrated in the zone map. Once
properly set, the compass will automatically compensate for the differences when calibrated, and provide the most
accurate compass headings.

436

MULTIMEDIA

Compass Calibration

Yes

NOTE:
Press “Compass Calibration” on the touchscreen to enter calibration. To start calibration of the compass, press the “Yes” but-
ton on the touchscreen and complete one or more 360-degree turns (in an area free from large metal or metallic objects). A
message will appear on the touchscreen when the compass has been successfully calibrated.
Keep magnetic materials away from the rear view mirror, such as Mobile Phones, Laptops and Radar Detectors. This is
where the compass module is located, and it can cause interference with the compass sensor, and it may give false readings.

Compass Variance Zone Map

MULTIMEDIA

437

Audio

After pressing the “Audio” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Equalizer

NOTE:
When in the “Equalizer” display you may adjust the Bass, Mid and Treble settings. Adjust the settings with the “+”
and “–” buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the
touchscreen.

Balance/Fade

Arrow Buttons

“C” icon

NOTE:
The “Balance/Fade” feature allows you to adjust the Balance and Fade settings. Press and drag the speaker icon or
use the arrows to adjust, tap the “C” icon to readjust to the center.

Speed Adjusted Vol-

ume

Off

NOTE:
The “Speed Adjusted Volume” feature increases or decreases volume relative to vehicle speed. To change the Speed
Adjusted Volume press the “Speed Adjusted Volume” button on the touchscreen and select from “Off,” “1,” “2” or
“3” buttons on the touchscreen.

438

MULTIMEDIA

Setting Name

Selectable Options

Surround Sound —

If Equipped

Off

NOTE:
The “Surround Sound” feature provides simulated surround sound mode. To make your selection, press the “Sur-
round Sound” button on the touchscreen, and select “On” or “Off.”

AUX Volume Offset

— If Equipped

–

NOTE:
The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through
the AUX input. To make your selection, press the “AUX Volume Offset” button on the touchscreen, select “+” and
“–”.

Auto Play — If

Equipped

Off

NOTE:

The Auto Play feature allows a media device to begin playing when the media device is plugged in. To make

your selection, press the On or Off buttons to activate or deactivate Auto Play.

MULTIMEDIA

439

Phone/Bluetooth

After pressing the “Phone/Bluetooth” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Do Not Disturb

List of Settings

NOTE:

Press “Do Not Disturb” to access the available settings. The following settings are: Auto Reply (both, text,

call), Auto Reply Message (custom, default), and Custom Auto Reply Message (create message).

Paired Phones/Devices

List of Paired Phones/Devices

NOTE:
This feature shows which phones are paired to the Phone/Bluetooth system. For further information, refer to the
Uconnect Owner’s Manual Supplement.

SiriusXM Setup — If Equipped

After pressing the “SiriusXM Setup” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Tune Start

Off

Channel Skip

Name of Channel

NOTE:

SiriusXM can be programmed to skip channels. To make your selection, press the “Channel Skip” button on

the touchscreen, select the channels you would like to skip.

440

MULTIMEDIA

Setting Name

Selectable Options

Subscription Information

Subscription Info

NOTE:
New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your
radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription
Information screen to re-subscribe.

1. Press the “Subscription Info” button on the touchscreen to access the Subscription Information screen.

2. Write down the SIRIUS ID numbers for your receiver. To reactivate your service, either call the number listed on the

screen or visit the provider online.

Restore Settings

After pressing the “Restore Settings” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Restore Settings

Yes

Cancel

NOTE:
When the “Restore Settings” feature is selected it will reset the Display, Clock, Audio, and Radio Settings to their de-
fault settings. If “Yes” is selected, a pop-up will appear asking

⬙Are you sure you want to reset your settings to de-

fault?” Select “Yes” to restore, or “Cancel” to exit.

MULTIMEDIA

441

Setting Name

Selectable Options

Reset App Drawer to Default Order

Cancel

NOTE:
When this feature is selected, it will reset all settings to their default settings. To restore the settings to their default
setting, press the “Restore Settings” button on the touchscreen. A pop-up will appear asking

⬙Are you sure you want

to reset your settings to default?”

Restore Apps

Cancel

Clear Personal Data

Yes

Cancel

NOTE:

When the “Clear Personal Data” feature is selected it will remove all personal data including Clock, Audio,

Radio, Bluetooth devices, Apps, and Favorites.

Modem Reset

Cancel

Clear Personal Data

After pressing the “Clear Personal Data Settings” button on
the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Clear Personal Data

Yes

Cancel

NOTE:
When this feature is selected it will remove all personal data including Bluetooth devices and presets. If “Yes” is se-
lected a pop-up will appear asking

⬙Are you sure you want to clear all personal data?” select “Yes” to Clear, or “Can-

cel” to exit.

442

MULTIMEDIA

System Information

After pressing the “System Information” button on the
touchscreen, the following settings will be available:

Setting Name

Selectable Options

Software License

System Software Information Screen

NOTE:
When the “Software License” feature is selected, a “System Software Information” screen will appear, displaying the
system software version. You can also update your maps with a USB device. Please see your authorized dealer for
further information.

Customer Programmable Features — Uconnect
4C/4C NAV Settings

Press the “Apps

” button (if equipped), and then

press the “Settings” button on the touchscreen to dis-
play the menu setting screen. In this mode, the
Uconnect system allows you to access programmable
features that may be equipped such as Language, Dis-
play, Units, Voice, Clock & Date, Safety & Driving
Assistance, Mirrors & Wipers, Lights, Doors & Locks,
Auto-On Comfort, Key Off Options, Audio, Phone/
Bluetooth, SiriusXM Setup, Reset, and System Informa-
tion.

NOTE:

Depending on the vehicle’s options, feature set-

tings may vary.

When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting “option” until
a check-mark appears next to the setting, showing that
setting has been selected. Once the setting is complete,
press the “X” button on the touchscreen to close out of the
settings screen. Pressing the up or down arrow button on
the right side of the screen will allow you to toggle up or
down through the available settings.

MULTIMEDIA

443

Language

After pressing the “Language” button on the touchscreen,
the following settings will be available:

Setting Name

Selectable Options

Set Language

English

Français

Español

Display

After pressing the “Display” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Display Mode

Auto

Manual

Display Brightness With Headlights

–

NOTE:

• When in the “Display Brightness With Headlights ON” display, you may select the brightness with the headlights

on.

• To make changes to the ⬙Display Brightness With Headlights ON⬙ setting, the headlights must be on and the inte-

rior dimmer switch must not be in the

⬙party⬙ or ⬙parade⬙ positions.

444

MULTIMEDIA

Dodge Challenger (2019 year). Manual - part 27
