P1756-GOV PRESS NOT EQUAL TO TARGET @ 35 - 40 PSI (GAS) (CONTINUED) For the Transmission circuit diagram (Refer to 21 - TRANSMISSION/TRANSAXLE/AUTOMATIC - 48RE - SCHE- For a complete wiring diagramRefer to Section 8W Theory of Operation The Governor Pressure Control System is used to regulate the governor pressure which controls the shifts for first, • When Monitored: • Set Condition: Possible Causes OTHER TRANSMISSION DTCS PRESENT (F856) 5-VOLT SUPPLY CIRCUIT OPEN (F856) 5-VOLT SUPPLY CIRCUIT OPEN - INTERNAL GOVERNOR PRESSURE SENSOR VALVE BODY INTERNAL TRANSMISSION POWERTRAIN CONTROL MODULE TRANSMISSION - INTERNAL DAMAGE Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to 21 - TRANSMIS- Diagnostic Test 1. CHECK IF OTHER TRANSMISSION DTCS ARE PRESENT Ignition on, engine not running. With the scan tool, read Engine DTCs. Are any other transmission DTCs present? Yes >> Refer to the Transmission category and perform the appropriate symptom(s). (Refer to 21 - TRANS- MISSION/TRANSAXLE/AUTOMATIC - 48RE - DIAGNOSIS AND TESTING) No >> Go To 2 21 - 760 AUTOMATIC TRANSMISSION - 48RE - GAS - ELECTRICAL DIAGNOSTICS DR/DH |
