P2175-LOW AIRFLOW/RESTRICTION DETECTED (SLOW ACCUMULATION) (CONTINUED) 7. TP SENSOR Connect the PCM harness connector. Ignition on, engine not running. With a scan tool, monitor the TP Sensor voltage. Connect a jumper wire between the (K22) TP Sensor No.1 Signal cir- TP Sensor No.1 voltage should start at approximately 4.8 volts and Connect a jumper wire between the (K122) TP Sensor No.2 Signal cir- TP Sensor No.2 voltage should start at approximately 0 volts and Does the TP Sensor voltage change to the appropriate voltage Yes >> Disconnect the Battery before replacing the Throttle Body Assembly. Replace the Throttle Body Assembly. After Perform the POWERTRAIN VERIFICATION TEST. (Refer No >> Go To 8 9 - 950 ENGINE - ELECTRICAL DIAGNOSTICS - 3.7L/4.7L/5.7L DR/DH |
