The mirror head can be adjusted up, down, left, and right
for various drivers. The mirror should be adjusted to
center on the view through the rear window.

Headlight glare from vehicles behind you can be reduced
by moving the small control under the mirror to the night
position (toward the rear of the vehicle). The mirror
should be adjusted while set in the day position (toward
the windshield).

Automatic Dimming Mirror — If Equipped

The mirror head can be adjusted up, down, left, and right
for various drivers. The mirror should be adjusted to
center on the view through the rear window.

This mirror automatically adjusts for headlight glare
from vehicles behind you.

Adjusting Rearview Mirror

130

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:

The Automatic Dimming Mirror feature is dis-

abled when the vehicle is in reverse gear to improve rear
view viewing.

The Automatic Dimming Mirror feature can be turned
On or Off through the touchscreen.

• Press the Mirror Dimmer button once to turn the

feature On.

• Press the Mirror Dimmer button a second time to turn

the feature Off.

If equipped, the rearview mirror contains an ASSIST and
a 9-1-1 button.

Automatic Dimming Mirror

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

131

WARNING!

ALWAYS obey traffic laws and pay attention to the
road. Some Uconnect Access services, including 9-1-1
and Assist, will NOT work without an operable 1X
(voice/data) or 3G (data) network connection.

NOTE:

• Your vehicle may be transmitting data as authorized

by the subscriber.

• The 9–1–1 and ASSIST buttons will only function if

you are connected to an operable 1X(voice/data) or
3G(data) network. Other Uconnect services will only
be operable if your Uconnect Access service is active
and you are connected to an operable 1X(voice/data)
or 3G(data) network.

ASSIST Call

The ASSIST Button is used to automatically connect you
to any one of the following support centers:

• Roadside Assistance – If you get a flat tire, or need a

tow, just push the ASSIST button and you’ll be con-
nected to someone who can help. Roadside Assistance
will know what vehicle you’re driving and its location.
Additional fees may apply for roadside Assistance.

• Uconnect Access Customer Care – In-vehicle support

for Uconnect Access and Uconnect Access Via Mobile
features.

• Vehicle Customer Care – Total support for all other

vehicle issues.

132

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

9-1-1 Call

1. Push the 9-1-1 Call button on the Rearview Mirror.

NOTE:

In case the 9-1-1 Call button is pushed in error,

there will be a 10 second delay before the 9-1-1 Call
system initiates a call to a 9-1-1 operator. To cancel the
9-1-1 Call connection, push the 9-1-1 Call button on the
Rearview Mirror or press the cancellation button on the
Device Screen. Termination of the 9-1-1 Call will turn off
the green LED light on the Rearview Mirror.

2. The LED light located between the ASSIST and 9-1-1

buttons on the Rearview Mirror will turn green once a
connection to a 9-1-1 operator has been made.

3. Once a connection between the vehicle and a 9-1-1

operator is made, the 9-1-1 Call system may transmit
the following important vehicle information to a 9-1-1
operator:

• Indication that the occupant placed a 9-1-1 Call.
• The vehicle brand.
• The last known GPS coordinates of the vehicle.

4. You should be able to speak with the 9-1-1 operator

through the vehicle audio system to determine if
additional help is needed.

WARNING!

ALWAYS obey traffic laws and pay attention to the
road. Some Uconnect Access services, including 9-1-1
and Assist, will NOT work without an operable 1X
(voice/data) or 3G (data) network connection.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

133

NOTE:

• Your vehicle may be transmitting data as authorized

by the subscriber.

• Once a connection is made between the vehicle’s

9-1-1 Call system and the 9-1-1 operator, the 9-1-1
operator may be able to open a voice connection with
the vehicle to determine if additional help is needed.
Once the 9-1-1 operator opens a voice connection
with the vehicle’s 9-1-1 Call system, the operator
should be able to speak with you or other vehicle
occupants and hear sounds occurring in the vehicle.
The vehicle’s 9-1-1 Call system will attempt to re-
main connected with the 9-1-1 operator until the
9-1-1 operator terminates the connection.

5. The 9-1-1 operator may attempt to contact appropriate

emergency responders and provide them with impor-
tant vehicle information and GPS coordinates.

WARNING!

• If anyone in the vehicle could be in danger (e.g.,

fire or smoke is visible, dangerous road conditions
or location), do not wait for voice contact from a
9-1-1 operator. All occupants should exit the vehicle
immediately and move to a safe location.

• Never place anything on or near the vehicle’s

operable 1X (voice/data) or 3G(data) network and
GPS antennas. You could prevent operable 1X
(voice/data) or 3G(data) network and GPS signal
reception, which can prevent your vehicle from
placing an emergency call. An operable 1X (voice/
data) or 3G(data) network and GPS signal recep-
tion is required for the 9-1-1 Call system to function
properly.

