Dodge Sprinter. Manual - part 279
SPECIFICATIONS - NAG1 AUTOMATIC TRANS-
MISSION
GEAR RATIOS
1ST
3.59:1
2ND
2.19:1
3RD
1.41:1
4TH
1.00:1
5TH
0.83:1
REVERSE
3.16:1
SPECIFICATIONS
COMPONENT
METRIC
(mm)
INCH (in.)
Geartrain End-play
0.3-0.5
0.012-0.020
Geartrain End-play Shim
0.2, 0.3,
0.4, and
0.5
0.008,
0.012,
0.016,
0.020
Rear Planetary Gear Set
End-play
0.15-0.6
0.006-0.024
Rear Planetary Gear Set
Snap-rings
3.0, 3.4,
and 3.7
0.118,
0.134,
0.146
B1 Clutch
Clearance -
Double Sid-
ed Friction
Discs
2 Disc
2.3-2.7
0.091-0.106
3 Disc
2.7-3.1
0.106-0.122
4 Disc
3.0-3.4
0.118-0.134
B1 Clutch
Clearance -
Single Sid-
ed Friction
Discs
4 Disc
2.2-2.6
0.087-0.102
6 Disc
2.4-2.8
0.095-0.110
8 Disc
2.6-3.0
0.102-0.118
B1 Clutch Snap-rings
2.6, 2.9,
3.2, 3.5,
3.8, and
4.1
0.102,
0.114,
0.126,
0.138,
0.150,
0.162
B2 Clutch
Clearance
4 Disc
1.9-2.3
0.075-0.091
5 Disc
2.0-2.4
0.079-0.095
B2 Clutch Snap-rings
2.9, 3.2,
3.5, 3.8,
and 4.1
0.114,
0.126,
0.138,
0.150,
0.162
B3 Clutch Clearance
2.0-2.4
0.079-0.095
B3 Clutch Snap-rings
3.2, 3.5,
3.8, 4.1,
4.4, and
4.7
0.126,
0.138,
0.150,
0.162,
0.173,
0.185
COMPONENT
METRIC
(mm)
INCH (in.)
K1 Clutch
Clearance -
Double Sid-
ed Friction
Discs
3 Disc
2.7-3.1
0.106-0.122
4 Disc
3.0-3.4
0.118-0.134
5 Disc
3.3-3.7
0.13-0.146
6 Disc
3.6-4.0
0.142-0.158
K1 Clutch
Clearance -
Single Sid-
ed Friction
Discs
6 Disc
2.4-2.8
0.095-0.110
8 Disc
2.6-3.0
0.102-0.118
10 Disc
2.8-3.2
0.110-0.126
12 Disc
2.9-3.3
0.114-0.130
K1 Clutch Snap-rings
2.6, 2.9,
3.2, 3.5,
3.8, and
4.1
0.102,
0.114,
0.126,
0.138,
0.150,
0.162
K2 Clutch
Clearance
3 Disc
2.3-2.7
0.091-0.106
4 Disc
2.4-2.8
0.095-0.110
5 Disc
2.5-2.9
0.099-0.114
6 Disc
2.7-3.1
0.106-0.122
K2 Clutch Snap-rings
2.3, 2.6,
2.9, 3.2,
3.5, and
3.8
0.091,
0.102,
0.114,
0.126,
0.138,
0.150
K3 Clutch
Clearance -
Double Sid-
ed Friction
Discs
3 Disc
2.3-2.7
0.091-0.106
4 Disc
2.4-2.8
0.095-0.110
5 Disc
2.5-2.9
0.099-0.114
K3 Clutch
Clearance -
Single Sid-
ed Friction
Discs
6 Disc
2.3-2.7
0.091-0.106
8 Disc
2.4-2.8
0.095-0.110
10 Disc
2.5-2.9
0.099-0.114
K3 Clutch Snap-rings
2.0, 2.3,
2.6, 2.9,
3.2, and
3.5
0.079,
0.091,
0.102,
0.114,
0.126,
0.138
21 - 86
AUTOMATIC TRANSMISSION NAG1 - SERVICE INFORMATION
VA
