(23) Remove ignition transponder. (Fig. 18) CAUTION: The position of the steering gear must (24) Turn the steering wheel and lock the steering wheel in the straight ahead position. (25) Remove steering column support bolts. (Fig. 19) (26) Remove the screws and remove instrument panel. (Fig. 20) Fig. 17 BRAKE PEDAL SPRING 1 - STEERING COLUMN Fig. 18 IGNITION TRANSPONDER 1 - COLUMN LOCK Fig. 19 STEERING COLUMN BOLTS 1 - BOLTS (2) Fig. 20 INSTRUMENT PANEL FASTENERS 1 - UPPER SCREWS (6) 23 - 62 INSTRUMENT PANEL VA |