• The 9-1-1 Call system is embedded into the vehi-

cle’s electrical system. Do not add aftermarket

(Continued)

134

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING! (Continued)

electrical equipment to the vehicle’s electrical sys-
tem. This may prevent your vehicle from sending a
signal to initiate an emergency call. To avoid inter-
ference that can cause the 9-1-1 Call system to fail,
never add aftermarket equipment (e.g., two-way
mobile radio, CB radio, data recorder, etc.) to your
vehicle’s electrical system or modify the antennas
on your vehicle. IF YOUR VEHICLE LOSES BAT-
TERY POWER FOR ANY REASON (INCLUDING
DURING OR AFTER AN ACCIDENT), THE
UCONNECT FEATURES, APPS AND SERVICES,
AMONG OTHERS, WILL NOT OPERATE.

• Modifications to any part of the 9-1-1 Call system

could cause the air bag system to fail when you
need it. You could be injured if the air bag system
is not there to help protect you.

9-1-1 Call System Limitations

Vehicles sold in Canada and Mexico DO NOT have 9-1-1
Call system capabilities.

9-1-1 or other emergency line operators in Canada and
Mexico may not answer or respond to 9-1-1 system calls.

If the 9-1-1 Call system detects a malfunction, any of the
following may occur at the time the malfunction is
detected, and at the beginning of each ignition cycle:

• The Rearview Mirror light located between the ASSIST

and 9-1-1 buttons will continuously be illuminated
red.

• The Device Screen will display the following message

“Vehicle device requires service. Please contact your
dealer.”

• An In-Vehicle Audio message will state “Vehicle de-

vice requires service. Please contact your dealer.”

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

135

WARNING!

• Ignoring the Rearview Mirror light could mean you

will not have 9-1-1 Call services. If the Rearview
Mirror light is illuminated, have an authorized
dealer service the 9-1-1 Call system immediately.

• The Occupant Restraint Control module turns on

the air bag Warning Light on the instrument panel
if a malfunction in any part of the system is
detected. If the Air Bag Warning Light is illumi-
nated, have an authorized dealer service the Occu-
pant Restraint Control system immediately.

Even if the 9-1-1 Call system is fully functional, factors
beyond FCA US LLC’s control may prevent or stop the
9-1-1 Call system operation. These include, but are not
limited to, the following factors:

• Delayed accessories mode is active.
• The ignition is in the OFF position.

• The vehicle’s electrical systems are not intact.
• The 9-1-1 Call system software and/or hardware are

damaged during a crash.

• The vehicle battery loses power or becomes discon-

nected during a vehicle crash.

• 1X(voice/data) or 3G(data) network and/or Global

Positioning Satellite signals are unavailable or ob-
structed.

• Equipment malfunction at the 9-1-1 operator facility.
• Operator error by the 9-1-1 operator.
• 1X (voice/data) or 3G (data) network congestion.
• Weather.
• Buildings, structures, geographic terrain, or tunnels.

136

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!

ALWAYS obey traffic laws and pay attention to the
road. Some Uconnect Access services, including 9-1-1
and Assist, will NOT work without an operable 1X
(voice/data) or 3G (data) network connection.

NOTE:

• Your vehicle may be transmitting data as authorized

by the subscriber.

• Never place anything on or near the vehicle’s 1X

(voice/data) or 3G (data) and GPS antennas. You could
prevent 1X (voice/data) or 3G (data) and GPS signal
reception, which can prevent your vehicle from plac-
ing an emergency call. An operable 1X (voice/data) or
3G (data) network connection and a GPS signal is
required for the 9-1-1 Call system to function properly.

General Information

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received, includ-
ing interference that may cause undesired operation.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

CAUTION!

To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

137

Automatic Dimming Mirror With Rear View
Camera Display — If Equipped

A single ball joint mirror is provided in the vehicle. It is
a twist on mirror that has a fixed position at the wind-
shield. The mirror installs on the windshield button with
a counterclockwise rotation and requires no tools for
mounting. The mirror head can be adjusted up, down,
left, and right for various drivers. The mirror should be
adjusted to center on the view through the rear window.

This mirror automatically adjusts for headlight glare
from vehicles behind you.

When the vehicle is placed into reverse gear a video
display illuminates to display the image generated by the
rear view camera located on the tailgate handle. The auto
dimming feature is also disabled to improve rear view
viewing.

Outside Mirrors

To receive maximum benefit, adjust the outside mirrors
to center on the adjacent lane of traffic with a slight
overlap of the view obtained on the inside mirror.

Automatic Dimming Mirror With Rear View Camera

138

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:

If your vehicle is equipped with illuminated

approach lights under the outside mirrors they can be
turned off through the instrument cluster or the Uconnect
radio. For further information refer to “Electronic Vehicle
Information Center (EVIC)” or “Driver Information Dis-
play (DID)” and “Uconnect Settings” in “Understanding
Your Instrument Panel”.

WARNING!

Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side convex mirror.
Some vehicles will not have a convex passenger side
mirror.

Outside Mirrors Folding Feature

All outside mirrors are designed to be able to be manu-
ally folded both forward and rearward to prevent dam-
age.

Folding Mirror

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

139

Content .. 6 7 8 9 ..
